DaqPro 8-channel Universal Input Data Logger - Fourtec

8-Channel Handheld, High-performance Data Logger

DaqPRO Logger Overview

8-channel, High-performance Data Logger

  • Cost effective data logging solution for a wide range of industrial applications
  • Eight sensor inputs supporting 16-bit resolution
  • Large graphic display for stand-alone setup, data display and analysis
  • User configurable sampling rate supporting up to 4,000 samples/second
  • Each input can be configured to measure a different sensor
  • Rechargeable 7.2 V battery supporting up to 24 hours between charging cycles

The DaqPRO is a stand-alone, high performance data acquisition device that is fully compatible with industry-standard sensors. The data logger features a graphical display and user-friendly handheld operation for measuring parameters such as voltage, current, temperature, pulse and frequency, as well as user-defined sensors.

DaqPRO Brochure (pdf file, opens in new tab)

DaqPRO Devices

DB5301A – DaqPro 8-channel Data Logger


DAQ PRO 8-channel Data Logger Kit, includes logger, software CD, USB cable, mains adaptor, calibration cert, carrying case.
DB5301A - DaqPro 8-channel Data Logger
Click here to show/ hide more info

DB5301A - DaqPro 8-channel Data Logger

The DaqPRO is a stand-alone, high performance data acquisition device that is fully compatible with industry-standard sensors. The data logger features a graphical display and user-friendly handheld operation for measuring parameters such as voltage, current, temperature, pulse and frequency, as well as user-defined sensors.

Designed to operate without the need for PC connection the DaqPRO is also supported by the DaqLab software for enhanced data analysis and device configuration.

Key product Benefits:

  • Eight sensor inputs supporting 16-bit resolution
  • One alarm output
  • Large graphic display for stand-alone setup, data display and analysis
  • User configurable sampling rate supporting up to 4,000 samples/second
  • Each input can be configured to measure a different sensor
  • Data storage up to 512 KB RAM, including cyclic memory mode
  • On-board real time clock for accurate time stamps
  • Rechargeable 7.2 V battery supporting up to 24 hours between charging cycles
  • Cost effective data logging solution for a wide range of industrial applications

Specifications:

INPUT TYPES
Each DaqPRO input can be configured to measure any of the input types below:
0 to 24 mA
  • Range: 0 to 24 mA
  • Resolution: 4.76 μA
  • Accuracy: ±0.5 %
  • Loop impedance: 21 Ω
0 to 50 mV
  • Range: 0 to 50 mV
  • Resolution: 3 μV
  • Accuracy: ±0.5 %
0 to 10 V
  • Range: 0 to 10 V
  • Resolution: 200 μV
  • Accuracy: ±0.5 %
  • Input impedance: 125 KΩ
Temperature NTC
  • NTC: 10/100 KΩ resistor
  • Range: -25 to 150 °C
  • Resolution: 0.05 °C
  • Accuracy: ±0.5 %
Temperature PT-100
  • Range: -200 to 400 °C
  • Resolution: 0.1 °C (7 mΩ)
  • Accuracy:
    -200 to -50 ºC: ±0.5 %
    50 to 400 ºC: ±0.5 %
    -50 to 50 ºC: ±0.5 ºC

The DaqPRO offers up to 8 PT-100 2 wire channels or 4 PT-100 3 wire channels

Temperature Thermocouple J
  • Range: -200 to 1200 °C
  • Resolution: 0.1 °C (1 μV)
  • Accuracy:
    -200 to -50 °C: ±0.5 %
    50 to 1,200 °C: ±0.5 %
    -50 to 50 °C: ±0.5 °C

Cold junction compensation error: ±0.3 °C

Temperature Thermocouple K
  • Range: -250 to 1,200 °C
  • Resolution: 0.1°C (1 μV)
  • Accuracy:
    -250 to -50 °C: ±0.5 %
    50 to 1,200 °C: ±0.5 %
    -50 to 50 °C: ±0.5 °C

Cold junction compensation error: ±0.3 °C

Temperature Thermocouple T
  • Range: -200 to 400 °C
  • Resolution: 0.1 °C (1 μV)
  • Accuracy:
    -200 to -50 °C: ±0.5 %
    50 to 400 °C: ±0.5 %
    -50 to 50 °C: ±0.5 °C

Cold junction compensation error: ±0.3 °C

Internal Temperature
  • Range: -25 to 70 °C
  • Resolution: 0.1°C (1 μV)
  • Accuracy: ±0.5 °C
Pulse Counter (Input 1 only)
  • Optocoupler input
  • Range: 0 to 65,000
  • Input signal: 0 to 5 V
  • Input impedance: 470 Ω
  • Bandwidth: 0 to 25 Hz
Frequency Meter (Input 1 only)
  • Optocoupler input
  • Range: 20 to 4,000 Hz
  • Input signal: 0 to 5 V
  • Input impedance: 470 Ω
General A to D Specifications
  • Noise: 30 μV rms
  • Internal linearity error: ±0.08 % of FSR
  • Offset error: 0.1 %
Open Collector Output (Output 8)
  • Maximum current sink: 50 mA (fuse protected)
  • Maximum input voltage: 5 V
  • Input impedance: 50 Ω
Communication
  • USB 1.1 compliant
Sampling
  • Capacity: 512 KB
  • Analog sampling rate: Variable, 1 sample/hour to 4,000 samples/sec (on 1 channel only)
  • Analog sampling resolution: 16-bit
  • Channel separation: 80 dB
Man Machine Interface
  • Full keyboard operation – enables manual programming of the logger
  • Graphic LCD 64 x 128 pixels
Power Supply
  • Internal rechargeable 7.2V NiMH battery
  • Built-in battery charger
  • External 9 to 12 V DC input
  • Battery life: 25 hours between charges
Operating Temperature Range
  • 0 to 50 °C
Casing
  • Plastic PC-ABS
  • Dimensions: 182 x 100 x 28 mm
  • Weight: 450 g
Standards Compliance
  • CE, FCC

Solutions:

  • Heavy Industry Productions
  • Laboratories
  • Schools Universities

DaqPRO User Guide (pdf file, opens in new tab)

Accessories and Software

Accessories

12751 – PT-100 Temperature Probe (2-wire), 6 m cable


Temperature Sensor, PT-100, stainless steel 80mm probe,-70 to 400 deg C,  6 meter Teflon cable (cable rating -65 to 200C).
PT-100 Temperature Probe (2-wire), 6 m cable
Click here to show/ hide more info

PT-100 Temperature Probe (2-wire), 6 m cable

The PT-100 temperature probe provides accurate, stable readings with fast response time over a range of -70 to 400 °C, and is well suited for a variety of temperature applications.

Fourtec’s range of PT-100 2-wire sensors is made of thin-film Platinum RTD elements sputtered on ceramic substrate. PT-100 sensors have a resistance of 100 Ώ at 0 °C, with the resistance changing with the temperature.

Fourtec software supports both 2-point and offset calibration for the PT-100 sensors when connected to the data loggers.

Specifications:

Temperature range: -70 to 400 °C
Class A accuracy
Probe length: 80 mm
Probe tip: Rounded
Cable material: Teflon, waterproof
Cable length: 6 m
Cable operating temperature: -65 to 200 ˚C

12752 – PT-100 Temperature Probe (2-wire), 4 m cable


Temperature Sensor, PT-100, stainless steel 80mm probe,-70 to 400 deg C,  4 meter Teflon cable (cable rating -65 to 200C).
PT-100 Temperature Probe (2-wire), 4 m cable
Click here to show/ hide more info

PT-100 Temperature Probe (2-wire), 4 m cable

The PT-100 temperature probe provides accurate, stable readings with fast response time over a range of -70 to 400 °C, and is well suited for a variety of temperature applications.

Fourtec’s range of PT-100 2-wire sensors is made of thin-film Platinum RTD elements sputtered on ceramic substrate. PT-100 sensors have a resistance of 100 Ώ at 0 °C, with the resistance changing with the temperature.

Fourtec software supports both 2-point and offset calibration for the PT-100 sensors when connected to the data loggers.

Specifications:

Temperature range: -70 to 400 °C
Class A accuracy
Probe length: 80 mm
Probe tip: Rounded
Cable material: Teflon, waterproof
Cable length: 4 m
Cable operating temperature: -65 to 200 ˚C

12753 – PT-100 Temperature Probe (2-wire), 2.5 m cable


Temperature Sensor, PT-100, stainless steel 80mm probe,-70 to 400 deg C,  2.5 meter Teflon cable (cable rating -65 to 200C)
12753 - PT-100 Temperature Probe (2-wire), 2.5 m cable
Click here to show/ hide more info

12753 - PT-100 Temperature Probe (2-wire), 2.5 m cable

The PT-100 temperature probe provides accurate, stable readings with fast response time over a range of -70 to 400 °C, and is well suited for a variety of temperature applications.

Fourtec’s range of PT-100 2-wire sensors is made of thin-film Platinum RTD elements sputtered on ceramic substrate. PT-100 sensors have a resistance of 100 Ώ at 0 °C, with the resistance changing with the temperature.

Fourtec software supports both 2-point and offset calibration for the PT-100 sensors when connected to the data loggers.

Specifications:

Temperature range: -70 to 400 °C
Class A accuracy
Probe length: 80 mm
Probe tip: Rounded
Cable material: Teflon, waterproof
Cable length: 2.5 m
Cable operating temperature: -65 to 200 ˚C

50116 – PT-100 Cryogenic Temperature Probe (2-wire), 2.5 m cable


Temperature Sensor, PT-100, stainless steel 80mm probe,-200 to 400 deg C,  2.5 meter Teflon cable (cable rating -65 to 200C)
50116 - PT-100 Cryogenic Temperature Probe (2-wire), 2.5 m cable
Click here to show/ hide more info

50116 - PT-100 Cryogenic Temperature Probe (2-wire), 2.5 m cable

The PT-100 Cryogenic temperature probe provides accurate, stable readings with fast response time over a range of -200 to 400 °C, and is therefore well suited to extreme low temperature applications.

Fourtec’s range of PT-100 2-wire sensors is made of thin-film Platinum RTD elements sputtered on ceramic substrate. PT-100 sensors have a resistance of 100 Ώ at 0 °C, with the resistance changing with the temperature.

Fourtec software supports both 2-point and offset calibration for the PT-100 sensors when connected to the data loggers.

Specifications:

Temperature range: -200 to 400 °C
Class A accuracy
Probe length: 80 mm
Probe tip: Rounded
Cable material: Teflon, waterproof
Cable length: 2.5 m
Cable operating temperature: -65 to 200 ˚C

50165 – Thermocouple Type K Probe with Flat Pin Connector


Temperature Sensor, Thermocouple K type, -200 to 1000 deg C, 1.5 mm probe diam, 500mm cable length
50165 - Thermocouple Type K Probe with Flat Pin Connector
Click here to show/ hide more info

50165 - Thermocouple Type K Probe with Flat Pin Connector

The Thermocouple Type K probe is a highly accurate, reliable probe for both extreme low and high temperature applications. A flat pin connector is used for easy interface between probe and connecting wires. The Thermocouple probe is compatible with Fourtec’s DaqPRO, DaqLink and DataNet range of data loggers.

Specifications:

Temperature range: -200 to 1000 °C
Flat pin connector
Probe length: 500 mmm
Probe diameter: 1.5 mm

DT043 – High Accuracy External Temperature and Humidity Probe


Humidity and Temperature Probe, RH 0-100% ±1.5%, temp -40 to 60°C ±0.5°C, 3m cable, suits DataNet/DaqLink universal input loggers.
DT043 - High Accuracy External Temperature and Humidity Probe
Click here to show/ hide more info

DT043 - High Accuracy External Temperature and Humidity Probe

The DT043 is a highly accurate temperature and humidity probe. It measures relative humidity ranging from 0 to 100% with an error of not more than ± 1.5% RH over the entire range. The DT043 includes, in its screw-on cap, a temperature sensing element that measures temperatures ranging from ‑50 to 100 °C.

The DT043 probe is compatible with Fourtec’s DaqPRO, DaqLink and DataNet range of data loggers.

Specifications:

Operating Range: 0…100% RH / -50…100 °C
Measurement Range: 0…100% RH / -50…100 °C
Outputs (factory default): 0…1 V = 0…100% RH / -40…60 °C
Start-up Time: 2 s
Measurement Interval: 1 s
Supply voltage & Load: 6…24 VDC / 5…16 VAC / >1 kOhm
Accuracy at 23 °C: ± 1.5% rH / ± 0.5 °C
Protection rating: IP65 (except sensor/filter area)
Cable length: 3 m
Wire Colors:                  Description:
Green Power +VDC
Gray GND (digital and power)
White Analogue signal % RH / Humidity
Brown Analogue signal °C  / Temperature
Yellow AGND (analogue ground)
Shield Not connected on probe side

13750 – USB over IP Ethernet Adapter for Remote Device Connection


USB over IP shareserver-4 ports USB2.0 Ethernet.
13750 - USB over IP Ethernet Adapter for Remote Device Connection
Click here to show/ hide more info

13750 - USB over IP Ethernet Adapter for Remote Device Connection

The 4-port USB over IP Ethernet Adapter provides the capability for remotely connecting to any Fourtec USB-supported device over a LAN connection. For example, if you need to monitor the DataNet wireless system remotely and not from an onsite PC, simply connect the DataNet Receiver to the USB over IP device, and as long as you are on the same LAN, launching the DataSuite software will automatically detect the DataNet network as if you were connected to the Receiver directly via the USB cable. You will then be able to monitor the entire system as normal.

Specifications:

Windows® XP x86 / XP 64-bit
Windows® Vista/7 X86 / Vista/7 64-bit
Windows® 2000
233 MHz Pentium® II or above
64 MB RAM (128 MB recommended)
CD-ROM drive for installation

Software

SFTDAQ001 – DaqLab Software for DaqPRO


DaqLab software provides sophisticated data analysis and configuration tools for the DaqPRO data acquisition system.
SFTDAQ001 - DaqLab Software for DaqPRO
Click here to show/ hide more info

SFTDAQ001 - DaqLab Software for DaqPRO

Use the DaqLab to stream data directly from the DaqPRO for online viewing in graph, meter or table displays. If operating the DaqPRO in standalone mode, perform fast USB download to the PC and use DaqLab to perform extensive data analysis.

The DaqLab interface is both user-friendly and feature-rich, offering the user a variety of configuration functions for the user to leverage the full functionality of the DaqPRO logger.

DaqLab is quick to install and has a highly intuitive Windows-based interface, featuring an easy 3-step DaqPRO setup wizard letting the user configure each of the 8 logger inputs, as well as alarm thresholds, sampling rate and recording time (by time or sample size),

DaqLab also supports full calibration of all inputs and input types, with the ability to save the calibration settings both on the logger and then back them up on the PC.

Key DaqLab benefits:

  • Fast data download from DaqPRO data logger
  • Data displayed in graphical, tabular and meter views
  • Online data streaming to DaqLab in real-time
  • Sophisticated data analysis tools including over 30 mathematical functions, data export to Excel & CSV, and graph features such as zoom, crop, manual scaling
  • Data archive and file management
  • Printing of data graphs and tables
  • Definition of up to 20 custom sensors in the DaqPRO
  • Intuitive DaqPRO configuration and calibration options

Specifications:

Product Part Number: SFTDAQ001
Software Activation: Software is free to use, no activation is required.
Order shipped with: Software CD included with every DaqPRO purchase
System Requirements
  • Windows XP, Vista, 7 (32 and 64-bit)
  • Screen resolution 800 x 600 or higher
  • 10 MB disk space
