Mini-ITX Industrial Motherboards – 17 x 17 cm

Mini-ITX is a compact motherboard configuration designed to support computers in small form factors, for use anywhere that a compact PC is needed, including industrial environments. The Mini-ITX board is similar and backward compatible to Micro-ATX and Flex-ATX, but it has several features that set it apart.

The Mini-ITX is very small, measuring 170 mm x 170 mm (6.75 inches x 6.75 inches). Early Mini-ITX boards used ultra low power x86 processors, often soldered to the motherboard, however nowadays Mini-ITX boards are available with sockets for full powered desktop processors as well. Mini-ITX motherboards have identical I/O panels to ATX motherboards, and usually carry all the onboard peripherals expected of a standard motherboard. However they normally only have one PCI or PCIe slot – this can support two devices with a riser card in a suitable chassis.

What’s special about Industrial Grade Mini-ITX boards?

  • Extra reliability testing – designed for reliable 24x7 operation in harsh environments
  • Temperature rating – most industrial grade boards are rated to 60°C (regular & server components are normally rated to 40°C or less)
  • Long product lifecycle – each motherboard is typically available for 5-10 years
  • Support for legacy peripherals – some industrial motherboards are available with PCI slots, multiple serial ports, RS-485 ports etc.

Note: All Intel 852/855 chipsets are no longer being manufactured.

PCH = Platform Controller Hub, a family of Intel chipsets, which replaces the Northbridge/Southbridge architecture.

Commell Mini-ITX Motherboards – Industrial Grade

LV-67T 6th generation Intel® Skylake(6th) U-series processor Mini-ITX Motherboard


Support 6th generation Intel® Skylake U-series processor mobile CPU with Sunrise Point-LP chipset, DDR4 up to 32 GB, Onboard DVI-I, Display port, LVDS, 1 x Giga LAN, 1 x Giga PHY LAN, 4 x USB 2.0, 4 x USB 3.0, 6 x COM, HD Audio, 2 x SATAIIl with RAID 0,1 , GPIO, 1 x PCI slot,
1 x MiniPCI, 2 x Mini-PCIe socket, 1 x SIM slot.
LV-67T
Click here to show/ hide more info

Commell Mini-ITX Motherboard LV-67T

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, unveiled LV-67T Mini-ITX embedded system board based on Intel® 6th generation “Skylake” Core™ processor family. The “Skylake” PC is claimed to deliver 30 percent better performance than a PC base on Ivy Bridge architecture, 20 percent better performance than a PCbased on “Haswell”, and 10 percent better performance than a “Broadwell” PC.The LV-67T mobile Mini-ITX platform is designed for the 6th generation Intel® Core™ U-series processor, FCBGA1356 package. It is the first mainstream. Intel® mobile platform to support DDR4 memory (Two DDR4 SO-DIMM 1866/2133 MHz up to 32GB).

The platform is based on Intel® HD530 Graphics, this Skylake GPU offers 24 execution units (EUs) clocked at up to 1150Mhz(depending on the CPU model), The revised video engine now decodes H.265/HEVC completely in hardware and thereby much more efficiently than before. Displays can be connected one DVI-I, one LVDS and one DP port or CRT optional, up to three displays can be controlled simultaneously. LV-67T offers lots of features including high-speed data transfer interfaces such as 4 x USB3.0 and 2 x SATAIII, equipped with dual Gigabit Ethernet (One of the dual LAN with iAMT 11.0 supported), and comes with PS/2 port, 5 x RS232 and 1 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and 1 x PCI slot, 1 x MiniPCI, 2 x MiniPCIe socket (Card2 upport mSATA) and Card2 half-size choosable, 1 x SIM slot.

Features:

  • CPU: Intel® Skylake 6th generation Intel® Core™ U-series Mobile processor, FCBGA1356 package.
  • Memory: Two DDR4 1866/2133 MHz SO-DIMM up to 32 GB.
  • Chipset: Sunrise Point-LP chipset.
  • Integrated Graphics: Intel® Gen 9 integrated HD Graphics.
  • DVI interface: Onboard DVI-I connector.
  • LVDS interface: Onboard 18/24-bit single/dual channel LVDS connector with +3.3V/+5V/ +12V supply
  • Display port interface: Onboard Display port connector.
  • CRT interface: 16-pin connector.
  • LAN Interface: 1 x Intel® I210 Gigabit LAN and 1 x Intel® I219-LM Gigabit PHY LAN (Support iAMT11).
  • Serial ATA: Support 2 x SATA3 for RAID 0,1.
  • Audio: Realtek ALC262 High Definition Audio.
  • Internal I/O: 2 x SATA3, 4 x RS232, 4 x USB2.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio, 1 x PS/2, 1 x SMBUS, 1 x CRT.
  • Rear I/O: 1 x DisplayPort(optional), 1 x DVI-I, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x RS232/422/485, 1 x Audio.
  • Extended interface: One PCI slot, two PCIE Mini card, one SIM socket (Mini_card2 support mSATA).
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface.
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement: Standard 24-pin ATX power supply (20-pin is compatible) or DC input 9~24V.

Specification:

Form Factor Mini-ITX Motherboard
Processor 6 th Generation Intel® Skylake Core™ U-series Mobile Processor

Package Type:  FCBGA1356

Memory 2 x 260-pin DDR4 1866/2133 MHz SO-DIMM up to 32GB. (Unbufferred,  none-ECC memory supported only)
Chipset Sunrise Point-LP
Integrated Graphics Intel® Gen 9 integrated HD Graphics
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Serial ATA Interface 2 x SATA3 support RAID 0, 1
CRT Interface Onboard 16-pin CRT interface
 DVI Interface  Onboard DVI connector
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 Display port Interface  Onboard Display port connector
Audio Interface Realtek ALC262 HD Audio
LAN Interface 1 x IntelR I210 Gigabit Ethernet Controller

1 x IntelR I219-LM Gigabit PHY Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot‚ 1 x PCIE Mini card, 1 x Half-Size PCIE Mini card, one SIM socket

(Optional support mSATA for Mini_Card2)

Internal I/O Port 2 x SATA3, 4 x RS232, 4 x USB2.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio (MIC-in & Line-out), 1 x SMBUS, 1 x CRT
Rear I/O Port 1 x PS/2, 1 x DisplayPort, 1 x DVI-I, 1 x HDMI, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x  RS232/422/485, 1 x Line-in, 1 x Line-out, 1 x MIC-in
Power Requirement Standard 24-pin ATX power supply (20-pin is compatible) or P4 4-pin 9~24V
Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C (32 ~ 140°F)

Storage within -20 ~ 80°C (-4 ~ 176°F)


Data sheet on LV-67T
 (pdf file, opens in new tab)

LV-67S – 6th / 7th generation Intel® Core™ i7 / i5 / i3 S-series and Xeon® E3-1200 v5 processor Mini-ITX Motherboard


Support 6th & 7th generation Intel® Core™ i7 / i5 / i3 S-series and Xeon® E3-1200 v5 processor desktop CPU with Intel® C236 chipset, DDR4 up to 32 GB, Onboard DVI-I, Display port, LVDS, 1 x Giga LAN, 1 x Giga PHY LAN, 4 x USB 2.0, 6 x USB 3.0, 6 x COM, HD Audio, 4 x SATAIIl
with RAID, GPIO, PCIe X16, 1 x Mini-PCIe socket , 1 x Half-Size Mini-PCIe socket .
LV-67S
Click here to show/ hide more info

LV-67S

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, unveiled LV-67S Mini-ITX embedded system board based on Intel® 6th / 7th generation processor family.

The LV-67S desktop Mini-ITX platform is designed for the 6th / 7th generation Intel® Core™ S-series processors and Xeon® E3-1200 v5 processor in the FCLGA1151 socket. It is the first mainstream Intel® desktop platform to support DDR4 memory(Two DDR4 LO-DIMM 1866/2133 MHz up to 32GB).

The platform is based on Intel® HD530 Graphics, this Skylake GPU offers 24 execution units (EUs) clocked at up to 1150Mhz(depending on the CPU model), The revised video engine now decodes H.265/HEVC completely in hardware and thereby much more efficiently than before. Displays can be connected via 1 CRT, 1 LVDS, 1 DVI-I, 1 HDMI and one DP port or CRT optional, up to three displays can be controlled simultaneously. LV-67S offers lots of features including high-speed data transfer interfaces such as 6 x USB3.0 and 4 x SATAIII, equipped with dual Gigabit Ethernet (One of the dual LAN with iAMT 11.0 supported), and comes with PS/2 port, 5 x RS232 and 1 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and 1 PCIE x16 slot, 1 MiniPCIe socket(Support mSATA), 1 Half size MiniPCIe socket(Support mSATA), 1 Sim slot.

Features:

  • CPU: Intel® 6th / 7th generation Intel® Core™ i7/ i5/ i3 S-series and Xeon® E3-1200 v5 Desktop processor in the FCLGA1151 socket.
  • Memory: Two DDR4 1866 / 2133 MHz LO-DIMM up to 32 GB.
  • Chipset: Intel® C236 chipset.
  • Integrated Graphics: Intel® Core™ integrated HD Graphics 530 Technology.
  • DVI interface: Onboard DVI-I connector.
  • LVDS interface: Onboard 18/24-bit single/dual channel LVDS connector with +3.3V/+5V/+12V supply
  • Display port interface: Onboard Display port connector.
  • LAN Interface: 1 x Intel® I210 Gigabit LAN and 1 x Intel® I219-LM Gigabit PHY LAN.
  • Serial ATA: Support 4 x SATA3.
  • Audio: Realtek ALC262 High Definition Audio.
  • Internal I/O: 4 x SATA3, 4 x RS232, 4 x USB2.0, 2 x USB3.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio, 1 x PS/2, 1 x SMBUS, 1 x CRT.
  • Rear I/O: 1 x DisplayPort(optional), 1 x DVI-I, 1 x HDMI, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x RS232/422/485, 1 x Audio.
  • Extended interface: One PCIE X 16 slot, one PCIE Mini card, one Half-Size PCIE Mini card, one SIM socket (Optional support mSATA for Mini_Card1 and Mini_card2).
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface.
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement: Standard 24-pin ATX power supply (20-pin is compatible) and P4 4-pin 12V.

Specification:

Form Factor Mini-ITX Motherboard
Processor 6th & 7th  Generation Intel® Core™ i7 / i5 / i3 series and Xeon®

E3-1200 v5 Desktop Processor.

Package Type:  FCLGA1151

Memory 2 x 288-pin DDR4 1866/2133 MHz LO-DIMM up to 32GB         (Unbufferred,  none-ECC memory supported only)
Chipset Intel® C236 PCH-H
Integrated Graphics Intel® Core™ integrated HD Graphics 530 Technology
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Serial ATA Interface Intel® C236 PCH-H built-in 4 x Serial ATA3 interface up to 600MB/s

Support RAID 0, 1, 5, 10 and Intel Rapid Storage Technology.

CRT Interface Onboard 16-pin CRT interface
 DVI Interface  Onboard DVI connector
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 Display port Interface  Onboard Display port connector (optional)
Audio Interface Realtek ALC262 HD Audio
LAN Interface 1 x IntelR I210 Gigabit Ethernet Controller

1 x IntelR I219-LM Gigabit PHY Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot‚ 1 x PCIE Mini card, 1 x Half-Size PCIE Mini card, one SIM socket

(Optional support mSATA for Mini_Card1 and  Mini_Card2)

Internal I/O Port 4 x SATA3, 4 x RS232, 4 x USB2.0, 2 x USB3.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio (MIC-in & Line-out), 1 x PS/2(Keyboard & Mouse), 1 x SMBUS, 1 x CRT
Rear I/O Port 1 x DisplayPort, 1 x DVI-I, 1 x HDMI, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x  RS232/422/485, 1 x Line-in, 1 x Line-out, 1 x MIC-in
Power Requirement Standard 24-pin ATX power supply (20-pin is compatible) and

P4 4-pin 12V

Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C

Storage within -20 ~ 80°C

Data sheet on LV-67S (pdf file, opens in new tab)

LV-67R – 6th generation Intel® Core™ i7 / i5 / i3 H-series processor Mini-ITX Motherboard


Support 6th generation Intel® Core™ i7 / i5 / i3 H-series processor mobile CPU with Intel® QM170 chipset, DDR4 up to 32 GB, Onboard DVI-I, Display port, LVDS, 1 x Giga LAN, 1 x Giga PHY LAN, 4 x USB 2.0, 6 x USB 3.0, 6 x COM, HD Audio, 3 x SATAIIl with RAID, GPIO,
PCIe X16, 1 x Mini-PCIe socket , 1 x Half-Size Mini-PCIe socket.
LV-67R
Click here to show/ hide more info

LV-67R

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, unveiled LV-67R Mini-ITX embedded system board based on Intel® 6th generation “Skylake” Core™ processor family. The “Skylake” PC is claimed to deliver 30 percent better performance than a PC base on Ivy Bridge architecture, 20 percent better performance than a PCbased on “Haswell”, and 10 percent better performance than a “Broadwell” PC.The LV-67R mobile Mini-ITX platform is designed for the 6th generation Intel® Core™ H-series processor, FCBGA1140 package. It is the first mainstream. Intel® mobile platform to support DDR4 memory (2 DDR4 SO-DIMM 2133 MHz up to 32GB).

The platform is based on Intel® HD530 Graphics, this Skylake GPU offers 24 execution units (EUs) clocked at up to 1150Mhz(depending on the CPU model), The revised video engine now decodes H.265/HEVC completely in hardware and thereby much more efficiently than before. Displays can be connected via 1 CRT, 1 LVDS, 1 DVI-I, 1 HDMI and one DP port or CRT optional, up to three displays can be controlled simultaneously. LV-67R offers lots of features including high-speed data transfer interfaces such as 6 x USB3.0 and 3 x SATAIII, equipped with dual Gigabit Ethernet (One of the dual LAN with iAMT 11.0 supported), and comes with PS/2 port, 5 x RS232 and 1 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and 1 PCIE x16 slot, 1 MiniPCIe socket(Support mSATA), 1 Half size MiniPCIe socket(Support mSATA), 1 Sim slot.

Features:

  • CPU: Intel® 6th generation Intel® Core™ i7/ i5/ i3 H-series Mobile processor, FCBGA1440 package.
  • Memory: Two DDR4 2133 MHz SO-DIMM up to 32 GB.
  • Chipset: Intel® QM170 chipset.
  • Integrated Graphics: Intel® Core™ integrated HD Graphics 530 Technology.
  • DVI interface: Onboard DVI-I connector.
  • LVDS interface: Onboard 18/24-bit single/dual channel LVDS connector with +3.3V/+5V/ +12V supply
  • Display port interface: Onboard Display port connector.
  • CRT interface: 16-pin connector.
  • LAN Interface: 1 x Intel® I210 Gigabit LAN and 1 x Intel® I219-LM Gigabit PHY LAN.
  • Serial ATA: Support 3 x SATA3.
  • Audio: Realtek ALC262 High Definition Audio.
  • Internal I/O: 3 x SATA3, 4 x RS232, 4 x USB2.0, 2 x USB3.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio, 1 x PS/2, 1 x SMBUS, 1 x CRT.
  • Rear I/O: 1 x DisplayPort(optional), 1 x DVI-I, 1 x HDMI, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x RS232/422/485, 1 x Audio.
  • Extended interface: One PCIE X 16 slot, one PCIE Mini card, one Half-Size PCIE Mini card, one SIM socket (Mini_card2 support mSATA).
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface.
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement: Standard 24-pin ATX power supply (20-pin is compatible) or P4 4-pin 12V.

Specification:

Form Factor Mini-ITX Motherboard
Processor 6 th Generation Intel® Skylake™ i7 / i5 / i3 H-series Mobile Processor

Package Type:  FCBGA1440

Memory 2 x 260-pin DDR4 2133 MHz SO-DIMM up to 32GB. (Unbufferred,  none-ECC memory supported only)
Chipset Intel® QM170
Integrated Graphics Intel® Core™ integrated HD Graphics 530 Technology
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Serial ATA Interface Intel® QM170 built-in 3 x Serial ATA3 interface up to 600MB/s

Support RAID 0, 1, 5 and Intel Rapid Storage Technology.

CRT Interface Onboard 16-pin CRT interface
 DVI Interface  Onboard DVI connector
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 Display port Interface  Onboard Display port connector (optional)
Audio Interface Realtek ALC262 HD Audio
LAN Interface 1 x IntelR I210 Gigabit Ethernet Controller

1 x IntelR I219-LM Gigabit PHY Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot‚ 1 x PCIE Mini card, 1 x Half-Size PCIE Mini card, one SIM socket

(Optional support mSATA for Mini_Card2)

Internal I/O Port 3 x SATA3, 4 x RS232, 4 x USB2.0, 2 x USB3.0, 1 x LVDS, 1 x LPC, 1 x LCD inverter, 1 x GPIO, 1 x Audio (MIC-in & Line-out),  1 x PS/2(Keyboard & Mouse), 1 x SMBUS, 1 x CRT
Rear I/O Port 1 x DisplayPort, 1 x DVI-I, 1 x HDMI, 4 x USB3.0, 2 x LAN, 1 x RS232, 1 x  RS232/422/485, 1 x Line-in, 1 x Line-out, 1 x MIC-in
Power Requirement Standard 24-pin ATX power supply (20-pin is compatible) or P4 4-pin 6~30V
Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C

Storage within -20 ~ 80°C

Data sheet on LV-67R (pdf file, opens in new tab)

LV-67P – Mini-ITX Motherboard with Intel® Braswell Series Processor


Intel® Braswell Series Processor. Onboard DVI, HDMI , HD Audio, Serial ATA3, USB3.0 & 2.0, Gigabit LAN, PCIE Mini card, mSATA, optional choice CRT, LVDS, or Display port.
LV-67P
Click here to show/ hide more info

LV-67P

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers,
launched a Mini-ITX Motherboard form factor LV-67P consists of the Intel® Braswell Series N3710/X5-E8000,
combined with the Intel® Express chipset, Integrated Intel® Braswell SoC integrated HD Graphics Technology
with integrated memory. The COMMELL LV-67P platform provides excellent CPU, graphics, media
performance, flexibility, and enhanced security, is ideally suited to applications requiring multi-tasking
capabilities, such as gaming, surveillance, medical, defense, transportation and industrial automation
application.

The Mini-ITX Motherboard LV-67P is designed for Intel® Braswell Series processors supporting two DDR3L SO-DIMM up to 8GB and running 1600 MHz No ECC function. The platform is based on Intel® Braswell SoC integrated HD Graphics Technology that provides high-end media and graphics capabilities for devices that display videos, 2D/3D graphics and interactive content. In addition, LV-67P integrated DVI, HDMI, and optional choice CRT, LVDS or Display port for Triple display supports to provide its advanced solutions for imaging, machine vision and digital signage applications.

LV-67P offers lots of features including high-speed data transfer interfaces such as 4 x USB 3.0, equipped with two Gigabit Ethernet, and it comes with PS/2 Keyboard and Mouse port, 1 x RS232/422/485, 5 x RS232, 4 x USB2.0, Intel® High Definition Audio, one PCIE Mini card socket and one mSATA.

Features:

  • CPU: Intel® Braswell Series Processor.
  • Memory: 2 x DDR3L (support 1.35V) 1600 SO-DIMM up to 8GB.
  • Integrated Graphics: Intel® Braswell SoC integrated HD Graphics.
  • DVI interface: Onboard DVI connector.
  • HDMI interface: Onboard HDMI connector.
  • CRT: Optional onboard 2x8 CRT connector (Only LV-67PNT & LV-67PET have).
  • Display port interface: Optional Display port connector (Only LV-67PNP & LV-67PEP have).
  • LVDS interface: Optional onboard 18/24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply (Only LV-67PNX & LV-67PEX have).
  • LAN Interface: 2 x Intel® I210 Gigabit LAN.
  • Serial ATA: Support 2 x SATA3 with 600MB/s (6Gb/s) transfer rate, no support RAID 0,1. (SATA3-2 cannot use when JMSATA’s jumper cap on pin1 and pin2)
  • Audio: Realtek ALC262 HD Audio.
  • Internal I/O Port: 1 x PS/2, 4 x RS232, 1 x GPIO, 1 x Audio, 1 x SMBUS, 1 x LVDS(Optional), 1 x LCD inverter(Optional), 1 x LPC, 4 x USB 2.0, 1 x CRT(Optional), 2 x SATA3 and 1 x DC_IN.
  • External I/O Port: 1 x RS232, 1 x RS232/422/485, 1 x DVI, 1 x HDMI port, 1 x Display port(Optional), 2 x RJ45 LAN ports, 4 x USB 3.0, 1 x Audio.
  • Extended interface: One PCIE Mini card slot, one mSATA, one SIM socket. (mSATA cannot use when JMSATA’s jumper cap on pin2 and pin3)
  • GPIO interface: Onboard programmable 12 pin-header, 8-bit Digital I/O interface.
  • Power Requirement: Standard 24-pin ATX power supply or 4-pin 6~30V.

Specification:

Form Factor Mini-ITX Motherboard
Processor Intel® Braswell Series Processor N3710/X5-E8000, FCBGA1170 package
Memory 2 x DDR3L (support 1.35V) 1600 SO-DIMM up to 8GB. (Unbufferred,  none-ECC memory supported only)
Integrated Graphics Intel® HD Graphics
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Serial ATA Interface Support 2 x SATA3 with 600MB/s (6Gb/s) transfer rate, no support

RAID 0,1. (SATA3-2 cannot use when JMSATA’s jumper cap on pin1 and pin2)

 DVI Interface Onboard DVI connector
 HDMI Interface Onboard HDMI connector
 CRT Interface Onboard 16-pin CRT interface (Only LV-67PNT & LV-67PET have)
Display port Interface Onboard Display port connector (Only LV-67PNP & LV-67PEP have)
LVDS Interface One onboard 18/24-bit dual channel LVDS connector with +3.3/+5/+12V supply (Only LV-67PNX & LV-67PEX have)
Audio Interface Realtek ALC262 HD Audio
LAN Interface 2 x Intel® I210-AT Gigabit LAN
GPIO Interface Onboard programmable 12 pin-header, 8-bit Digital I/O interface
Extended Interface  One PCIE Mini card slot, one mSATA and one SIM socket.

(mSATA cannot use when JMSATA’s jumper cap on pin2 and pin3)

Internal I/O Port 1 x PS/2, 4 x RS232, 1 x GPIO, 1 x Audio (MIC-in & Line-out), 1 x SMBUS, 1 x LVDS(Optional), 1 x LCD inverter(Optional), 1 x CRT(Optional), 1 x LPC, 4 x USB 2.0, 1 x PS/2 (Keyboard & Mouse), 2 x SATA3 and 1 x DC_IN
Rear I/O Port 1 x RS232, 1 x RS232/422/485, 1 x DVI, 1 x HDMI port, 1 x Display port(Optional), 2 x RJ45 LAN ports, 4 x USB 3.0, 1 x Line-in, 1 x Line-out, 1 x MIC-in
Power Requirement Standard 24-pin ATX power supply or 4-pin 6~30V
Board Dimension 146mm x 101mm (L x W), 1.6mm
Temperature Operating within 0°C ~ 60°C (32°F ~ 140°F)

Storage within -20 ~ 80°C (-4°F ~ 176°F)




Data sheet on LV-67R
 (pdf file, opens in new tab)

LV-67O – Bay Trail Mobile Intel® Celeron™ J1900 / N2930 and Atom™ E3845 Mini-ITX Motherboard


Support Bay Trail Intel® Celeron™ J1900 / N2930 and Atom™ E3845 mobile CPU , DDR3L up to 8GB, Onboard Display port & DVI, CRT , 2 x LVDS, 2 x Giga LAN, 5 x USB 2.0, 1 x USB 3.0, 6 x COM, HD Audio, 2 x SATAIl , GPIO , PCIE X16 , 1 x Mini-PCIe socket , mSATA.
LV-67O
Click here to show/ hide more info

LV-67O

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, launched a Mini-ITX form factor LV-67O embedded system board with the Intel® Express chipset, which adopts the Bay Trail Intel® Celeron™ J1900 / N2930 and Atom™ E3845 processor family. The COMMELL LV-67O platform provides excellent CPU, graphics, media performance, flexibility, and enhanced security, is ideally suited to applications requiring multi-tasking capabilities, such as gaming, surveillance, medical, defense, transportation and industrial automation application.

The LV-67O Mini-ITX is designed for the Bay Trail Intel® Celeron™ J1900/N2930 and Atom™ E3845 processors in the FCBGA1170 socket supporting two DDR3L SO-DIMM up to 8GB and running 1066/1333 Mhz No ECC function. The platform is based on Intel® Intel® Clear Video that provides high-end media and graphics capabilities for devices that display videos, 2D/3D graphics and interactive content. In addition, LV-67O supports CRT, LVDS, DVI and one DP port to provide its advanced solutions for imaging, machine vision and digital signage applications.

LV-67O offers lots of features including high-speed data transfer interfaces such as 1 x USB3.0 and 2 x SATAII , equipped with dual Gigabit Ethernet , and comes with PS/2 Keyboard and Mouse port, 5 x RS232 and 1 x RS232/422/485, 5 x USB2.0, Intel® High Definition Audio, and one PCI Expressx16 slot, one PCIE Mini card socket, mSATA.

Features:

  • CPU: Intel® Celeron™ J1900 / N2930 and Atom™ E3845 Mobile in the FCBGA1170 socket
  • Memory: Two DDR3L (Support 1.35V) 1066/1333 MHz SO-DIMM up to 8 GB
  • Integrated Graphics: Intel® Clear Video integrated HD Graphics Technology
  • DVI interface: Onboard DVI connector (DVI and LVDS1 can’t enable simultanesouly)
  • LVDS interface: 2 x Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
  • Display port interface: Onboard Display port connector (Display port and LVDS2 can’t enable simultanesouly)
  • LAN Interface: 2 x Intel® I210 Gigabit LAN
  • Serial ATA: Support 2 x SATAII (1 x SATAII and 1 x CFast is for option)
  • Audio: Realtek ALC262 High Definition Audio Codec
  • Internal I/O Port: 4 x RS232, 1 x GPIO port,1 x Audio connector, 2 x USB2.0, 1 x SMBUS connector , 1 x CRT, 2 x LVDS, 1 x LPC, 2 x SATAII
  • External I/O Port: 1 x PS/2 Keyboard/Mouse Port,1 x RS232,1 x RS232/422/485, 1 x DVI port, 1 x Display port, 2 x RJ45 LAN ports, 3 x USB2.0, 1 x USB 3.0, 1 x HD Audio
  • Extended interface: One PCIE X 16 slot, One PCIE Mini card, One SIM socket (Optional support mSATA(SATAII) for Mini_Card)
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement : Standard 24-pin ATX power supply or 6~27V full range DC Input

Specification:

Form Factor Mini-ITX Motherboard
Processor Bay Trail  Intel® Celeron™ J1900 / N2930 and  Atom™ E3845Mobile Processor.

Package Type:  FCBGA1170

Memory 2 x 240-pin DDR3L (Support 1.35V) 1066/1333 MHz SO-DIMM up to8GB (Unbufferred,  none-ECC memory supported only)
Integrated Graphics Intel® Clear Video integrated HD Graphics Technology
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Power Management Support ACPI 5.0 compliant
Serial ATA Interface 2 x Serial ATAII interface up to 300MB/s (3Gb/s) transfer rate

(1 x CFast and 1 x SATAII is for option)

CRT Interface Onboard 16-pin CRT interface
 DVI Interface  Onboard DVI connector.(DVI and LVDS1 can’t enables imultanesouly)
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
Display port Interface Onboard Display port connector (Display port and LVDS2 can’t enable  simultanesouly)
Audio Interface Realtek ALC262 High Definition Audio Codec
LAN Interface 2 x Intel I210 Gigabit Ethernet Controller
GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot(Only support 1 Lane)‚ 1 x PCIE Mini card ,

One SIM socket (Optional support mSATA(SATAII) for Mini_Card)

Internal I/O Port 4 x RS232, 1 x GPIO port,1 x Audio (MIC-in & Line-out),  2 x  USB2.0,  1 x SMBUS connector , 1 x CRT, 2 x LVDS, 1 x LPC,  2 x SATAII
External I/O Port 1 x PS/2 (Keyboard & Mouse), 1 x RS232, 1 x RS232/422/485, 1 xDVI port, 1 x Display port, 2 x RJ45 LAN ports, 3 x USB2.0, 1 x USB 3.0, 1 x Line-in, 1 x Line-out, 1 x MIC-in
Power Requirement Standard 24-pin ATX power supply (20-pin is compatible) or 6~27V full range DC input
Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C (For LV-67OJ and LV-67ON serial)

-40 ~ 85°C (For LV-67OE serial)



Data sheet on LV-67O (pdf file, opens in new tab)

LV-67N – 4th generation Intel® Core™ i7 / i5 / i3 Mini-ITX Motherboard


Support 4th generation Intel® Core™ i7 / i5 / i3 / desktop CPU with Intel® Q87 Express, DDR3/DDR3L up to 16GB, Onboard VGA & DVI,Display port ,LVDS 2 x Giga LAN, 4 x USB 2.0, 6 x USB 3.0, 4 x COM, HD Audio, 4 x SATAIIl with RAID, GPIO, PCIe X16, 2 x Mini-PCIe socket .
LV-67N
Click here to show/ hide more info

LV-67N

Taiwan Commate Computer Inc.(COMMELL), the worldwide leader of Industrial Single Board Computers, launched a Mini-ITX form factor LV-67N embedded system board with the Intel® Q87 Express chipset, which adopts the 4th generation Intel® Core™ processor family (formerly known as “Haswell”, manufactured on 22nm processor technology). The COMMELL LV-67N platform provides excellent CPU, graphics, media performance, flexibility, and enhanced security, is ideally suited to applications requiring multi-tasking capabilities, such as gaming, surveillance, medical, defense, transportation and industrial automation application

The LV-67N Mini-ITX is designed for the 4th generation Intel® Core™ processors in the FCLGA1150 socket H3 supporting two DDR3/DDR3L DIMMS up to 16GB and running 1333/1600 Mhz No ECC function. The platform is based on Intel® HD Graphics 4600 that provides high-end media and graphics capabilities for devices that display videos, 2D/3D graphics and interactive content. In addition, LV-67N supports VGA, LVDS, DVI-I and one DP port to provide its advanced solutions for imaging, machine vision and digital signage applications.

LV-67N offers lots of features including high-speed data transfer interfaces such as 6 x USB3.0 and 4 x SATAIII supported RAID 0/1/5/10, equipped with dual Gigabit Ethernet with iAMT 9.0 supported, and comes with PS/2 Keyboard and Mouse port, 3 x RS232 and 1 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and one PCI Expressx16 slot, two PCIE Mini card socket

Features:

  • CPU: Intel® 4th generation Core™ i7/ i5/ i3/ Desktop in the FCLGA1150 socket
  • Memory: Two DDR3/DDR3L (Support 1.5V)1333/1600 MHz DIMM up to 16 GB
  • Chipset: Intel® Q87 Express chipset
  • Integrated Graphics: Intel® Core™ integrated HD Graphics 4600 Technology
  • DVI interface: Onboard DVI connector
  • LVDS interface: Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
  • Display port interface: Onboard Display port connector
  • LAN Interface: 1 x Intel® I210 Gigabit LAN and 1 x Intel® I217-LM Gigabit LAN
  • Serial ATA: Support 4 x SATAIII
  • Audio: Realtek ALC888 High Definition Audio.
  • I/O ports: 3 x RS232 and 1 x RS232/422/485 Serial Ports, 4 x USB2.0 ports, 6 x USB3.0 ports,1 x DB15 VGA port 1 x PS/2 keyboard and mouse ports
  • Extended interface: One PCIE X 16 slot, Two PCIE Mini card, One SIM socket (Optional support mSATA(SATAIII) for Mini_Card1)
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement : Standard 24-pin ATX power supply (20-pin is compatible) and P4 4-pin 12V

Specification:

Form Factor Mini-ITX Motherboard
Processor 4 th Generation Intel® Core™ i7/ i5/ i3/Celeron® Desktop Processor.

Package Type:  FCLGA1150

Memory  2 x 240-pin DDR3/DDR3L 1333/1600 MHz DIMM up to 16GB          (Unbufferred,  none-ECC memory supported only)
Chipset Intel® BD82Q87 PCH
Integrated Graphics Intel® Core™ integrated HD Graphics 4600 Technology
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Power Management ACPI 4.0 compliant
Serial ATA Interface Intel® Q87 PCH built-in 4 x Serial ATAIII interface up to 600MB/s

Support RAID 0, 1, 5, 10 and Intel Rapid Storage Technology.

(not support SATA II device)

VGA Interface Onboard 16-pin VGA interface
 DVI Interface  Onboard DVI connector
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 Display port Interface  Onboard Display port connector
Audio Interface Realtek ALC888 HD Audio
LAN Interface 1 x IntelR I210 Gigabit Ethernet Controller

1 x IntelR I217-LM Gigabit Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot‚ 2 x PCIE Mini card , One SIM socket

(Optional support mSATA(SATAIII) for Mini_Card1)

Internal I/O Port 2 x RS232, 1 x GPIO port, 1 x CDIN connector, 1 x Audio

(MIC-in & Line-out), 1 x IrDA connector, 1 x SMBUS connector ,

1 x CRT, 1 x LVDS, 1 x LPC , 4 x USB2.0, 2 x USB3.0, 4 x SATAIII

Rear I/O Port 1 x PS/2 (Keyboard & Mouse), 1 x RS232, 1 x RS232/422/485,

1 x DVI port, 1 x Display port, 2 x RJ45 LAN ports, 4 x USB3.0, 1 x Line-in, 1 x Line-out, 1 x MIC-in

Power Requirement Standard 24-pin ATX power supply (20-pin is compatible) and

P4 4-pin 12V

Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C

Storage within -20 ~ 85°C


Data sheet on LV-67N
 (pdf file, opens in new tab)

LV-67M – 4th generation Mobile Intel® Core™ i7 / i5 / i3 ,Celeron Mini-ITX Motherboard


Support 4th generation Intel® Core™ i7 / i5 / i3 , Celeron Mobile CPU with Intel® QM87 Express, DDR3L SO-DIMM up to 16GB, Onboard VGA & DVI, LVDS, Display port,2 x Giga LAN, 4 x USB 2.0, 6 x USB 3.0, 6 x COM, HD Audio, GPIO, 4 x SATAIIl with RAID,PCIe X16, 2 x Mini-PCIe socket.
LV-67M
Click here to show/ hide more info

LV-67M

The LV-67M Mini-ITX is designed for the 4th generation Intel® Core™ i7/i5/i3 , Celeron Mobile Processors in the FCBGA1364 supporting two DDR3L SO-DIMM up to 16GB and running 1333/1600 Mhz No ECC function. The platform is based on Intel® HD Graphics 4600 that provides high-end media and graphics capabilities for devices that display videos, 2D/3D graphics and interactive content. In addition, LV-67M supports VGA, LVDS, DVI-I and one DP port to provide its advanced solutions for imaging, machine vision and digital signage applications.

LV-67M offers lots of features including high-speed data transfer interfaces such as 6 x USB3.0 and 4 x SATAIII supported RAID 0/1/5/10, equipped with dual Gigabit Ethernet with iAMT 9.0 supported, and comes with PS/2 Keyboard and Mouse port, 5 x RS232 and 1 x RS232/422/485, 4 x USB2.0, Intel® High Definition Audio, and one PCI Expressx16 slot, two PCIE Mini card socket

Features:

  • CPU: Intel® 4th generation Core™ i7/ i5/ i3, Celeron Mobile Processor in the FCBGA1364 socket
  • Memory: Two DDR3L SO-DIMM 1333/1600 MHz up to 16 GB
  • Chipset: Intel® QM87 Express chipset
  • Integrated Graphics: Intel® Core™ integrated HD Graphics 4600 Technology
  • DVI interface: Onboard DVI connector
  • LVDS interface: Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
  • Display port interface: Onboard Display port connector
  • LAN Interface: 1 x Intel® I210 Gigabit LAN and 1 x Intel® I217-LM Gigabit LAN
  • Serial ATA: Support 4 x SATAIII
  • Audio: Realtek ALC888 High Definition Audio.
  • I/O ports: 5 x RS232 and 1 x RS232/422/485 Serial Ports, 4 x USB2.0 ports, 6 x USB3.0 ports, 1 x DB15 VGA port , 1 x PS/2 keyboard and mouse ports,
  • Extended interface: One PCIE X 16 slot, Two PCIE Mini card, One SIM socket (Optional support mSATA(SATAIII) for Mini_Card1)
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface
  • External Audio: Line-in, MIC-in, Front, Rear, Center/Subwoofer.
  • Power requirement : Standard 24-pin ATX power supply or 9~24V full fange DC Input

Specification:

Form Factor Mini-ITX Motherboard
Processor 4 th Generation Intel® Core™ i7/ i5/ i3 , Celeron Mobile Processor.

Package Type:  FCBGA1364

Memory  2 x 240-pin DDR3L 1333/1600 MHz SDRAM up to 16GB           (Unbufferred,  none-ECC memory supported only)
Chipset Intel® DH82QM87 PCH
Integrated Graphics Intel® Core™ integrated HD Graphics 4600 Technology
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Power Management ACPI 4.0 compliant
Serial ATA Interface Intel® QM87 PCH built-in 4 x Serial ATAIII interface up to 600MB/s transfer rate

Support RAID 0, 1, 5, 10 and Intel Rapid Storage Technology.

(not support SATA II device)

VGA Interface Onboard 16-pin VGA interface
 DVI Interface  Onboard DVI connector
LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 Display port Interface  Onboard Display port connector
Audio Interface Realtek ALC888 HD Audio
LAN Interface 1 x Intel® I210 Gigabit Ethernet Controller

1 x Intel® I217-LM Gigabit Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  1 x PCIE X 16 slot‚ 2 x PCIE Mini card , One SIM socket

(Optional support mSATA(SATAIII) for Mini_Card1)

Internal I/O Port 4 x RS232, 1 x GPIO port, 1 x CDIN connector

1 x IrDA connector, 1 x SMBUS connector ,

1 x CRT, 1 x LVDS, 1 x LPC , 4 x USB2.0, 2 x USB3.0,

4 x SATAIII , 1 x Audio (MIC-in & Line-out)

Rear I/O Port 1 x PS/2 (Keyboard & Mouse), 1 x RS232, 1 x RS232/422/485,

1 x DVI port, 1 x Display port, 2 x RJ45 LAN ports, 4 x USB3.0 ports, 1 x Line-in, 1 x Line-out, 1 x MIC-in

Power Requirement Standard 24-pin ATX power supply or 9~24V full range DC Input
Board Dimension 170 mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C

Storage within -20 ~ 85°C

Data sheet on LV-67M (pdf file, opens in new tab)

LV-67L – Mini-ITX Embedded Intel® Celeron® Processor 807UE or 847E


Mini-ITX Miniboard based on Intel Celeron Processor 807UE/847E, Intel® HM65 Express Chipset with DDR3 SDRAM, VGA, 24-bit Dual channel LVDS Interface, DVI, Giga LAN, 6 x COM, HD Audio, 10 x USB, SATAIII , LPC, Mini-PCIE, PCI-Express X16 slot, 1 x SIM socket.GPIO, DC 9V~24V
LV-67L
Click here to show/ hide more info

LV-67L

LV-67L consists of the Intel® Celeron® 807UE or 847E, combined with the Intel HM65 express chipset, Integrated extreme HD graphics Technology providing one DDR3-1066/1333 SO-DIMM SDRAM up to 4GB(807UE)or 16GB(847E) and an array of video interface including VGA, DVI and 24-bit Dual channel LVDS.

The LV-67L comes with PS/2 Keyboard and Mouse, 1 x RS232/422/485 and 5 x RS232, 2 x Intel Giga LAN, LPC, 4 x SATAII ,2 x SATAIII, 10 x USB2.0 ports and HD Audio are also integrated. Two PCIE mini card socket(or one PCIE mini card and one mSATA) allows for easily using any wireless card or other add-on cards. Additionally, The operating voltage of LV-67L is from 9V to 24V DC that is ideal for vehicle computer applications.

Features:

  • CPU: Intel Celeron Processor 807UE or 847E
  • Memory: 1 x 204-pin DDR3 1066/1333 SO-DIMM SDRAM up to 4.0GB (LV-67LNB) 2 x 204-pin DDR3 1066/1333 SO-DIMM SDRAM up to 16GB (LV-67LBU)
  • Chipset: Intel® HM65 Express Chipset
  • Integrated Graphics: Intel® Integrated extreme HD graphics Technology
  • LVDS interface: Onboard 24-bit dual channel LVDS
  • DVI interface: Onboard 20-pin DVI interface
  • LAN Interface: 1 x Intel® 82574L Giga LAN and 1 x Intel® 82579LM Giga LAN
  • Serial ATA: Support 6 x SATA ( 4 x serial ATAII, 2 x serial ATAIII , The HM65 doesn’t support RAID function )
  • Audio: Realtek ALC888 High Definition Audio.
  • I/O ports: 5 x RS232 and 1 x RS232/422/485 Serial Ports, 10 x USB2.0 ports, 1 x DB15 VGA port, PS/2 keyboard and mouse ports, 1 x LPC, 1 x SMBUS, 1 x IrDA
  • Extended interface:LV-67LNB support 2 x PCIE mini card socket, 1 x SIM socket. LV-67LBU support 1 x PCIE x16 slot, 2 x PCIE mini card socket, 1 x SIM socket. Optional support mSATA(SATAII) for above models in Mini_Card2,but SATA6 will be disabled.
  • GPIO interface: Onboard programmable 8-bit Digital I/O interface.
  • Power requirement :Standard 24-bit ATX power supply or DC 9V ~ 24V (±5%)DC input

Specification:

Form Factor Mini-ITX Motherboard
Processor Intel Celeron Processor 807UE or 847E
Memory 1 x 204-pin DDR3 1066/1333 SO-DIMM SDRAM up to 4.0GB (LV-67LNB)

2 x 204-pin DDR3 1066/1333 SO-DIMM SDRAM up to 16GB

(LV-67LBU)

Chipset Intel® HM65 Express Chipset
Real Time Clock   Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Serial ATA Interface 4 x Serial ATA ll interface up to 300MB/s

2 x SATAlll interface up to 600MB/s. Total 6 x SATA interface

(The HM65 doesn’t support RAID function )

Integrated Graphics Intel® Integrated extreme HD graphics Technology
LVDS Interface 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply
 DVI Interface  Onboard 20-pin DVI interface
Audio Interface Realtek ALC888 HD Audio
LAN Interface 1 x Intel® 82574L Gigabit Ethernet Controller

1 x Intel® 82579LM Gigabit Ethernet Controller

GPIO Interface Onboard programmable 8-bit digital I/O interface
Extended Interface  LV-67LNB support 2 x PCIE mini card socket, 1 x SIM socket.

LV-67LBU support 1 x PCIE x16 slot, 2 x PCIE mini card socket, 1 x SIM socket.

Optional support mSATA(SATAII) for above models in Mini_Card2,but SATA6 will be disabled.

Internal I/O Port 3 x RS232 , 1 x GPIO,  1 x SMBus,1 x  Front panel HD Audio,

1 x CDIN, 1 x IrDA, 6 x USB2.0, 1 x LPC, 1 x DVI, 1 x LVDS,

1 x CN_INV, 4 x Serial ATAII, 2 x Serial ATAIII

External I/O Port 1 x PS/2 , 2 x RJ45 LAN, 1 x VGA, 4 x USB2.0,1 x RS232/422/485

2 x RS232 , 1 x SPDIF and 1 x 2 Channel HD Audio

Power Requirement Standard 24-bit ATX power supply or DC 9V ~ 24V (±5%) input
Board Dimension 170mm x 170 mm (L x W)
Temperature Operating within 0 ~ 60°C

Storage within -20 ~ 85°C

Data sheet on LV-67L (pdf file, opens in new tab)

iBase Mini-ITX Motherboards – Industrial Grade

MI991 Mini-ITX Motherboard w/ Intel® C236 PCH


7th/6th Generation Intel® Xeon® E3/Core™ i7/i5/i3 & Pentium®/ Celeron® Mini-ITX Motherboard w/ Intel® C236 PCH
iBase Mini-ITX Motherboard - MI991
Click here to show/ hide more info

iBase Mini-ITX Motherboard - Mi991

The MI991 Mini-ITX motherboard is with a Socket H4 (LGA1151) socket and the Intel C236 chipset. System integrators can benefit from the MI991 equipped with space-saving compact configuration and rich I/O design for maximum flexibility.

IBASE MI991 supports up to three independent displays via Intel® HD Graphics: DVI-D, HDMI, and DisplayPort, as well as DDR4 32GB limitation on two memory slots. It uses the more expensive Intel i211 controller instead of Realtek controllers for the motherboard alongside the Intel chipset i219 NIC device. Friendly features also include eight USB, four serial ports, four SATA III as well as two Mini PCI-E, an mSATA and a PCI-E(16x) expansion slot.

Aside from the Intel® C236, the MI991 models are also offered with the Intel Q170 or H110 chipset with differences in NIC and SATA III configurations. The boards come standard with a watchdog timer and IBASE iSMART green technology featuring power on/off scheduling, power resume function, and intelligent OS recovery that reduces maintenance cost, enhances system stability and ensures long-term reliability.

Features:

  • 7th/6th Generation Intel® Xeon® E3 / Core™ i7 / i5 /i3 / Pentium® / Celeron® QC/DC processors, up to 4GHz
  • 2x DDR4 SO-DIMM, Max. 32GB, ECC compatible
  • Intel® Processor integrated graphics device, supports DVI-D, HDMI and DisplayPort
  • Dual Intel® Gigabit LAN
  • 2x USB 2.0, 6x USB 3.0, 4x COM, 4x SATAIII
  • 2x Mini PCI-E slots, 1x mSATA, 1x PCI-E(x16)
  • Watchdog timer, Digital I/O, iAMT (11.0), TPM (1.2), iSMART

Speifications:

CPU LGA1151 for 7th/6th Generation Intel® Xeon®/ Core™ i7/i5/i3/ Pentium®/ Celeron® QC/ DC processors, up to 4GHz
System Memory 2x DDR4 SO-DIMM, Max. 32GB (Supports ECC by CPU SKUs)
System Chipset Intel® C236 / Q170 (MI991AF) / H110 PCH (MI991EF)
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16), 2x Mini PCI-E
VGA Controller 6th Generation Intel® Xeon® / Core™ i7 / i5 / i3 / Pentium® processor Integrated
VGA Memory Max. Shared memory – 1024MB
Display Interface Supports DVI-D, HDMI and DisplayPort
LAN Controller MI991AF: Intel® I219LM Gigabit LAN PHY
MI991EF: Intel® I219V Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN( as 2nd LAN)
LAN Connector RJ-45 on board
I/O Chipset Fintek F81846D-I
3x RS232, 1x RS232/422/485(Jumper-less selection),
4x SATAIII (MI991AF) or 3x SATAIII (MI991EF)
USB USB 3.0:
6 ports onboard (MI991AF), 4 ports onboard (MI991EF)
USB 2.0:
2 ports onboard (MI991EF), 2 ports via pin-header
Serial ATA
Audio Intel® C236/ Q170/ H110 PCH built-in HD audio + Realtek ALC662 codec
Others Digital I/O(4-in/4-out), EuP/ErP supporting, RAID, TPM(1.2), iAMT(11.0), iSMART
Dimensions 170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement Intel® Core™ I5-6500TE 2.3GHz
w/ 2x DDR4-2133 4GB
+12V: 3.56A; +5V: 1.28A; +5VSB: 0.08A; +3.3V: 0.32A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on IP413 (pdf file, opens in new tab)

MI990 Mini-ITX Motherboard w/ Intel® CM236 PCH


6th Generation Intel® Xeon® E3/ Core™ i7/i5/i3 & Celeron® Mini-ITX Motherboard w/ Intel® CM236 PCH
iBase Mini-ITX Motherboard - MI990
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI990

The MI990 Mini-ITX motherboard is based on the new 6th Gen Intel® Core™ processor family (codename Skylake) manufactured on Intel’s 14 nm manufacturing process. It offers accelerated processing performance and leading-edge graphics capability to simultaneously drive up to three independent displays with clear, crisp visuals without a discrete graphics card. With outstanding features that include up to 32GB of fast DDR4 DRAM memory in two SO-DIMM sockets, it is designed for high-end applications in industrial automation, kiosk, digital signage, medical and gaming markets.

MI990 integrates the Intel CM236 / HM170 chipset to deliver performance and to accommodate current I/O technologies for fast connectivity including 4x USB 2.0, 6x USB 3.0, 6x serial ports and 2x/4x SATA III, as well as flexible expansion with 1x PCI-E(x16), 2x Mini PCI-E and 1x M.2 slots. The board supports two Gigabit Ethernet ports and other advanced features, such as iAMT (11.0) for remote management and repair of systems, TPM (2.0) for improved systems integrity, vPro and IBASE’s owned iSMART (3.0) that enables energy-efficient systems with various power-saving functions.

There are four MI990 models available in MI990VF and MI990EF series with support for Intel CM236 and HM170 chipsets respectively. The four integrated processors list includes Intel Xeon E3-1505M v5, Intel Core i7-6820EQ, Intel Core i5-6440EQ and Intel Core i3-6100E.

Features:

  • Onboard 6th Generation Intel® Xeon® E3/ Core™ i7/i5/i3 / Celeron® QC/DC processors, up to 3.7GHz
  • 2x DDR4 SO-DIMM, Max. 32GB, ECC compatible
  • Intel® Processor integrated graphics device, supports DVI-D, HDMI (2.0), DisplayPort and 24-bit dual channel LVDS
  • 2x Intel® Gigabit LAN
  • 4x USB 2.0, 6x USB 3.0, 6x COM, 4x SATAIII
  • 1x PCI-E(x16), 2x Mini PCI-E, 1 x mSATA, 1x M.2
  • Watchdog timer, Digital I/O, iAMT (11.0), TPM (2.0), vPro, iSMART 3.0

Speifications:

CPU BGA1440 for 6th Generation Intel® Xeon® / Core™
i7/ i5/ i3 / Celeron® QC/ DC processors, up to 3.7GHz
System Memory 2x DDR4 SO-DIMM, Max. 32GB (Support ECC by CPU SKUs)
System Chipset Intel® CM236 / HM170 PCH
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA via MiniPCIe (Thru SATAIII)
1x M.2 slot (Thru SATA III & PCIe)
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16), 2x Mini PCI-E, 1x M.2
VGA Controller 6th Generation Intel® Xeon® / Core™ i7/ i5/ i3 / Celeron® processor integrated
VGA Memory Shared memory
Display Interface Supports DVI-D, HDMI (2.0), DisplayPort and
24-bit dual channel LVDS
LAN Controller MI990VF series: Intel® I219LM Gigabit LAN PHY
MI990EF series: Intel® I219V Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN (as 2nd LAN)
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81866AD-I
5x RS232
1x RS232/422/485(Jumper-less selection)
4x SATA III
USB 6 ports on board (USB 3.0)
4 ports via pin-header (USB 2.0)
Audio Intel® CM236 / HM170 PCH built-in HD audio + Realtek ALC892 codec
Others Digital I/O(4-in/4-out), RAID, TPM(2.0), iAMT(11.0), iSMART
Dimensions 170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement Intel® Core™ i5-6400EQ 2.4GHz w/2 x 8GB DDR4-2133
+12V : 2.84A ; +5V : 1.45A
+3.3V : 0.52A ; +5VSB : 0.058A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on MI990
 (pdf file, opens in new tab)

MI985 Mini-ITX Motherboard w/ Intel® QM87 PCH


5th Generation Intel® Core™ H Mini-ITX Motherboard w/ Intel® QM87 PCH
iBase Mini-ITX Motherboard - MI985
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI985

The MI985 Mini-ITX motherboard supports the 5th Generation Intel® Core™ processors (H-processor line) and Mobile Intel® QM87 Express Chipset that deliver industry-leading processing and graphics performance. Based on the Intel microarchitecture, the MI985 provides the processing power and advanced features such as Intel® Hyper-Threading Technology and Intel® Active Management Technology 9.0, power-management suitable for high-end applications in kiosk, medical, factory, industrial automation and control markets.

Powered by 5th Generation Intel® Core™ processors (H-processor line), the MI985 delivers exceptional performance and responsiveness. The latest Intel® HD Graphics GT2-530 allows MI985 to display stunning 3D videos and interactive media content from a range of onboard interfaces such as VGA, DVI, DisplayPort and LVDS/eDP.

The board has two SO-DIMM slots supporting up to 16GB of DDR3L memory. Expansion functionality is available with one PCI-E(x16) and two Mini-PCIe slots. In addition, there are two Gigabit LAN, six USB2.0, four USB 3.0, six COM, four SATA III and two SATA II ports supported. The MI985 also comes with advanced capabilities such as Trusted Platform Module 2.0 and IBASE’s iSMART green technology featuring EuP/ErP power saving and intelligent scheduler.

Features:

  • Onboard 5th Generation Intel® Core™ i7 QC processors
  • 2x DDR3L SO-DIMM, Max. 16GB
  • Integrated VGA, supports DVI-I/ DVI-D / LVDS/ DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O, TPM 2.0, iSMART 3.1
  • 6x USB 2.0, 4x USB 3.0, 6x COM, 4x SATA III, 2x SATA II
  • 1x PCI-E(x16), 2x Mini PCI-E(x1)

Speifications:

CPU BGA1364 for 5th generation Intel® mobile Core™ i7 QC processors
System Memory 2x DDR3L SO-DIMM, Max. 16GB (Non-ECC)
System Chipset Intel® QM87 PCH
BIOS AMI
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16), 2x Mini PCI-E(x1)
VGA Controller Intel® 5th generation Core™ i7 integrated graphics
supports CRT, DVI, DisplayPort, LVDS / eDP
VGA Memory Max. Shared memory – 1024MB
Display Interface Supports 24-bit dual channel LVDS/eDP
DVI-I, DVI-D, DisplayPort
LAN Controller Intel® I218LM PHY
Intel® I211AT PCI-E Gigabit LAN
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81866AD-I
5x RS232, 1x RS-232/422/485 (jumperless selection)
4x SATA III, 2x SATA II
USB 2 ports on board
4 ports via pin-header (USB 2.0)
4 ports on board (USB 3.0)
Audio Intel® QM87 PCH built-in HD audio controller+
ALC892 with 7.1 channels
Others Digital I/O (4-in/4-out), ATX power connector, iSMART
Dimensions 170mm x 170mm (6.7” x 6.7”)
Max. Power Requirement Intel® Core™ i7-5850EQ 2.70GHz w/ 4GB DDR3L-1600
+3.3V: 0.51A +5V: 0.83A
+5Vsb: 0.08A +12V: 3.37A
Operating Temperature 0°C~60°C ( 32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI985 (pdf file, opens in new tab)

MI987 Mini-ITX motherboard w/ Intel® Q87 PCH


4th Generation Intel® Core™ i7/i5/i3 Processor Mini-ITX motherboard w/ Intel® Q87 PCH
iBase Mini-ITX Motherboard - MI985
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI987

The MI987 Mini-ITX motherboard is based on the Q87 chipset designed to support socket LGA1150 4th Generation Intel® Core™ i7/i5/i3 desktop processors built on the latest 22nm process technology. The board offers leading-edge processing performance as well as an increase in graphics performance compared to its predecessors, making it quite suitable for demanding applications in the gaming, automation and digital signage markets.

The IBASE MI987 Mini-ITX motherboard is equipped with two DDR3-1600 SO-DIMM sockets to support up to 16GB of system memory and three types of graphics display interface, including VGA CRT, HDMI and DisplayPort. Alongside the display edge-connectors are one serial port, four USB ports, two Gigabit Ethernet ports, audio connectors and a 19V DC-in jack that eliminates the need for a bulky internal power supply and shrinks the volume of the system chassis.

With long-term availability, the MI987 comes with many great features, such as two 6Gb/s SATA III interface, two serial ports, watchdog timer, digital I/O, TPM 1.2 and iSMART. While TPM allows systems to run applications securely, iSMART provides EuP/ErP power saving and intelligent scheduler for better environmental performance. The MI987 is available in both the Intel Q87 and H81 versions.

Features:

  • 4th Generation Intel® Core™ i7/i5/i3 processor (maximum 45W TDP), up to 2.7GHz
  • 2x DDR3-1600 SO-DIMM, Max 16GB
  • Supports VGA,HDMI and DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • 4x USB3.0, 6x USB2.0, 2x COM, 2x SATA III
  • 2x Mini PCI-E slots, 2x mSATA , 1x PCI-E(4x)
  • Watchdog timer, Digital I/O, iAMT(9.0), TPM(1.2), iSMART

Speifications:

CPU LGA1150 for 4th Generation Intel® Core™ DT i7/i5/i3 processors (Max. 45W TDP)
System Memory 2x DDR3-1600 SO-DIMM, Max 16GB (Non-ECC)
System Chipset Intel® Q87/H81
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD 2x mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(4x) slot
2x Mini PCI-E (1x full-sized, 1x half-sized)
VGA Controller 4th Generation Intel® Core™ DT i7/i5/i3 processors integrated graphics
VGA Memory Max. Shared memory – 1024MB
Display Interface Support VGA, HDMI and DisplayPort
LAN Controller MI987AF: Intel® I217LM Gigabit LAN PHY
MI987EF: Intel® I217V Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN( as 2nd LAN)
LAN Connector 2x RJ45 with 4x USB 2.0 on board
I/O Chipset Nuvoton NCT5523D
1x RS-232/422/485 (Jumperless selection)
1x RS232, 2x SATA III
USB MI987AF:
4 ports USB3.0 on board
6 ports USB2.0 via pin header
MI987EF:
2 ports USB3.0 & 2 ports USB2.0 on board
4 ports USB2.0 via pin header
Audio Intel® Q87/H81 PCH built-in HD audio controller + Realtek ALC662 w/ 5.1 channels
Others 19V DC-In, Digital I/O, TPM 1.2, iSMART
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i7-4770TE 2.30 GHz
w/ 2x 2GB DDR3-1333
+19V: 6.08 A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI987 (pdf file, opens in new tab)

MI982 Mini-ITX Motherboard w/ Intel® H81 PCH


4th Generation Intel® Core™ i7/i5/i3/Pentium Processor Mini-ITX Motherboard w/ Intel® H81 PCH
iBase Mini-ITX Motherboard - MI982
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI982

Features:

  • 4th Generation Intel® Core™ i7/i5/i3 processor, up to 4.0GHz
  • 2x DDR3-1600 SO-DIMM, Max 16GB
  • Supports DVI-D, VGA and DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • 2x USB 3.0, 6x USB 2.0, 6x COM, 2x SATA III, 2x SATA II
  • 2x Mini PCI-E slots,1x PCI-E(16x)
  • Watchdog timer, Digital I/O, iSMART 3.0

Speifications:

CPU LGA1150 for 4th Generation Intel® Core™ DT i7/i5/i3/Pentium processors
System Memory 2x DDR3-1600 SO-DIMM, Max 16GB (Non-ECC)
System Chipset Intel® H81 PCH
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI-E(16x) slot
2x Mini PCI-E (1x full-sized, 1x half-sized)
VGA Controller 4th Generation Intel® Core™ DT i7/i5/i3/ Pentium
processors integrated graphics
VGA Memory Max. shared memory-1024MB
Display Interface Supports VGA, DVI-D and DisplayPort
LAN Controller Intel® I217LM Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN (as 2nd LAN)
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81866AD-I
1x RS-232/422/485 (jumperless selection)
5x RS232, 4x SATA III
USB 2 ports USB 3.0 on board
4 ports USB 2.0 on board
2 ports USB 2.0 via pin header
Audio Intel® H81 PCH built-in High Definition Audio controller
+ Realtek ALC892 with 7.1 channel
Others Digital I/O [4-in/4-out], iSMART 3.0, EuP/ErP
Dimensions 170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement Intel® Core™ i7-4770TE 2.3 GHz
w/ 2GB DDR3-1333
+3.3V: 0.46A +5V: 1.28A
+5Vsb: 0.23A +12V: 3.54A
Operating Temperature 0°C~60°C ( 32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on MI982
 (pdf file, opens in new tab)

MI981 Mini-ITX Motherboard w/ Intel® Q87 PCH


4th Generation Intel® Core™ i7/i5/i3/ Pentium® / Celeron®
Mini-ITX Motherboard w/ Intel® Q87 PCH
iBase Mini-ITX Motherboard - MI981
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI981

The MI981 Mini-ITX motherboard adopting the Intel® Q87 chipset and the new generation of Intel® Core™ processors. It is designed to provide high performance and flexibility for functional expansions, and is ideal for applications in industrial control, factory automation, communications and gaming industries.

By integrating the 4th Generation Intel® Core™ processors manufactured on 22nm process technology with 3-D tri-gate transistors, the MI981 provides more excellent computing and graphics performance and enhanced security over earlier platforms built with the 3rd Generation Intel® Core™ processors. High-end graphics capabilities can be experienced with the available display interfaces, including VGA CRT, DVI-D, LVDS and Display Port. TPM version 1.2 helps assure computer platform integrity and iAMT 9.1, when used with a software management application, allows remote system monitoring, upgrading and repairing.

IBASE’s MI981 supports two DDR3-1600 SO-DIMM memory slots for a maximum capacity of 16GB. It provides advanced and essential I/O connections such as six USB 3.0, six USB 2.0, six serial ports, four SATA III ports and two Gigabit Ethernets. Adding expansion cards is made possible by two Mini PCI-E, one mSATA and one PCI-E(16x) slots. Last but not least, the MI981 features IBASE’s iSMART green technology with intelligent scheduler and power savings that offers better environmental performance.

Features:

  • 4th Generation Intel® Core™ i7/i5/i3 Pentium® / Celeron® Processor, up to 4.0GHz
  • 2x DDR3-1600 SO-DIMM, Max 16GB
  • Supports DVI-D, VGA, LVDS and DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • 6x USB3.0, 6x USB2.0, 6x COM, 4x SATA III
  • 2x Mini PCI-E slots, 1x mSATA , 1x PCI-E(16x)
  • Watchdog timer, Digital I/O, iAMT(9.1), TPM(1.2), iSMART3.0

Speifications:

CPU 4th Generation Intel® Core™ DT i7/i5/i3 /Pentium®/ Celeron® processors
System Memory 2x DDR3-1600 SO-DIMM, Max 16GB (Non-ECC)
System Chipset Intel® Q87 PCH
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD 1x mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(16x) slot
2x Mini PCI-E (1x full-size, 1x half-size)
VGA Controller 4th Generation Intel® Core™ DT i7/i5/i3 processors integrated graphics
VGA Memory Max. Shared memory – 1024MB
Display Interface Supports VGA, DVI-D, LVDS and DisplayPort
LAN Controller Intel® I217LM Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN( as 2nd LAN)
LAN Connector 2x RJ45 on board
I/O Chipset Fintek F81866AD-I
1x RS-232/422/485 (Jumperless selection)
5x RS232, 4x SATA III
USB 6 ports USB3.0 on board
6 ports USB2.0 via pin header
Audio Intel® Q87 PCH built-in HD audio controller + Realtek ALC892 w/ 7.1 channels
Others Digital I/O [4-in/4-out], TPM 1.2, iAMT9.1, iSMART3.0
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i5-4570S 2.9GHz
2x Unigen DDR3-1333 2GB
+3.3V 0.76A
+5V 2.51A
+5Vsb 0.55A
+12V 6.29A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)

Data sheet on MI981 (pdf file, opens in new tab)

MI980 Mini-ITX Motherboard w/ Intel® QM87 PCH


4th Generation Intel® Core™ i7/i5/i3/Celeron®
Mini-ITX Motherboard w/ Intel® QM87 PCH
iBase Mini-ITX Motherboard - MI980
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI980

The MI980 Mini-ITX supports the 4th Generation Intel® Core™ i7/i5 processors. This motherboard is based on the mobile Intel® QM87 and HM86 Express chipsets that offer an increase in graphics and CPU performance over previous generations. The new board design was developed primarily for the industrial and embedded markets that require high processing capability, but at the same time are constrained by power limits.

The MI980 is equipped with two standard voltage or low-voltage DDR3 SO-DIMM sockets supporting up to 16GB of system memory. Video connections include DVI-I, DVI-D, LVDS/eDP and DisplayPort. To accommodate expansion cards, it also comes with one PCI Express x16 and two Mini PCI Express x1 slots (one for mSATA). Standard to this 170mm x 170mm platform are 6x USB 2.0, 4x USB 3.0, 6x COM (jumperless selection), 4x SATA III, 2x SATA II with the latest Intel-based dual Gigabit LAN support, which allow comprehensive peripheral and networking features. The MI980VF is also available with advanced capabilities such as Intel® Active Management Technology 9.0, Trusted Platform Module 1.2, RAID and state-of-the-art Intel® vPro™ technology.

Features:

  • Onboard 4th Generation Intel® Core™ i7/i5/i3 / Celeron® QC / DC processors
  • 2x DDR3/DDR3L SO-DIMM, Max. 16GB
  • Integrated VGA, supports DVI-I/ DVI-D/ LVDS or eDP/ DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O, iAMT (9.0), vPro, iSMART
  • 6x USB 2.0, 4x USB 3.0, 6x COM, 4x SATA III, 2x SATA II
  • 1x PCI-E(x16), 2x Mini PCI-E(x1)

Speifications:

CPU BGA1364 for 4th generation Intel® mobile Core™ i7/i5/i3/ Celeron® QC/ DC processors
System Memory 2x DDR3/DDR3L SO-DIMM, Max. 16GB (Non-ECC)
System Chipset MI980VF Series: Intel® QM87 PCH
MI980F: Intel® HM86 PCH
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA via Mini PCI-E (Thru SATA III)
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16), 2x Mini PCI-E(x1)
VGA Controller 4th Generation Intel® Core™ i7/i5/i3 / Celeron® integrated graphics, supports CRT, DVI, DisplayPort, LVDS / eDP
VGA Memory Max. Shared memory – 1024MB
Display Interface Supports 24-bit dual channel LVDS/eDP, DVI-I, DVI-D, DisplayPort
LAN Controller MI980VF Series: Intel® I217LM Gigabit LAN PHY
MI980F: Intel® I217V Gigabit LAN PHY
Intel® I211AT PCI-E Gigabit LAN (as 2nd LAN)
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81866AD-I
1x RS-232/422/485 (jumperless selection)
5x RS232
MI980VF Series: 4x SATA III, 2x SATA II
MI980F: 2x SATA III, 2x SATA II
USB 2 ports on board, 4 ports via pin-header (USB 2.0)
4 ports on board (USB 3.0)
Audio Intel® QM87 / HM86 PCH built-in HD audio controller + ALC892 w/ 7.1 channels
Others Digital I/O (4-in/4-out), ATX power connector, iSMART support
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i5-4402E 1.60 GHz
w/ 2x 2GB DDR3-1333
+3.3V: 0.29 A +5V: 0.73 A
+5Vsb: 1.70 A +12V: 2.01 A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on MI980
 (pdf file, opens in new tab)

MI970 Mini-ITX Motherboard w/ Intel® QM77 PCH


3rd Generation Intel® Core™ i7/i5/i3/Celeron® Mini-ITX Motherboard w/ Intel® QM77 PCH
iBase Mini-ITX Motherboard - MI970
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI970

The MI970 Mini-ITX motherboard is based on the Intel QM77 Express Chipset, providing support for both the 3rd and 2nd generation Intel® Coreä processor families. The board is suitable for a wide range of applications such as gaming, medical, industrial automation, kiosk, digital signage and ATM machines.

Equipped with the latest mobile Intel Chipset QM77 chipset, the MI970 takes advantage of the hardware-assisted security and manageability features integrated in the chipset, such as Intel AMT 8.0, TPM 1.2 and Intel vPro. These features enable professionals to quickly troubleshoot and repair systems remotely, as well as remotely power on/off devices to reduce energy consumption. Its iSMART technology improves environmental performance by allowing start/shutdown scheduling and power resume to make systems more energy efficient.

MI970 has two DDR3 SO-DIMM sockets to support up to 16GB of system memory. Four display interfaces provided include DVI-I, DVI-D, DisplayPort and 24-bit dual channel LVDS. It features advanced technologies including USB 3.0 and SATA III connectivity to deliver unprecedented performance and speed. Expansion is available with one PCI-E(x16) and two Mini PCI-E(x1) slots. Dimensions are 170mm by 170mm.

Features:

  • Supports 3rd Generation Intel® Core™ i7/i5/i3 / Celeron® QC/DC processors
  • 2x DDR3 SO-DIMM, Max. 16GB
  • iSMART – for EuP/ErP power saving, auto-scheduler and power resume
  • Integrated VGA, supports DVI-I/ DVI-D/ LVDS/ DisplayPort
  • 2x Intel® PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O, TPM 1.2
  • 6x USB 2.0, 4x USB 3.0, 4x COM, 4x SATA II, 2x SATA III
  • 1x PCI-E(x16), 2x Mini PCI-E(x1)

Speifications:

CPU rPGA988B for 3rd Generation Intel® mobile Core™ i7/i5/i3 / Celeron® QC/ DC processors
System Memory 2x DDR3 SO-DIMM, Max. 16GB (Non-ECC)
System Chipset Intel® QM77 PCH (MI970VF) / HM76 PCH (MI970F)
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA via Mini PCI-E (Full-Size)
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16)
2x Mini PCI-E(x1) – w/ USB signal (1x half-size, 1x full-size)
VGA Controller Intel® Core™ i7/i5/i3 / Celeron® integrated graphics, supports CRT, DVI, DisplayPort, LVDS
VGA Memory Max. Shared memory – 1024MB
Display Interface Supports 24-bit dual channel LVDS, DVI-I, DVI-D, DisplayPort
LAN Controller Intel® 82579LM(MI970VF) / 82579V(MI970F) Gigabit LAN PHY,
Intel® 82583V PCI-E Gigabit LAN
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81846AD-I
3x RS232, 1x RS-232/422/485, 4x SATA II,
2x SATA III
USB 4 ports on board, 2 ports via pin-header (USB 2.0)
2 ports on board, 2 ports via pin-header (USB3.0)
Audio Intel® QM77/HM76 PCH built-in HD audio controller+ ALC892 w/ 7.1 channels
Others Digital I/O (4-in/4-out), ATX power connector, iSMART support
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement 3rd Generation Intel® Core™ i3-3120ME 2.40GHz
w/ 2x 2GB DDR3-1333
+3.3V: 0.79A +5V: 1.27A
+12V: 2.10A +5Vsb: 0.06A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI970 (pdf file, opens in new tab)

MI963 Mini-ITX Motherboard


AMD Embedded G-Series SoC Mini-ITX Motherboard
iBase Mini-ITX Motherboard - MI963
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI963

Features:

  • Onboard AMD Embedded G-Series GX-424CC SoC, 2.4GHz
  • 2x DDR3 DIMM, Max. 8GB
  • Supports 2x HDMI
  • 2x Intel® PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O
  • 6x USB 2.0, 2x USB 3.0, 4x COM, 2x SATA III
  • 1x PCI-E(x8) [(x4) Link]

Speifications:

CPU AMD Embedded G-Series GX-424CC SoC (2.4GHz)
System Memory 2x DDR3 DIMM, Max. 8GB (ECC compatible )
System Chipset Integrated
BIOS AMI
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI-E(x8)[(x4) Link]
1x PCI-E(x1)
VGA Controller AMD Embedded G-series SoC built-in GPU
( AMD Radeon™ HD8000 series)
VGA Memory N/A
Display Interface Supports 2x HDMI
LAN Controller 2x Intel® I211AT PCI-E Gigabit LAN
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81846AD-I
3x RS232, 1x RS232/422/485 (jumperless selection)
2x SATA III
USB 4 ports onboard, 2 ports via pin-header (USB 2.0)
2 ports onboard (USB 3.0)
Audio AMD Embedded G-series SoC built-in audio controller w/ Realtek ALC662QHD codec
Extra 3W + 3W amplifier
Others Digital I/O (4-in/4-out), ATX power connector
Dimensions 170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement AMD GX-424CC 2.4GHz
w/ 2x DDR3L-1600 8G
+12V: 1.56A; +5V: 1.75A; +5VSB: 0.13A; +3.3V: 0.23A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI963 (pdf file, opens in new tab)

MI961 Mini-ITX Motherboard w/ Intel® H61 PCH


LGA1155 2nd/3rd Generation Intel® Core™ i7/i5/i3 / Pentium® / Celeron® Mini-ITX Motherboard w/ Intel® H61 PCH
iBase Mini-ITX Motherboard - MI961
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI961

Features:

  • Supports 2nd/3rd Generation Intel® Core™ i7/i5/i3 / Pentium® / Celeron® processors, up to 3.4GHz
  • 2x DDR3 DIMM, Max. 16GB
  • iSMART – for EuP/ErP power saving, auto-scheduler and power resume
  • Intel® processor integrated graphics, supports HDMI, DVI-D and VGA
  • Dual Gigabit LAN
  • 8x USB 2.0, 2x USB 3.0, 4x COM, 3x SATA II
  • 1x PCI-E(x16), 1x Mini PCI-E(x1)
  • Watchdog timer, Digital I/O

Speifications:

CPU LGA1155 for 2nd/3rd Generation Intel® Core™ i7/i5/i3/ Pentium®/ Celeron® processors, up to 3.4GHz
System Memory 2x DDR3 DIMM, Max. 16GB (Non-ECC)
System Chipset Intel® H61 PCH
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD 1x mSATA via Mini PCI-E
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16)
1x Mini PCI-E(x1) – w/ USB signal (full-size)
VGA Controller Intel® Core™ i7/i5/i3/ Pentium®/ Celeron® processors integrated
VGA Memory Max. Shared Memory – 1024 MB
Display Interface Supports HDMI, DVI-D and VGA
LAN Controller 2x Realtek RTL8111E Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Fintek F81846AD-I
3x RS232, 1x RS232/422/485, 3x SATA II
USB 4 ports on board, 4 ports via pin-header (USB 2.0)
2 ports on board (USB 3.0)
Audio Intel® H61 PCH built-in HD audio + Realtek ALC892 codec
Others Digital I/O(4-in/4-out), iSMART
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i7-2600 3.40GHz
w/ 2x 2GB DDR3-1333
+3.3V: 1.18A +5V: 2.37A
+12V: 1.29A +5Vsb: 0.39A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on
 MI961
 (pdf file, opens in new tab)

MI956 Mini-ITX Motherboard w/ Intel® QM67 PCH


rPGA988B 2nd/3rd Generation Intel® Core™ i7/i5/i3/ Celeron® Mini-ITX Motherboard w/ Intel® QM67 PCH
iBase Mini-ITX Motherboard - MI956
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI956

The MI956F Mini-ITX motherboard is based on the latest Intel® QM67 Express chipset. The platform supports the 2nd generation Intel® Core processor family with rPGA988B packing and features an integrated dual-channel DDR3 memory controller as well as a graphics core. It meets the requirement in the gaming, POS, digital signage and server market segment.

Measuring 170mm x 170mm, the MI956F offers fast 6Gbps SATA support (2 ports), USB 3.0 (2 ports) functionality and interfaces for DVI-D, DVI-I, LVDS and HDMI displays. Another board model, MI956AF, features Intel Active Management Technology 7.0.

Features:

  • Supports 2nd/3rd Generation Intel® Core™ i7/i5/i3 / Celeron® QC/DC processors, up to 2.7GHz
  • 2x DDR3 SO-DIMM, Max. 16GB
  • Integrated VGA, supports DVI-I/DVI-D/LVDS/HDMI
  • Dual Gigabit LAN
  • 8x USB 2.0, 2x USB 3.0, 4x COM, 4x SATA II, 2x SATA III
  • 1x PCI-E(x16), 1x Mini PCI-E(x1)
  • Watchdog timer, Digital I/O

Speifications:

CPU rPGA988B for 2nd/3rdGeneration Intel® Core™ i7/i5/i3/ Celeron® QC/ DC processors, up to 2.7GHz
System Memory 2x DDR3 SO-DIMM, Max. 16GB (Non-ECC)
System Chipset Intel® QM67 PCH
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI-E(x16), 1x Mini PCI-E(x1)
VGA Controller Intel® Core™ i7/i5/i3/ Celeron® processors integrated graphics Gen 5.75
VGA Memory Max. Shared Memory – 1024 MB
Display Interface Supports 24-bit dual channel LVDS, DVI-I, DVI-D, HDMI (supports HDCP)
LAN Controller MI956AF: Intel® 82579LM
MI956F: Intel® 82579VGigabit LAN PHY
Intel® 82583V PCI-E Gigabit LAN
LAN Connector 2x RJ-45 on board
I/O Chipset Fintek F81865-I
3x RS232, 1x RS-232/422/485, 4x SATA II,
2x SATA III
USB 4 ports on board, 4 ports via pin-header (USB 2.0)
2 ports on board (USB 3.0)
Audio Intel® QM67 built-in HD audio w/ Realtek ALC892 for 7.1 CH
Others Digital I/O (4-in/4-out), ATX power connector,
EuP/ErP compliant
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i5-2510E 2.5GHz
w/ 2x 2GB DDR3-1333
+3.3V: 1.33A +5V: 0.97A
+12V: 2.18A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI956 (pdf file, opens in new tab)

MI957 Mini-ITX Motherboard w/ Intel® QM57 PCH


BGA1288 Intel® Core™ i7/i3 Mini-ITX Motherboard w/ Intel® QM57 PCH
iBase Mini-ITX Motherboard - MI957
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI957

The Intel® Core™ i7-610E processor-based MI957 Mini-ITX motherboard supports the mobile Intel® QM57 Express Chipset. MI957 is designed for applications requiring high-level processing and graphics performance with a long product life such as those in digital signage, gaming, POS, kiosk and multimedia sectors.

With the 2.53GHz Core™ i7-610E integrated graphics, the MI957 platform offers dual independent display and comes with a wide array of display outputs including CRT, DVI-D, HDMI, 18/24-bit LVDS and Display Port. Integrated graphics support includes features such as DirectX 10, OpenGL 2.1, and Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0). With two DIMM slots, it supports a maximum of 8GB of ECC DDR3 memory.

Aside from the video ports at the board’s edge, the MI957 motherboard has a single Gigabit Ethernet port, audio and eight USB ports onboard. Other connectivity and expansion features include four COM ports, four SATA II (RAID 0,1) ports, a Mini PCI-E, a PCI-E and a PCI slot. MI957 also comes available with the Intel® Core™ i3-330E 2.13GHz processor.

Features:

  • Onboard Intel® Core™ i7-610E / i3-330E processor, up to 2.53GHz
  • 2x DDR3 DIMM, Max. 8GB, supports ECC
  • Supports CRT, DVI-D, HDMI, LVDS and DisplayPort
  • Intel® 82577LM Gigabit PHY
  • 4x SATA II (RAID 0,1), 12x USB 2.0, 4x COM
  • 1x Mini PCI-E, 1x PCI-E(x1), 1x PCI

Speifications:

CPU Intel® Core™ i7-610E 2.53GHz
Intel® Core™ i3-330E 2.16GHz
System Memory 2x DDR3 DIMM, 800/1066MHz, Max. 8GB, supports ECC
System Chipset Intel® QM57 PCH
BIOS AMI
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI, 1x PCI-E (x1), 1x Mini PCI-E
VGA Controller Intel® Core™ i7-610E / i3-330E integrated
VGA Memory Max. shared memory – 352MB
Display Interface Onboard CRT, DVI-D & 24-bit single channel LVDS, HDMI,
DisplayPort
LAN Controller Intel® 82577LM Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Fintek F81865-I
1x KB, 1x mouse, 1x LPT,
3x RS-232, 1x RS-232/422/485, 4x SATA II
USB 4 ports on board
Pin header for 8 ports (USB 2.0)
Audio Intel® QM57 built-in audio w/ Realtek ALC888 codec for 5.1CH
Others Digital I/O (4-in/4-out), +12V DC In
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i5-540 2.52MHz
w/ 2x 1GB DDR3-1333
+12V: 4.24A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI957 (pdf file, opens in new tab)

MI953 Mini-ITX Motherboard w/ Intel® QM57/HM55 PCH


rPGA988 Intel® Core™ i7/i5/i3 / Celeron® Mini-ITX Motherboard w/ Intel® QM57/HM55 PCH
iBase Mini-ITX Motherboard - MI953
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI953

The Intel® QM57-based MI953 Mini-ITX motherboard is designed for multimedia, gaming, POS, kiosk and demanding applications requiring reliable performance. MI953 supports Intel® Core™ i7 and Core™ i5 processors and a maximum of 8GB of non ECC unbuffered DDR3 memory – with DDR3 pegged at 800 and 1066 MHz speeds.

Equipped with Intel® Turbo Boost technology and Intel® Hyper-Threading technology and built on new Intel 32nm process technology, Intel Core i7 and Core i5 processors provide users with reliable performance and power efficiency. The Intel QM57 Express chipset built to accompany on-package graphics processors, enables the IBASE MI953 platform to offer a wide array of display interface connections encompassing VGA CRT, DVI-I, DVI-D and 24-bit dual channel LVDS that will suit your display output requirement.

The 170mm x 170mm MI953 motherboard has all of the essential connectivity features such as ten USB 2.0 ports, four COM ports, four SATA II ports and dual Gigabit Ethernet connections, while expansion slots on board include Mini PCI-E, PCI-E and PCI. The built-in high definition 7.1-channel audio is aided by a Realtek ALC888 codec.

Features:

  • Supports Intel® Core™ i7/i5/i3/ Celeron® 32nm processors
  • 2x DDR3 SO-DIMM (w/o ECC), Max. 8GB
  • Supports CRT, LVDS and dual DVI-D (dual display)
  • 2x Gigabit LAN
  • 4x SATA II, 10x USB 2.0, 4x COM
  • 1x Mini PCI-E, 1x PCI-E(x1), 1x PCI
  • RAID, Optional AMT

Speifications:

CPU rPGA988 for Intel® Core™ i7/i5/i3/ Celeron® processors
System Memory 2x DDR3 SO-DIMM, Max. 8GB
System Chipset Intel® QM57/HM55 PCH
BIOS AMI
Watchdog Timer 256 levels
SSD N/A
H/W Monitor Yes
Expansion Slots 1x PCI, 1x PCI-E (x1), 1x Mini PCI-E (x1)
VGA Controller Intel® Core™ i7 / i5 / i3 / Celeron® integrated
VGA Memory Max. shared memory – 352MB
Display Interface Supports CRT, 2x DVI-D & 24-bit dual channel LVDS
LAN Controller Intel® 82577LM Gigabit LAN
Intel® 82574L PCI-E Gigabit LAN
LAN Connector Dual RJ-45 on board
I/O Chipset Fintek F81865-I
1x Keyboard, 1x mouse,
3x RS232, 1x RS-232/422/485, 4x SATA II (3.0Gb/sec.)
USB 6 ports on board
Pin header for 4 ports (USB 2.0)
Audio Built-in HD audio w/ Realtek ALC892 codec for 7.1CH
Others Digital I/O (4-in/4-out)
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Core™ i5-520M 2.4GHz w/ 2x 2GB DDR3-1066
+12V: 2.03A
+5V: 4.53A
+3.3V: 1.14A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on
 MI953
 (pdf file, opens in new tab)

MI811 Mini-ITX Motherboard


Intel® Pentium® / Celeron® SoC Mini-ITX Motherboard
iBase Mini-ITX Motherboard - MI811
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI811

The MI811 Mini-ITX Motherboard comes built in with the Intel® 2.5GHz Pentium® QC N4200 or Celeron® DC N3350 processors, both belonging to the formerly Apollo Lake processor family and using the Goldmont microarchitecture for low-power Intel SoCs. The board has two memory sockets to support DDR3L-1866 SO-DIMM modules with a total capacity of 8GB.

The versatile MI811 takes advantage of the latest SoC integrated with Intel® Gen9 featuring seamless Ultra HD graphics, with three display outputs including an HDMI, 2nd HDMI or DVI-D, and eDP or 24-bit dual channel LVDS. In compliance with EuP/ErP standards, the MI811 supports power failure detection and 4K UHD resolution.

Measuring 170mm by 170mm, the MI811 is populated with two Intel I211-AT PCI-E Gigabit Ethernet and four COM ports. Other essential interfaces include four USB 3.0, four USB 2.0, and two SATA III, while expandability comes in the form of one PCI-E(1x), one Mini PCI-E and one mSATA. The board is designed to accept a wide-range of DC power input from 12V to 24V, making it suitable for use in POS, kiosk and industrial automation applications.

With two processors, Pentium N4200 and Celeron N3350, to choose from, buyers can opt between ATX or 12V~24V power.

Features:

  • Intel® Pentium® QC N4200 @ 2.5GHz or Celeron® DC N3350 @ 2.4GHz on board
  • 2x DDR3L SO-DIMM socket, Max. 8GB
  • Supports HDMI, HDMI / DVI-D and eDP / 24-bit dual channel LVDS
  • 2x Intel® I211-AT PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O
  • 4x USB 3.0, 4x USB 2.0, 4x COM, 2x SATA III
  • 1x PCI-E(1x), 1x Mini PCI-E, 1x mSATA

Speifications:

CPU Intel® Pentium® QC N4200 @ 1.1GHz ~ 2.5GHz
Intel® Celeron® DC N3350 @ 1.1GHz ~ 2.4GHz
System Memory DDR3L-1866 SO-DIMM socket, Max. 8GB
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(1x), 1x Mini PCI-E
VGA Controller Intel® Pentium® SoC integrated Intel® Gen 9 graphics
VGA Memory Shared memory
Display Interface Supports HDMI, 2nd HDMI or DVI-D, eDP or 24-bit dual channel LVDS
LAN Controller Intel® I211AT PCI-E Gigabit LAN
LAN Connector RJ-45 onboard
I/O Chipset Fintek F81846AD-I
1x RS232/422/485(Jumperless selection), 3x RS232,
USB 4 ports onboard (USB 3.0)
2 ports onboard + 2 ports via pin-header (USB 2.0)
Serial ATA 2x SATA III
Audio Intel® Pentium® SoC built-in High Definition Audio controller + Realtek ALC283 w/ 2.1 channels+ amplifier
Others Digital I/O (4-in/4-out); ATX or 12V~24V DC-in; EuP/ErP
Dimensions 170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement TBD
Operating Temperature 0°C~60°C ( 32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI811 (pdf file, opens in new tab)

MI808 Mini-ITX Motherboard


Intel® Pentium® / Celeron® SoC Mini-ITX Motherboard
iBase Mini-ITX Motherboard - MI808
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI808

The MI808 is a Mini-ITX Motherboard to support DC power input. The board can be powered by a 2.4GHz Intel® Pentium® N3710 or 2.08GHz Celeron® N3010 processor and is paired with two DDR3L SO-DIMM sockets that accept up to 8GB of memory. With a DC-power input design, it is scalable to adapt to various applications in transportation, mobile, POS and industrial automation markets.

Measuring 170mm x 170mm, the MI808 provides expansion with one PCI-E(x1) and one Mini PCI-E slots. Display interfaces supported are DVI, VGA and 24-bit dual-channel LVDS. Network connectivity and I/Os come in the form of two Gigabit Ethernets, four COM, one LPC, two SATA III, four USB 3.0, two USB 2.0 and one mSATA for SSD devices. Other important features include digital I/O, iSMART power-saving technology, TPM (2.0) and a SIM card slot.

The MI808 is currently available in four models that differ in the processor type and the DC-in value, which is 12V or 18V~24V.

Features:

  • Onboard Intel® Pentium® QC N3710, up to 2.56GHz or Celeron® DC N3010, up to 2.24GHz
  • 2x DDR3L SO-DIMM sockets, Max. 8GB
  • Supports VGA, DVI-D and 24-bit dual channel LVDS
  • 2x Intel® I211-AT PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O, iSMART, TPM (2.0)
  • 4x USB 3.0, 2x USB 2.0, 4x COM, 2x SATA III
  • 1x PCI-E(1x), 1x Mini PCI-E, 1x mSATA, 1x CFast

Speifications:

CPU Intel® Pentium® N3710, up to 2.4GHz or Celeron® N3010, up to 2.24GHz
System Memory 2x DDR3L-1600 SO-DIMM socket, Max. 8GB
System Chipset N/A
BIOS AMI BIOS
Watchdog Timer 256 levels
SSD 1x mSATA, 1x CFast (optional)
H/W Monitor Yes
Expansion Slots 1x PCIe(x1), 1x Mini PCI-E
VGA Controller Intel® Pentium® SoC integrated
Intel® Gen 8 graphics
VGA Memory Shared memory
Display Interface Supports DVI-D , CRT
24-bit dual channel LVDS
LAN Controller Intel® I211AT PCI-E Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Fintek F81846AD-I
1x RS-232/422/485 (jumperless selection)
3x RS232, PS/2 keyboard/mouse
1x printer port
2x SATA III
USB 4 ports on board (USB 3.0)
2 ports via pin-header (USB 2.0)
Audio Intel® Pentium SoC built-in HD audio controller + Realtek ALC269 with 2.1 channels + amplifier
Others Digital I/O (4-in/4-out); 12V DC-in or 18V~24V; iSMART 3.2; TPM(2.0); SIM card slot, CFast (optional)
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Pentium® Processor N3700 1.6 GHz
w/ 2x 4GB DDR3L-1600
+19V: 1.01A
Operating Temperature 0°C~60°C ( 32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI808 (pdf file, opens in new tab)

MI805 Mini-ITX Motherboard


Intel® Celeron® J1900 SoC Mini-ITX Motherboard
iBase Mini-ITX Motherboard - MI805
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI805

The MI805 Mini ITX Motherboard comes on board with the Intel® Celeron® J1900 quad-core processor with a clock speed of 2.0GHz. The board has two memory sockets to support DDR3L SO-DIMM modules with a total capacity of 8GB.

The versatile and low-power consumption MI805 motherboard is designed to accept a wide-range of DC power input from 9V to 30V. This feature makes it highly suitable for in-vehicle applications. With the advanced Intel® Gen7 graphics engine, MI805 delivers smooth video performance with triple display functionality including CRT, DVD-D and 24-bit dual channel LVDS.

Meeting EuP/ErP compliance, the MI805 features the remarkable iSMART software that allows power failure detection, auto scheduling, low temperature monitoring, as well as intelligent firmware update in the BIOS to improve the overall environmental performance.
In terms of connectivity, the MI805 provides a DC jack, two serial ports, CRT and DVD-D, two RJ45, three USB 2.0, one USB 3.0 and audio connectors in the rear. The board carries a total of six serial ports, seven USB 2.0 ports and two SATA II connectors. Expansion comes in the form of two Mini PCIe and a PCIe(x1) slot. Dimensions are 170mm by 170mm.

Features:

  • Onboard Intel® Celeron® J1900(2.0GHz) SoC
  • 2x DDR3L SO-DIMM, Max. 8GB
  • Supports VGA, DVI-D and 24-bit dual channel LVDS
  • Onboard dual PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O, iSMART
  • 1x USB 3.0, 4x USB 2.0, 6x COM, 2x SATA II
  • 1x PCI-E(1x), 1x Mini PCI-E, 1x mSATA

Speifications:

CPU Intel® Celeron® J1900 SoC (2.0GHz, 2MB cache)
System Memory 2x DDR3L-1333 SO-DIMM, Max. 8GB(Non-ECC)
System Chipset N/A
BIOS AMI
Watchdog Timer 256 levels
SSD mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(1x), 1x Mini PCI-E
VGA Controller Intel® Celeron® J1900 integrated Gen7 graphics
VGA Memory Max. shared memory – 224MB
Display Interface Supports DVI-D, CRT 24-bit dual channel LVDS
LAN Controller Intel® I211AT PCI-E Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Nuvoton NCT6106D
1x RS232/422/485 , 5x RS232, 2x SATA II
USB 1 port USB 3.0 on board
2 ports USB 2.0 on board
2 ports USB 2.0 via pin-header
Audio Intel® Celeron® J1900 built-in audio w/ Realtek ALC269 codec
Others 12V~24V DC-In, iSMART, Digital I/O (4-in/4-out)
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Celeron® J1900 2GHz w/ 8GB DDR3L-1600
+12V: 1.28A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on
 MI805
 (pdf file, opens in new tab)

MI802 Mini-ITX Motherboard w/ Intel® NM10 Chipset


Intel® Atom™ D2550/N2600 Mini-ITX Motherboard
w/ Intel® NM10 Chipset
iBase Mini-ITX Motherboard - MI802
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI802

The MI802/MI802N Mini-ITX motherboard integrates with the Intel® Atom™ Processor D2550/N2600 (1.86GHz/1.6GHz) and Intel® CG82NM10 PCH chipset. Featuring six serial ports, it provides seamless performance for a wide range of applications in factory automation, POS, kiosk, ATM and medical field. As an energy-efficient platform, the MI802/MI802 offers low power consumption and iSMART technology with EuP/ErP power saving and start/shutdown scheduling functions.

The IBASE MI802/MI802N comes with two/one SO-DIMM socket supporting 2GB memory per socket. Display interface includes a DVI-D/VGA and 18/24-bit dual channel LVDS connectors. The boards comes with complete I/O options, including six serial ports, two Gigabit LAN, two SATA II, seven USB and audio. Expansion is possible with the onboard PCI and two mini PCI-E sockets.

Features:

  • Onboard Intel® Atom™ D2550(1.86GHz) or Atom™ N2600 (1.6GHz) processor
  • 2x DDR3 SO-DIMM, Max. 4GB
  • iSMART – auto-scheduler and power resume
  • EuP/ErP power saving
  • Supports DVI-D / VGA and 24-bit dual channel LVDS
  • Onboard dual PCI-E Gigabit LAN
  • Watchdog timer, Digital I/O
  • 7x USB 2.0, 6x COM, 2x SATA II
  • 1x PCI, 2x Mini PCI-E, 12V~24V DC-in

Speifications:

CPU Intel® Celeron® J1900 SoC (2.0GHz, 2MB cache)
System Memory 2x DDR3L-1333 SO-DIMM, Max. 8GB(Non-ECC)
System Chipset N/A
BIOS AMI
Watchdog Timer 256 levels
SSD mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E(1x), 1x Mini PCI-E
VGA Controller Intel® Celeron® J1900 integrated Gen7 graphics
VGA Memory Max. shared memory – 224MB
Display Interface Supports DVI-D, CRT 24-bit dual channel LVDS
LAN Controller Intel® I211AT PCI-E Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Nuvoton NCT6106D
1x RS232/422/485 , 5x RS232, 2x SATA II
USB 1 port USB 3.0 on board
2 ports USB 2.0 on board
2 ports USB 2.0 via pin-header
Audio Intel® Celeron® J1900 built-in audio w/ Realtek ALC269 codec
Others 12V~24V DC-In, iSMART, Digital I/O (4-in/4-out)
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement Intel® Celeron® J1900 2GHz w/ 8GB DDR3L-1600
+12V: 1.28A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)


Data sheet on
 MI802
 (pdf file, opens in new tab)

MI977 Mini-ITX Motherboard with AMD A77E FCH


AMD 2nd Generation R-series Mini-ITX Motherboard with AMD A77E FCH
iBase Mini-ITX Motherboard - MI977
Click here to show/ hide more info

iBase Mini-ITX Motherboard - MI977

Features:

  • Supports AMD 2nd Generation R-series APU on board, up to 2.7GHz
  • 2x DDRIII SO-DIMM, Max. 32GB
  • 3x PCI-E Gigabit LAN
  • DVI-I, DisplayPort & 24-bit dual channel LVDS
  • Watchdog timer, Digital I/O, iSMART 3.1, RAID
  • 5x SATA III, 4x USB 3.0, 8x USB 2.0, 6 x COM, 1x mSATA
  • 1x PCI-E(x16), 2 x Mini PCI-E
  • 1x SIM card slot

Speifications:

CPU AMD 2nd Generation R-series APU on board,
up to 2.7GHz
System Memory 2x DDR3 SO-DIMM, Max. 32GB
System Chipset AMD A77E FCH
BIOS AMI
Watchdog Timer 256 levels
SSD 1x mSATA
H/W Monitor Yes
Expansion Slots 1x PCI-E (X16), 2x Mini PCI-E
VGA Controller AMD A77E built-in Radeon HD9000 series graphic core
VGA Memory Shared memory
Display Interface DVI-I, DisplayPort & 24-bit dual channel LVDS
LAN Controller 3x Realtek 8111G Gigabit LAN
LAN Connector RJ-45 on board
I/O Chipset Fintek F81866AD-I
1x RS232/422/485( jumperless selection)
5x RS232, 5x SATA III (6.0Gb/sec.)
USB 4 ports (USB3.0) + 2 ports (USB2.0) on board
6 ports via pin header (USB 2.0)
Audio Built-in HD audio with ALC662 codec for 5.1 CH
Others Digital I/O (4-in/4-out), RAID, iSMART 3.1, SIM Card Slot
Dimensions 170mm x 170mm (6.7″ x 6.7″)
Max. Power Requirement AMD RX427 APU 2.70GHz 2GB DDR3-1333
+3.3V: 1.02A +5V: 1.88A
+12V: 1.08A
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)

Data sheet on MI977 (pdf file, opens in new tab)

Advantech Mini-ITX Motherboards – Industrial Grade

AIMB-205 Mini-ITX Motherboard


6th & 7th Gen Intel® Core™ i7/i5/i3 LGA 1151 Mini-ITX with H110, DP/DVI/VGA, 8 COM, 4 USB3.0, 6 USB2.0, Dual GbE LAN, PCIe x 16, mini PCIE, M.2, DDR4, ATX Input
Advantech Mini-ITX Motherboards - AIMB-205
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-205

Features:

  • Supports Intel® 6th & 7th Gen Core™ i processor (LGA1151) with Intel H110 chipset
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Supports PCIe x 16 (Gen 3), 1 F/S miniPCIe, 1 M.2 2242 , 4 USB 3.0, 6 USB2.0 and 2 SATA III
  • Supports dual display of DP/DVI/VGA/LVDS(optional)
  • Supports TPM 1.2 / 2.0 (optional)

Data sheet on AIMB-205 (pdf file, opens in new tab)

AIMB-275 Mini-ITX Motherboard


7th & 6th Gen Intel® Core™ i7/i5/i3 LGA 1151 Mini-ITX with Q170/H110, VGA/DP++/HDMI/LVDS, 2 COM, Dual LAN, PCIe x16, M.2, DDR4, DC Input
Advantech Mini-ITX Motherboards - AIMB-275
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-275

Features:

  • Supports Intel® 7th & 6th Gen Core™ i processor (LGA1151) with Intel Q170/H110 chipset
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Supports triple display of VGA/DP/HDMI/LVDS(eDP)
  • Supports PCIe x16 (Gen 3), 1 F/S miniPCIe 1 M.2 (NGFF), 6 USB 3.0 and 3 SATA III
  • Support wide range 12V~24V DC Input
  • Supports Intel vPro, AMT 11.0, PECI 3.0, Software RAID 0,1,5,10, TPM 1.2 / 2.0 (optional)
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-275 (pdf file, opens in new tab)

AIMB-285 Mini-ITX Motherboard


7th & 6th Gen Intel® Core™ i7/i5/i3 LGA 1151 Mini-ITX with H110, DP/HDMI/VGA, 2 COM, 4 USB3.0, Dual GbE LAN, PCIe x 4, mini PCIE, DDR4, DC Input
Advantech Mini-ITX Motherboards - AIMB-285
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-285

Features:

  • Supports Intel® 6th & 7th Gen Core™ i processor (LGA1151) with Intel H110 chipset
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Supports PCIe x 4 (Gen 3), 1 F/S miniPCIe 1 H/S miniPCIe, 4 USB 3.0 and 3 SATA III
  • Supports dual display of DP/HDMI/VGA/LVDS(optional)
  • Supports TPM 1.2 / 2.0 (optional)
  • Support 12V DC Input

Data sheet on AIMB-285 (pdf file, opens in new tab)

AIMB-242 Mini-ITX Motherboard


6th Gen Intel® Xeon, Core™ i7/i5/i3 FCBGA1440 Mini-ITX with Dual DP++/HDMI/LVDS(eDP), 2 COM, Dual LAN, PCIe x16, M.2, DDR4, 8 USB3.0 & 1 USB2.0
Advantech Mini-ITX Motherboards - AIMB-242
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-242

Features:

  • Supports Intel® Xeon, 6th Gen Core™ i mobile processor (BGA) with Intel QM170/CM236 chipset
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Supports triple display of Dual DP++/HDMI/LVDS(eDP)
  • Supports PCIe x16 (Gen 3), 2 MiniPCIe, M.2, 8 USB3.0 & 1 USB2.0, 2 SATAIII
  • Supports Intel vPro, AMT 11.0, TPM 1.2 / 2.0 (optional)
  • Supports WISE PaaS/RMM and Embedded Software APIs

Data sheet on AIMB-242 (pdf file, opens in new tab)

AIMB-232 Mini-ITX Motherboard


6th Gen Intel® Core™ i7/i5/i3/Celeron BGA 1356 Mini-ITX with DP++/HDMI/LVDS(eDP), 2 COM, Dual LAN, miniPCIe, DDR4, DC Input
Advantech Mini-ITX Motherboards - AIMB-232
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-232

Features:

  • Supports 6 USB 3.0, 2 USB 2.0, TPM 1.2 / 2.0 (optional)
  • Support 12V DC Input and low profile height
  • Support 2 F/S miniPCIe
  • Multiple display I/O supports versatile Tri display functions for HDMI, DP, LVDS/eDP
  • Two 260-pin SO-DIMM up to 32GB DDR4 2133 MHz SDRAM
  • Supports Intel® Core™ core i7-6600u /core i5-6300u /core i3-6100u/celeron 3955u, 15W TDP, BGA 1356,14nm Processor

Data sheet on AIMB-232 (pdf file, opens in new tab)

AIMB-231 Mini-ITX Motherboard


5th Gen Intel® Core™ i5-5350U/ i3-5010U Mini-ITX with LVDS(eDP)/DP(HDMI)/DP++, 2 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-231
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-231

Features:

  • Intel® Core™ i5-5350U/ i3-5010U processor (Dual core), 15W TDP, BGA 1168 (MCP) 14nm Processor
  • Two 204-pin SO-DIMM up to 16 GB DDR3L 1600 MHz SDRAM
  • Multiple display I/O supports versatile Tri display functions for eDP/LVDS, DP/HDMI, and DP++
  • Realtek ALC892 supports 7.1 + 2 channel HD audio
  • Dual Intel i218/i210 Gigabit LAN
  • 1 Full-sized Mini-PCIe, 1 Half-sized Mini-PCIe,1 SIM Card Holder
  • 2 COM, 3 SATA III, 1 mSATA
  • 4 USB 3.0, 2 USB 2.0

Data sheet on AIMB-231 (pdf file, opens in new tab)

AIMB-274 Mini-ITX Motherboard


4th Gen Intel® Core™ i7/i5/i3 LGA 1150 Mini-ITX with Q87, VGA/ DP++/HDMI (DP++)/LVDS (eDP), 2 COM, Dual GbE LAN, PCIe x16, ATX or 12VDC
Advantech Mini-ITX Motherboards - AIMB-274
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-274

Features:

  • Supports Intel® Core™ i7/i5/i3 desktop processor (LGA1150) with Intel Q87 chipset
  • Two 204-pin SO-DIMM up to 16 GB DDR3/DDR3L 1333/1600 MHz SDRAM
  • Supports triple display of VGA/DP/HDMI(DP)/LVDS(eDP)
  • Supports PCIe x16 (Gen 3) and two mini PCIe
  • Supports Intel vPro, AMT 9.0, PECI 3.0, Software RAID 0,1,5,10, TPM 1.2 (optional)
  • Supports iManager, SUSIAccess and Embedded Software APIs

Data sheet on AIMB-274 (pdf file, opens in new tab)

AIMB-203 Mini-ITX Motherboard


4th Gen Intel® Core™ i7/i5/i3 LGA 1150 Mini-ITX with H81, CRT/DP /DVI/LVDS, 9 COM, 6 USB 3.0, 2 USB 2.0, Dual GbE LAN, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-203
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-203

Features:

  • Supports Intel® 4th Gen Core™ i processor (LGA1150) with Intel H81 chipset
  • Two 204-pin SO-DIMM up to 16 GB DDR3 1600 MHz SDRAM
  • Supports dual display of CRT/DVI-D/DP++/LVDs
  • Supports PCIe x16 (Gen 2) and two mini PCIe
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-203 (pdf file, opens in new tab)

AIMB-230 Mini-ITX Motherboard


4th Gen Intel® Core™ i5-5350U/ Celeron 3755U Mini-ITX with LVDS(eDP)/DP(HDMI)/DP , 2 COM, 4 USB 3.0, 2 USB 2.0, miniPCIE, and Dual GbE LAN
Advantech Mini-ITX Motherboards - AIMB-230
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-230

Features:

  • Intel® Core™ i5-5350U/ Celeron 3755U processor (Dual core), 15W TDP, BGA 1168 (MCP) 14nm Processor
  • Multiple display I/O supports versatile Tri display functions for eDP/LVDS, DP/HDMI, and DP++
  • Realtek ALC892 supports 5.1 + 2 channel HD audio
  • Dual Intel i218/i210 Gigabit LAN
  • 1 Full-sized Mini-PCIe, 1 Half-sized Mini-PCIe
  • 2 COM, 3 SATA III, 1 mSATA
  • 4 USB 3.0, 2 USB 2.0

Specifications:

Category Attribute Value
Display Controller Intel Processor Integrated
DDI (HDMI/DVI/DisplayPort) HDMI : 1920 x 1080 @ 60Hz
Graphic Engine DirectX 11.1, OpenGL 4.0, OpenCL 1.3, Full AVC, VC1, MPEG2 H/W encoder
Graphic Memory Share with system memory,2 GB and above
LCD (TTL/LVDS/eDP) LVDS: Dual channel 24-bit LVDS, up to 1920 x 1080
Multiple Display Dual/ Triple
Video Interface HDMI+LVDS (eDP), HDMI+DP++, LVDS (eDP)+DP++
Form Factor Form Factor mini ITX
I/O COM Port 2 ( 1 x RS232, 1 x RS232/ 422/ 485)
Smart Fan 2
USB2.0 2
USB3.0 4
Memory Max. Capacity 16 GB
Socket 2x 204 PIN SODIMM
Technology DDR3L 1333 MHz
Processor BIOS AMI EFI 128Mbit
Chipset Wildcat Point-LP
Core Number 2 / 4
CPU Intel 4th Celeron-2980U
CPU TDP 15 W
Frequency 1.8 GHz / 1.7 GHz
L3 Cache 3 MB
Storage CFast 0
mSATA miniPCIe co-lay mSATA
SATA 3 x SATA III (Max. Data Transfer Rate 600 MB/s)
Operating System iManager Yes
Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 1 Grm (OP)
Power Connector DC 12V Jack/ 4-pin with ATX12V
Power Adaptor Yes
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Realtek RTL8111E; GbE2: Realtek RTL8111E
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 2 (Line out, Mic In)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Safety Certifications CCC/BSMI
Expansion Slot Type 1 x Full-size (Supports mSATA) 1 x Half-size
Slots Full-size Mini-PCIe, Half-size Mini-PCIe
Physical Construction Thermal moudle or CPU cooler
Dimension (mm) 170 x 170 mm
Weight 1.04 kg (1.72 lb), weight of total package

Data sheet on AIMB-230 (pdf file, opens in new tab)

AIMB-273 Mini-ITX Motherboard


3rd Gen Intel® Core™ i7/i5/i3/Celeron uFC-PGA988 Mini-ITX with QM77, 2 DP/HDMI/LVDS/CRT, 2 COM, Dual GbE LAN, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-273
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-273

Features:

  • Supports Intel® Core™ i7/i5/i3 mobile processor (PGA) with Intel QM77 chipset
  • Two 204-pin SO-DIMM up to 16 GB DDR3 1333/1600 MHz SDRAM
  • Supports triple display of 2 DP, HDMI, LVDS, CRT
  • Supports PCIe x16 (Gen 3) and mini PCIe
  • Supports Intel vPro, AMT 8.0, PECI 3.0, Software RAID 0,1,5,10, TPM 1.2 (optional)
  • Supports iManager, SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Integrated Gfx Gen5.75
DDI (HDMI/DVI/DisplayPort) HDMI: 1650 Mbps / channel @ 165 MHz
Graphic Engine DirectX 10 and OpenGL 2.1 support
Graphic Memory Share with system memory up to 2 GB
LCD (TTL/LVDS/eDP) LVDS: Single channel 24-bit / dual channel 48-bit LVDS up to 1920 x 1080
Multiple Display Triple
VGA up to 2048 x 1536
Form Factor Form Factor mini ITX
I/O COM Port 2 ( RS-232 )
GPIO 1
TPM Yes
USB2.0 4
USB3.0 4
Memory Max. Capacity 16 GB
Socket 2 x 204-pin SODIMM
Technology DDR3 1333 / 1600 MHz
Processor BIOS AMI EFI 64 Mbit
Chipset Intel QM77
Core Number 4 / 2
CPU Intel Core i7-3610QE / i7-2710QE / i5-3610ME / i5-2510E / i3-3120ME / i3-2330E / Celeron B810
CPU TDP 45 / 35 W
Frequency 2.3 / 2.1 / 2.7 / 2.5 / 2.4 / 2.2 / 1.6 GHz
L3 Cache 6 / 3 / 2
Storage CFast 1
SATA 2 x SATA 3 (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -20~ 70° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector ATX20P
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82579LM, GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 3 (Mic-in, Line-out, Line-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI Express x 16 1
Slot Type 1
Slots PCIe x16, Mini-PCIe
Physical Construction with CPU cooler design
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package


Data sheet on AIMB-273
 (pdf file, opens in new tab)

AIMB-201DS Mini-ITX Motherboard


3rd Gen Intel® Core™ i7/i5/i3/Celeron uFC-PGA988 Mini-ITX with QM77, 2 DP/HDMI/LVDS/CRT, 2 COM, Dual GbE LAN, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-201DS
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-201DS

Features:

  • Supports Intel® Core™ i7/i5/i3 mobile processor (PGA) with Intel QM77 chipset
  • Supports triple independent display of 3 HDMI(CEC), CRT
  • Supports miniPCIe, CFast
  • 19VDC Power input, supports DC power hot plug
  • Supports iManager, SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Intel Processor Integrated
DDI (HDMI/DVI/DisplayPort) HDMI : 1920 x 1080 @ 60Hz
Graphic Engine DirectX 11 ,OpenCL 1.1 and OpenGL 3.0 support
Graphic Memory Share with system memory, 2 GB and above
Multiple Display Dual/ Triple
Form Factor Form Factor mini ITX
I/O COM Port 1
Smart Fan 1
USB2.0 2
USB3.0 1
Memory Max. Capacity 16 GB
Socket 2x 204 PIN SODIMM
Technology DDR3 1333/1600MHz
Processor BIOS AMI EFI 64Mbit
Chipset Intel QM77
Core Number 2 / 4
CPU Intel Core i7-3610QE / i7-2710QE / i5-3610ME / i5-2510E / i3-3120ME / i3-2330E / Celeron B810
CPU TDP 35 W / 45 W
Frequency 1.6 ~ 2.7 GHz
L3 Cache 2 ~ 6 MB
Storage CFast 1
mSATA miniPCIe co-lay mSATA
SATA 1 x SATA III (Max. Data Transfer Rate 600 MB/s)
Operating System iManager Yes
Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Operational Temperature 0 ~ 55° C
Vibration Resistance 1 Grm (OP)
Power Connector DC Jack
Power Adaptor Yes
Power Type ATX, AT
Ethernet Connector RJ45 x 1
Controller GbE1: Intel 82579LM
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 1 (Line-out)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Safety Certifications CCC, BSMI, UL
Expansion Slot Type 1
Physical Construction Thermal moudle or CPU cooler
Dimension (mm) 249.6 x 190.0 x 35.0 mm (with PCH heatsink)
Weight 1.04 kg (1.72 lb), weight of total package

Data sheet on AIMB-201DS (pdf file, opens in new tab)

AIMB-272 Mini-ITX Motherboard


3rd Gen Intel® Core™ i7/i5/i3/Celeron uFC-PGA988 Mini-ITX with QM77, 2 DP/HDMI/LVDS/CRT, 2 COM, Dual GbE LAN, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-272
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-272

Features:

  • Supports Intel® Core™ i7/i5/i3 mobile processor (PGA) with Intel QM67/HM65 chipset
  • Two 204-pin SO-DIMM up to 8 GB DDR3 1066/1333 MHz SDRAM
  • Supports dual display of DVI, HDMI, LVDS, CRT
  • Supports PCIe x16 (Gen 2) and mini PCIe
  • Supports Inel vPro, AMT 7.0, PECI 3.0, Software RAID 0,1,5,10, TPM 1.2 (optional)
  • Supports embedded software APIs and Utilities

Specifications:

Category Attribute Value
Display Controller Integrated Gfx Gen5.75
DDI (HDMI/DVI/DisplayPort) HDMI: 1650 Mbps / channel @ 165 MHz DVI: 1920 x 1200
Graphic Engine DirectX 10 and OpenGL 2.1 support
Graphic Memory Share with system memory up to 2 GB
LCD (TTL/LVDS/eDP) LVDS: Single channel 24-bit / dual channel 48-bit
Multiple Display Dual
VGA up to 2048 x 1536
Video Interface CRT+LVDS, CRT+DVI, DVI+HDMI, LVDS+HDMI, CRT+HDMI, DVI+LVDS
Form Factor Form Factor mini ITX
I/O COM Port 4 (RS-232)
GPIO 1
Keypad 2
TPM Yes
USB2.0 8
Memory Max. Capacity 8 GB
Socket 2x 204-pin SODIMM
Technology DDR3 1066 / 1333 MHz
Processor BIOS AMI EFI 64 Mbit
Chipset Intel QM67
Core Number 4 / 2
CPU Intel Core i7-2710QE / i5-2510E / i3-2330E / Celeron B810
CPU TDP 45 / 35 W
Frequency 2.1 / 2.5 / 2.2 / 1.6 GHz
L3 Cache 6 / 3 / 3 / 2 MB
Storage CFast 1
SATA 2 x SATA 3 (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -20~ 70° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector ATX20P
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82579LM, GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 3 (Mic-in, Line-out, Line-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI Express x 16 1
Slot Type 1
Slots PCIe x16, Mini-PCIe
Physical Construction with CPU cooler design
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package

Data sheet on AIMB-272 (pdf file, opens in new tab)

AIMB-281 Mini-ITX Motherboard


2nd & 3rd Gen Intel® Xeon E3/ Core™ i7/i5/i3/Celeron LGA1155 Mini-ITX with H61, CRT/DVI/LVDS, 6 COM, Dual GbE LAN, PCIe x4
Advantech Mini-ITX Motherboards - AIMB-281
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-281

Features:

  • Support Intel Xeon E3/ Core i7/i5/i3/ Pentium / Celeron desktop processor (LGA) with Intel H61 chipset
  • Supports dual display for VGA, DVI, LVDS
  • Support PCIe x4 (Gen 2) and mini PCIe
  • Support 8 USB, 6 COMs, 3 SATA II, 8 bit GPIO
  • Support embedded software APIs and Utilityies
  • Two 204-pin SO-DIMM up to 8GB DDR3 1066/1333/1600 MHz SDRAM

Data sheet on AIMB-281 (pdf file, opens in new tab)

AIMB-270 Mini-ITX Motherboard


1st Gen Intel® Core™ i7/i5/Celeron uFC-PGA989 Mini-ITX with QM57, CRT/2DVI/LVDS, 6 COM, Dual GbE LAN, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-270
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-270

Features:

  • Supports Intel® Core™ i7 and i5 mobile processor (PGA) with Intel QM57 chipset
  • Two 204-pin SO-DIMM up to 8 GB DDR3 800/1066/1333 MHz SDRAM
  • Supports dual display of 2 DVI, LVDS, and CRT
  • Supports PCIe x16 (Gen 2) and mini PCIe
  • Supports, AMT6.0 and software RAID 0, 1, 5, 10
  • Supports SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Integrated Gfx Gen5.75
DDI (HDMI/DVI/DisplayPort) DVI 1: 1920 x 1200 DVI 2: 1920 x 1200
Graphic Engine DirectX 10 and OpenGL 2.1 support
Graphic Memory Share with system memory up to 2 GB
LCD (TTL/LVDS/eDP) LVDS: Single channel 18/24-bit / Dual channel 36/48-bit up to 1920 x 1200
Multiple Display Dual
VGA up to 2048 x 1536
Form Factor Form Factor mini ITX
I/O COM Port 4 (RS-232)
GPIO 1
Keypad 2
USB2.0 8
Memory Max. Capacity 8 GB
Socket 2x 204-pin SO-DIMM
Technology DDR3 800 / 1066 MHz
Processor BIOS AMI EFI 64 Mbit
Chipset Intel QM57
Core Number 2 /
CPU Intel Core i7-620M / i5-520M / Celeron
CPU TDP 35 / 31 W
Frequency 2.66 / 2.4 / 1.86 GHz
L2 Cache 4 / 3 / 2 MB
Storage SATA 4 x SATA II (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -20~ 70° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector ATX20P
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82577LM, GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 3 (Mic-in, Line-out, Line-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI Express x 16 1
Slot Type 1
Slots PCIe x16, Mini-PCIe
Physical Construction with CPU cooler design
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package

Data sheet on AIMB-270 (pdf file, opens in new tab)

AIMB-280 Mini-ITX Motherboard


1st Gen Intel® Core™ i7/i5/i3/Pentium® LGA1156 Mini-ITX with Q57, CRT/DVI, 2 COM, Dual GbE LAN, 8 USB 2.0, PCIe x16
Advantech Mini-ITX Motherboards - AIMB-280
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-280

Features:

  • Supports Intel® Core™ i7/i5/i3/Pentium® processor with Q57 chipset
  • One DIMM socket supports up to 4 GB DDR3 800/1066/1333 MHz SDRAM
  • Supports dual display, CRT and DVI, and dual GbE LAN
  • Supports 2 COM, 8 USB, and 4 SATA ports
  • Supports SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Intel CPU Integrated
DDI (HDMI/DVI/DisplayPort) DVI
Graphic Memory Share with system memory up to 2 GB
LCD (TTL/LVDS/eDP) N/A
Multiple Display Dual
Video Interface CRT, DVI
Form Factor Form Factor mini ITX
I/O COM Port 2
Keypad 2
USB2.0 8
Memory Max. Capacity 4 GB
Socket 1 x 240-pin DIMM
Technology DDR3 800 / 1066 / 1333 MHz
Processor BIOS AMI EFI 64 Mbit
Chipset Intel Q57
Core Number 4 / 2
CPU Intel Core i7 / i5 600 / i5 700 / i3 / Pentium
CPU TDP 45 / 35 W
Frequency 2.93 / 2.66 / 3.3 / 3.06 / 2.8 GHz
L3 Cache 8 / 4 / 3
Storage SATA 4 x SATA II (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -20~ 70° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector ATX20P
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82578DM, GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC888, High Definition Audio (HD)
Connector 3 (Mic-in, Line-out, Line-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI Express x 16 1
Slots PCIe x16
Physical Construction with CPU cooler design
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package


Data sheet on AIMB-280
 (pdf file, opens in new tab)

AIMB-217 Mini-ITX Motherboard


Intel® Pentium/Celeron/Atom Quad Core/Dual Core Mini-ITX with DP /HDMI/VGA, 6 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-217
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-217

Features:

  • Supports Intel Pentium/Celeron/Atom processor N4200/N3350/x7-E3950
  • Two 204-pin SO-DIMM up to 8 GB DDR3L 1866 MHz SDRAM
  • Supports, DP++ (or LVDs), HDMI, VGA (or eDP)
  • Supports 1 PCIe x1 or 1 M.2 (E key), 1 Mini-PCIe expansion slot, 6 COMs, 4 USB 3.0 & 4 USB 2.0, dual LAN.
  • Lower total cost of ownership with DC12V support and onboard TPM1.2 (optional) & Amplifier (optional)

Data sheet on AIMB-217 (pdf file, opens in new tab)

AIMB-216 Mini-ITX Motherboard


Intel® Pentium/Celeron Quad Core/Dual Core Mini-ITX with DP /HDMI/DVI-D, 6 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-216
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-216

Features:

  • Supports SUSIAccess and Embedded Software APIs
  • Lower total cost of ownership with DC12V support and onboard TPM1.2 (optional) & Amplifier (optional)
  • Supports 1 PCIe x1 or 1 Mini-PCIe expansion slot, 1 M.2, 6 COMs, 4 USB 3.0 & 2 USB 2.0, dual LAN.
  • Supports DVI-D, DP, HDMI or 24-bit dual channel LVDS.
  • Two 204-pin SO-DIMM up to 8 GB DDR3L 1600 MHz SDRAM
  • Supports Intel Pentium N3710, Celeron N3160/N3010, Atom x5-E8000 processor

Data sheet on AIMB-216 (pdf file, opens in new tab)

AIMB-215 Mini-ITX Motherboard


Intel® Celeron Quad Core J1900/N2920 Mini-ITX with CRT/LVDS/DP , 6 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-215
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-215

Features:

  • Supports Intel Celeron Quad Core J1900/N2920 processor
  • Two 204-pin SO-DIMM up to 8 GB DDR3L 1333 MHz SDRAM
  • Supports VGA/DP1.2 /24-bit dual channel LVDS
  • Supports 1 PCIE x1 and 2 mini-PCIE expansion slot, 6 COMs, 9 USB 2.0, and 1 USB 3.0
  • Lower total cost of ownership with DC12V support and onboard TPM1.2(optional)
  • Supports SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display DDI (HDMI/DVI/DisplayPort) Display port 1.2 supports up to 2560 x 1600
LCD (TTL/LVDS/eDP) LVDS: dual channel 24-bit up to 1920 x 1200
Multiple Display Dual
VGA Up to 2560 x 1600
I/O COM Port (5 x RS232,1 x RS232/ 422/ 485)
Processor CPU J1900
Ethernet Controller GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E
Audio CODEC Realtek ALC892, High Definition Audio (HD)
Expansion Slots 1 x PCIex1, 2 x MiniPCIe

Data sheet on AIMB-215 (pdf file, opens in new tab)

AIMB-214 Mini-ITX Motherboard


Intel® Atom™ N2600/D2550 Mini-ITX with CRT/HDMI/2LVDS, 6COM, and Dual LAN ports
Advantech Mini-ITX Motherboards - AIMB-214
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-214

Features:

  • Supports Intel® Atom™ processor N2600, and D2550 dual core
  • One 204-pin SODIMM up to 4 GB DDR3 1066 MHz SDRAM
  • Supports 1 PCI and 1 Mini-PCIe expansion, 6 serial ports, 6 USB, and CFast
  • Lower total cost of ownership with DC12V support, and supports 18/24-bit LVDS
  • Onboard TPM 1.2 support (optional)
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-214 (pdf file, opens in new tab)

AIMB-213 Mini-ITX Motherboard


Intel® Atom™ N455/D525 Mini-ITX with CRT/DVI/LVDS, 6 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-213
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-213

Features:

  • Supports Intel® Atom™ processor N455 and D525 dual core
  • Two 204-pin SODIMM up to 2 GB/4 GB DDR3 800 MHz SDRAM
  • Supports 1 PCI and 1 Mini-PCIe expansion, 6 serial ports, 8 USB, and CF
  • Lower total cost of ownership with DC12V support and support 18/24-bit LVDS
  • Onboard TPM 1.2 support (optional)
  • Supports SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Intel Atom N455 intergrated
DDI (HDMI/DVI/DisplayPort) DVI: up to UXGA 1600 x 1200 @ 60Hz
Graphic Memory Share with system memory up to 224 MB
LCD (TTL/LVDS/eDP) LVDS: single channel 18/24-bit up to WXGA 1366 x 768
Multiple Display Dual
VGA up to SXGA 1400 x 1050 @ 60Hz
Video Interface VGA+DVI , VGA+LVDS
Form Factor Form Factor mini ITX
I/O COM Port 6(5 x RS-232, 1 x RS-232/422/485)
GPIO 1
USB2.0 8
Memory Max. Capacity 4 GB
Socket 2 x 204 pin SODIMM
Technology DDR3 800MHz
Processor BIOS AMI SPI 16 Mbit
Chipset Intel ICH8M
Core Number 1
CPU Intel Atom N455
CPU TDP 6.5 W
Frequency 1.66 GHz
L2 Cache 512 KB
Storage CompactFlash CompactFlash Type I/II
RAID 3 x SATA II (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -40~ 85° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector DC jack, internal 4pin
Power Adaptor Yes
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82567V, GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 3 (Line-in, Line out, Mic-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI 1
Slot Type 1
Slots PCI, Mini-PCIe
Physical Construction with fanless design
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package

Data sheet on AIMB-213 (pdf file, opens in new tab)

AIMB-212 Mini-ITX Motherboard


Intel® Atom™ N450/D510 Mini-ITX with CRT/LVDS, 6 COM, and Dual LAN ports
Advantech Mini-ITX Motherboards - AIMB-212
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-212

Features:

  • Supports Intel® Atom™ processor N450 and D510 dual core
  • One 200-pin SODIMM up to 2 GB DDR2 667 MHz SDRAM
  • Supports 1 PCI and 1 Mini-PCIe expansion, 6 serial ports, 8 USB, and CF
  • Lower total cost of ownership with DC12V support
  • Supports SUSIAccess and Embedded Software APIs

Specifications:

Category Attribute Value
Display Controller Intel Atom D510 intergrated
Graphic Memory Share with system memory up to 224 MB
LCD (TTL/LVDS/eDP) LVDS:single channel 18-bit up to WXGA 1366 x 768
Multiple Display Dual
VGA up to SXGA 2048 x 1536 @ 60Hz
Video Interface LVDS, VGA, Dual Display CRT+LVDS
Form Factor Form Factor mini ITX
I/O COM Port 6(5 x RS-232, 1 x RS-232/422/485)
GPIO 1
USB2.0 8
Memory Max. Capacity 2 GB
Socket 1 x 200-pin SODIMM
Technology DDR2 667MHz
Processor BIOS AMI PSI 16 Mbit
Chipset Intel ICH8M
Core Number 2
CPU Intel Atom D510
CPU TDP 13 W
Frequency 1.66 GHz
L2 Cache 1 MB
Storage CompactFlash CompactFlash Type I/II
SATA 2 x SATA II (Max. Data Transfer Rate 300 MB/s)
Operating System Linux Yes
Microsoft Windows Yes
SUSIAccess Yes
Environment Non-Operational Temperature -40~ 85° C
Operational Temperature 0 ~ 60° C (32 ~ 140° F)
Vibration Resistance 3.5 Grms (non OP)
Power Connector DC jack, internal 4pin
Power Adaptor Yes
Power Type ATX, AT
Ethernet Connector RJ45 x 2
Controller GbE1: Intel 82567V; GbE2: Intel 82583V
Speed 10/ 100/ 1000 Mbps
Audio Audio Interface HD Audio
CODEC Realtek ALC892, High Definition Audio (HD)
Connector 3 (Mic-in, Line-out, Line-in)
Watchdog Timer WatchDog Timer Yes
Certification EMC CE, FCC
Expansion PCI 1
Slot Type 1
Slots PCI, Mini-PCIe
Physical Construction with CPU cooler desing
Dimension (mm) 170x 170 mm (without heatsink)
Weight 1.04 kg (1.72 lb), weight of total package


Data sheet on AIMB-212
 (pdf file, opens in new tab)

AIMB-227 Mini-ITX Motherboard


AMD Merlin Falcon Quad Core Mini-ITX with DP /DP /DP/HDMI, 6COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-227
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-227

Features:

  • Supports AMD Merlin Falcon / Brown Falcon / Prairie Falcon processor
  • Two 260-pin SO-DIMM up to 16GB DDR4 2133 SDRAM
  • Supports triple display with DP/eDP/LVDS + DVI-D + HDMI
  • Supports 1 PCIe x8 and 1 Mini-PCIe expansion slots
  • 6 COM, 4 USB 2.0, 4 USB 3.0
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-227 (pdf file, opens in new tab)

AIMB-226 Mini-ITX Motherboard


AMD R-series Quad Core/Dual Core Mini-ITX with HDMI/LVDS/DP , 6 COM and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-226
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-226

Data sheet on AIMB-226 (pdf file, opens in new tab)

AIMB-225 Mini-ITX Motherboard


AMD G-series Quad Core Mini-ITX with DVI-I/LVDS/DP /eDP, 5 COM, and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-225
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-225

Features:

  • Supports AMD Steppe Eagle Quad core processor
  • Two 204-pin SO-DIMM up to 16GB DDR3L 1866 SDRAM
  • Supports dual display with DVI-I+LVDS, DVI-I+DP, eDP+LVDS and eDP+DP
  • Supports 1 PCIe x4 and 2 Mini-PCIe expansion slots
  • 5 COM, 6 USB 2.0, 2 USB 3.0
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-225 (pdf file, opens in new tab)

AIMB-224 Mini-ITX Motherboard


Mobile AMD R-series Quad Core/Dual Core Mini-ITX with VGA/LVDS/HDMI/DP/eDP, 6COM and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-224
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-224

Features:

  • Supprt AMD Mobile eTrinity Quard core/Dual Core processor
  • Two 204-pin SODIMM up to 16 GB DDR3 1066/1333/1600 MHz SDRAM
  • Supports VGA/LVDS/HDMI/DP/eDP
  • Daul LANs, 6COM, 2Mini PCIe
  • Supports embedded software APIs and Utilities

Data sheet on AIMB-224 (pdf file, opens in new tab)

AIMB-223 Mini-ITX Motherboard


Mobile AMD G-series Dual Core/Single Core Mini-ITX with CRT/LVDS/HDMI, 6 COM and Dual LAN
Advantech Mini-ITX Motherboards - AIMB-223
Click here to show/ hide more info

Advantech Mini-ITX Motherboards - AIMB-223

Features:

  • Supports AMD Mobile G-series Dual Core/Single Core processor
  • ƒOne 204-pin SO-DIMM up to 4 GB DDR31066/1333 MHz SDRAM
  • Supports Dual display with CRT/HDMI/LVDS (eDP)
  • Dual LANs, 6COM, Mini PCIe, and CFast
  • Supports SUSIAccess and Embedded Software APIs

Data sheet on AIMB-223 (pdf file, opens in new tab)
