Analog I/O Cards

WaveScan 2 (supplied)
Wavescan is a real-time waveform display utility capable of displaying on the screen and storing the incoming data into users’ HDD.
In the Version 2.0, moreover, Wavescan extend its support list to all our PCI cards.
The ActiveDAQ-based design concept gives more fexibility to the users by designing their own Wavescan edition.

Other software available:  See  Software (for Advantech hardware only) (opens new Tab or Window)

Note about installing the drivers for cards and devices under Windows
It is best to install the driver software before you install the actual hardware 1. Reboot the computer 2. Install the driver. 3. Insert the card into the PCI bus 4. Power on and take note of the i/o and interupt the PnP bios gives the card. 5. Boot into Windows and let the cards detect and let Windows search for the driver.	If you installed the card before installing the drivers: 1. Uninstall the driver, power off, remove the card. 2. Reboot, reinstall the driver. 3. Reinsert the card into the PCI bus, but in a different slot 4. Power on and take note of the i/o and interupt the PnP bios gives the card. 5. Boot into Windows and let the cards detect and let Windows search for the driver.



Analog Input and Analog Output Cards with DIO – Advantech

Part Number

Description

Analog Input*

Analog Output*

General

Isolated Digital I/O

Relay Output

Timer/Counter

TTL DI/O

Channels

Resolution (Bits)

Sampling Rates (S/s)

Type

Channels

Resolution (Bits)

Update Rate (S/s)

Bus

Input Channels

Output Channels

Channels

Channels

Input Channels

Output Channels

PCI-1706U-AE

250 kS/s, 16-bit, 8-ch Simultaneous Sampling, Multifunction PCI Card

8

16

250 K

Simultaneous Sample

2

12

30 K

PCI

N/A

N/A

N/A

2

16 (shared)

16 (shared)

PCI-1710HGU-DE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

2

12

Static

PCI

N/A

N/A

N/A

1

16

16

PCI-1710U-DE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

2

12

Static

PCI

N/A

N/A

N/A

1

16

16

PCI-1710UL-DE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

1

16

16

PCI-1711U-CE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

2

12

Static

PCI

N/A

N/A

N/A

1

16

16

PCI-1711UL-CE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

1

16

16

PCI-1712-AE

1 MS/s, 12-bit, 16-ch Multifunction PCI Card

16

12

1 M

Scan

2

12

1 M

PCI

N/A

N/A

N/A

3

16 (shared)

16 (shared)

PCI-1712L-AE

1 MS/s, 12-bit, 16-ch Multifunction PCI Card

16

12

1 M

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

3

16 (shared)

16 (shared)

PCI-1713U-BE

100 kS/s, 12-bit, 32-ch Isolated Analog Input Universal PCI Card

32

12

100 K

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

N/A

N/A

N/A

PCI-1714U-BE

10/30 MS/s, 12-bit, 4-ch Simultaneous Analog Input PCI Card

4

12

30 M

Simultaneous Sample

N/A

N/A

N/A

PCI

N/A

N/A

N/A

N/A

N/A

N/A

PCI-1714UL-BE

10/30 MS/s, 12-bit, 4-ch Simultaneous Analog Input PCI Card

4

12

10 M

Simultaneous Sample

N/A

N/A

N/A

PCI

N/A

N/A

N/A

N/A

N/A

N/A

PCI-1715U-AE

500 kS/s, 12-bit, 32-ch Isolated Analog Input Universal PCI Card

32

12

500 K

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

N/A

N/A

N/A

PCI-1716-AE

250 kS/s, 16-bit, 16-ch Multifunction PCI Card

16

16

250 K

Scan

2

16

Static

PCI

N/A

N/A

N/A

1

16

16

PCI-1716L-AE

250 kS/s, 16-bit, 16-ch Multifunction PCI Card

16

16

250 K

Scan

N/A

N/A

N/A

PCI

N/A

N/A

N/A

1

16

16

PCI-1718HDU-AE

100 kS/s, 12-bit, 16-ch Universal Multifunction PCI Card

16

12

100 K

Scan

1

12

100 K

PCI

N/A

N/A

N/A

1

16

16

PCI-1720U-BE

12-bit, 4-ch Isolated Analog Output Universal PCI Card

N/A

N/A

N/A

N/A

4

12

Static

PCI

N/A

N/A

N/A

N/A

N/A

N/A

PCI-1721-AE

12-bit, 4-ch Analog Output PCI Card with 16-ch Digital I/O

N/A

N/A

N/A

N/A

4

12

10 M

PCI

N/A

N/A

N/A

1

16 (shared)

16 (shared)

PCI-1723-BE

16-bit, 8-ch Analog Output PCI Card with 16-ch Digital I/O

N/A

N/A

N/A

N/A

8

16

Static

PCI

N/A

N/A

N/A

N/A

16 (shared)

16 (shared)

PCI-1724U-AE

14-bit, 32-ch Isolated Analog Output Universal PCI Card

N/A

N/A

N/A

N/A

32

14

Static

PCI

N/A

N/A

N/A

N/A

N/A

N/A

Select from a wide range of ADLINK’s PC-based data acquisition modules, including analog input, load cell sensor measurement, analog output, digital I/O, relay outputs, and timer/counter boards.

ADLINK’s data acquisition modules are designed for a wide range of applications and are available in a variety of form factors including USB, PCI, PCI Express, PXI, CompactPXI, PC/104+, and ISA.

More than one hundred DAQ and DIO modules are offered. All ADLINK boards support NI® Labview™, MATLAB® Data Acquisition Toolbox™, Microsoft® Visual Basic®, and Microsoft® Visual C++®.

M-ACL9111   16-Ch 12/16-Bit 100 kS/s Low Cost Multi-Function DAQ Card – PCI Bus
Data on M-ACL9111 (pdf, opens in new tab)

PCI-9111DG   16-Ch 12-Bit 100 kS/s Low Cost Multi-Function DAQ Card
PCI-9111HR   16-Ch 16-Bit 100 kS/s Low Cost Multi-Function DAQ Card

PCI/PCIe Multi-Function DAQ

PCI-9222/9223	16/32 -CH 16-Bit 250/500 KS/s Multi-Function DAQ Cards with Encoder Input
DAQe-2213/2214	16-CH 16-Bit 250 kS/s Low-Cost Multi-Function DAQ PCI Express Cards
DAQe-2500 Series	4/8-CH 12-Bit 1 MS/s Analog Output Multi-Function DAQ PCI Express Cards
DAQe-2200 Series	64-CH 12/16-Bit Up to 3 MS/s Multi-Function DAQ PCI Express Cards
DAQe-2208	96-CH 12-Bit 3 MS/s High-Density Analog Input PCI Express Card
DAQe-2000 Series	4-CH 14/16-Bit Up to 2 MS/s Simultaneous-Sampling Multi-Function DAQ PCI Express Cards
PCI-9221	Low-Cost 16-Bit Multi-Function DAQ Card with 2-CH Encoder Input
DAQ-2213/2214	Low-Cost 16-CH 250 kS/s 16-Bit Multi-Function DAQ Cards
DAQ-2208	96-CH 12-Bit 3 MS/s High-Density Analog Input Card
PCI-9114 Series	32-CH 16-Bit Up to 250 kS/s Multi-Function DAQ Cards
PCI-9113A	32-CH 12-Bit 100 kS/s Isolated Analog Input Card
PCI-9112	16-CH 12-Bit 110 kS/s Multi-Function DAQ Card
PCI-9111 Series	16-CH 12/16-Bit 100 kS/s Low-Cost Multi-Function DAQ Cards
DAQ-2500 Series	4/8-CH 12-Bit 1 MS/s Analog Output Multi-Function DAQ Cards
DAQ-2200 Series	64-CH 12/16-Bit, Up to 3 MS/s Multi-Function DAQ Cards
DAQ-2000 Series	4-CH 14/16-Bit Up to 2 MS/s Simultaneous-Sampling Multi-Function DAQ Cards



Analog Cards for PC – ISA Bus

PC-LabCards (Advantech): ISO-9001 – High quality cards and computers, Taiwan. Warranty period: 2 years.

PCL-818 Series: 12-bit Data Acquisition Cards, ISA Bus

PCL-812PG-CE  30k, 12bit Multifunction Card $445+GST      9/11
PCL-813B-AE     25k, 12bit, 32ch Isolated Analog Input Card $561
PCL-816-AE       16 Bit Modular Data Acquisition Card $843

PCL-818HD-CE 100k, 12bit Multifunction Card $578
PCL-818HG-CE 100k, 12bit High-gain Multifunction Card $623
PCL-818L-B1 CIRCUIT BOARD, 40k, 12bit Low-cost Multifunction Card $361
PCL-818L-CE 40k, 12bit Low-cost Multifunction Card $361
PCL-818LS-CE PCL-818L with PCLD-8115 and PCL-10137 $383

Half size, ISA bus cards, using Advantech AD1801 ASIC.
A/D inputs: 16 single ended or 8 differential, 12-bit, 40 or 100Ksa/sec sample & hold, with programmable gain.
Multigain instr amplifier, 0.01% acc ±1 bit.
Auto channel scanning, and on-board SRAM, allow multiple-channel A/D conversion with DMA, and individual channel gains.
Trigger by software, onboard timer or ext trigger.
Data transfer by prog ctrl, interrupt or by DMA.
D/A: PCL-818H/HG/L: 1ch.; PCL-818: 2ch;    12-bit, 0 to +5V or 0 to +10V, 5µsec.
Digital: 16 input lines & 16 output lines
Counter/Timer: Intel 8254; Trig out from ev 71 min to 2.5MHz; Timebase 10MHz or 1 MHz; 16-bit counter.
SW provided: see top of col 2, transducer linearization, demo & calibration programs, install aids. BASIC, C & PASCAL drivers; Labtech Acquire

The PCL-818 series has programmable gain. It offers a software programmable analog input range (gain) for each channel,
with A/D conversion time of 8µsec for PCL-818H, or 25µsec for the PCL-818L.
Automatic channel list & gain scanning (SRAM stores ch list with different gain values for each channel).

Compatible with Keithley Metrabyte DAS-16. All PCL-818 series have 2x 20-pin cnnctrs for digital I/O.

Model	A/D speed	Unipolar input (V)	Bipolar input (V)	On-board memory	D/A chan.	Connector	Size	On-board DC/DC	Power Consumption
PCL-818L	40kHz	—	+/-10, +/-5, +/-2.5, +/-1.25, +/-0.625	—	1	DB-37	155 X 100 mm	—	<1.4W
PCL-818HD	100kHz	1~10, 0~ 5, 0~2.5, 0~1.25	+/-10, +/-5, +/-2.5, +/-1.25, +/-0.625	1 K word FIFO	1	DB-37	185 X 100 mm	Yes	<2.8W
PCL-818HG	100kHz	0~10, 0~ 1, 0~0.1, 0~0.01	+/-10, +/-5, +/-2.5, +/-1.25, +/-0.625	1 K word FIFO	1	DB-37	185 X 100 mm	Yes	<2.8W
PCL-818H	100kHz	0~10,0~ 5, 0~2.5,0~1.25	+/-10, +/-5, +/-2.5, +/-1.25, +/-0.625	—	1	20-pin box header	185 X 100 mm	Yes	<2.8W

Click here for wiring boards or daughter boards.
For analog I/O, some use DB37 & some use 2x 20-pin flat. See above for software included.

PCL-818L Low cost, 25µsec (40KHz), inputs: ±10V, ±5V,±2.5V,±1.25V,±0.625V.
DB37F cnnctr for analog inputs, 2 x 20-pin male for digital in & out

PCL-818LS adds PCLD-8115 wiring board & cable with mating DB37 cnnctr, 1m

PCL-10501 Adaptor for Analog ports:
a 37-pin male connector with solder lugs for wiring to shielded cable,
plus 2x 20-pin F ribbon cable connectors to 37-pin D-type female connector.    PCL-10501: $35

See Wiring Accessories at end of this page.

PCL-818H 8µsec. Inputs: ±10V, ±5V, ±2.5V, ±1.25V, ±0.625V, & unipolar 10V, 1V, 0.1V, 0.01V, sw sel. Has 1 D/A conv. An I/O: 4x 20-pin m flat cable cnctrs. 185x100mm (see also PCL-818HD)

PCL-818HG as above, with high gain & 1Kword data FIFO buffer. Measure thermocouples directly.
Programmable gains of 0.5, 1 (100KHz, single ch);    0.5, 1, 5, 10 (35KHz Multiple Channel Scan);
50, 100 (7KHz);     500 & 1000 (800Hz).
Ranges: bipolar ±0.005/0.01/0.05/0.1/0.5/1/5/10 V,
or unipolar: 0 to 0.01/0.1/1/10 Volts.
The 1Kword FIFO buffer provides more reliable data transfer and more predictable performance under Windows.
Interrupt can be generated when FIFO is half full allowing 100KHz A/D, and data streaming to disk under Windows.
Visidaq & DASYLab supports this. Has DB37 male cnnctr for analog, & 2x 20-pin cnnctrs for Digital I/O.
Includes PCLD-8115 wiring board with DB37 cnnctr, cold junction comp for thermocouples, and provision for low pass filters.
Also one analog output, and 16DI, 16DO.

PCL-818HD fully software and connector compatible with PCL-818HG except for different programmable gains (0.5, 1, 2, 4, 8).
Ranges: ±0.625 / 1.25 /2.5 / 5 / 10 V, or unipolar 0-1.25 / 2.5 / 5 / 10 V. Max throughput 100kHz for all input ranges.
Has DB-37 cnnctr for analog, & 2x 20-pin for digital. (No PCLD-8115)

Options for PCL-818 Series:

See Wiring Accessories at end of this page.

PCLS-DLL-8 Windows driver for PCL-718/818series now included with the cards
Visual Basic Custom Controls for PCL-818/L/H/HD/HG PCLS-VBX-8:

ActiveX Control drivers

for Win95/NT/98 supports PCL, PCI cards, ADAM-4000, ADAM-5000/485. See page 4. PCLS-OCX:

PCLS-OPC/MTP30-AE   Advantech Modbus/TCP for OPC Server $166+GST     9/11
PCLS-OPC/RTU30-AE   Advantech Modbus/RTU for OPC Server $166

Analog Output Cards – ISA Bus

 Data on Advantech Analog Cards

PCL-726-BE 12bit, 6ch Analog Output Card $467+GST      9/11
PCL-727-A   14bit, 12ch Synchronized Analog Output Card $759
PCL-728-AE 12bit, 2ch Analog Output Card $312

PCL-726  D/A Card: 6ch, 12-bit – ISA bus

0-5V, 0-10V, ±5V, ±10V, 4-20ma, 70usec settling time. (5usec settling by repl. OP-07 with OP-37 op amp.)
Dig I/O: 16 in, 16 out. Two 20-pin flat cable cnnctrs.
Compat with daughter brds: PCLD-780,782,785,786, PCLD-7216, PCLK-1050.
Software included.

PCL-727  D/A Card: 12ch, 12-bit – ISA bus

Each ch can be set to 0 to 5V, 0 to 10V, ±5V, or 4 to 20mA. Has output fuses. 70µsec.
Dig I/O: 16 digital in, 16 dig out.

PCL-728  D/A Card: Isolated 2ch – ISA bus

2 ch isolated, 12-bit. 0 to 5V, 0 to 10V, ±5V, ±10V,
0 to 20ma or 4 to 20ms (sink) output. Over 500V DC isolation. 60µsec.
Two 9-pin D connectors

---

Prices do not include GST and may change without notice.

PCL-812PG  16 single ended inputs ±0.3..±10V, 25µsec,12-bit;
2 analog outputs 0-5V/0-10V, (±10V ext ref) 30µsec, 12-bit;
16 DIO;   16-bit cntr.   Full length card

PCL-812PG-CE  30k, 12bit Multifunction Card $445+GST    9/11

PCL-711B   8se in ±0.3…±5V, 25µsec;  1 analog output;  16 DIO

PCL-711S  as above, with PCLD-7115 external wiring board & 1m cable

PCL-711B-BE  40k, 12bit Multifunction Card $334+GST      9/11
PCL-711S-BE  PC-MultiLab Package $357

Data on Advantech products

---

PCL-813B  32 ch Isolated A/D Card, ISA Bus

ISA bus, also good for 4-20ma Loop Inputs

32 single ended inputs opto-isolated to 500VDC, 12-bit successive approximation A/D,
SW programmable gain on each channel: ±5V, ±2.5V, ±1.25V, ±0.625V. Unipolar 5V, 1.25V, 0.25V, 0.0625V. 20mA loop.
Program controlled A/D trigger and data transfer.
25µsec conversion time, 25K/sec max data transfer rate, acc 0.01% of rdg ±1LSB.
I/O cnctr: 37-pin D-type female. 99x219mm. Requires ext resistor card for I loop inputs.
With special PCLD-881 Wiring Board, DB37 Shielded Cable,
allowing sequential connection of all input signals.

PCL-816 Hi Performance Data Acq Card, ISA bus with Analog Ouput Module

A/D inputs: 16-bit resolution, 16 differential input channels, 8.5µsec, 100KHz sample rate, analog input range is programmable: ±5V, ±2.5V, ±1.25V, ±0.625V, +10V, +5V, +2.5V, +1.25V, acc 0.003% ±1LSB of full span; progr DMA & IRQ level.
Automatic channel gain scanning (SRAM stores different gain values for each channel). DB37 male cnnctr.
Dig I/O: 16 lines in, 16 lines out, 2x 20-pin flat cable cnctrs.
Progr pacer clock 8254. Has no cable connector for daughter boards. Trigger by SW, pacer or ext trigger
Data transfer by SW, interrupt or DMA.
Incl softw. with 45 functions.

PCL-816-AE  16 Bit Modular Data Acquisition Card $843+GST      9/11

PCLS-DLL-6 Win Driver for 814B/816 included.

Data on Advantech products
