ADAM-3000 Signal Conditioners & Signal Isolators

Warranty period: 2 years.

ADAM-3000 series & PCLD- data sheets (Advantech Catalog, opens new tab or window)
Includes Terminal Board Selection Guide – Connection chart

1000VDC isolation (input/output/power) and 100dB common mode rejection. Protect your instruments and process signals from the harmful effects of ground loop, motor noise, and other electrical interference.

DIN rail mounting, signals are connected with screw terminals.
With simple two-wire input-output cables, wiring is easy and reliable under harsh industrial environments.

ADAM-3000 modules use +24 VDC power.
The electrical wiring can be connected through adjacent modules. This greatly simplifies wiring and maintenance.
The I/O configuration switches are located inside the module.
To reach the switches, you need to remove the DIN-rail bracket by sliding it down.

ADAM-3011 J/K/T/E/S/R/B type Thermocouple module. Output: 0-10V. CMR 115dB min.

ADAM-3013 RTD Input Module, Isolated       Scroll down to see price list

ADAM-3014 DC Input/Output Module 1000 VDC isolation, three-way (input/output/power) .
Voltage input:
Bipolar input: ±10 mV, ±50 mV, ±100 mV, ±0.5 V, ±1.0 V, ±5 V, ±10 V
   Unipolar input: 0 ~ 10 mV, 0 ~ 50 mV, 0 ~ 100 mV, 0 ~ 0.5 V, 0 ~ 1 V, 0 ~ 5 V, 0 ~ 10 V
Current input: Bipolar: �20 mA Unipolar: 0 ~ 20 mA Input impedance: 250 ohms
Input impedance: 2Mohm, Bandwidth 2.4kHz

Voltage output: Bipolar: ±5V, ±10V Unipolar: 0 ~ 10 V
Impedance: <50 ohms, Drive: 10 mA max.
Current output: 0 ~ 20 mA

ADAM-3016 Strain Gauge Input, isolated

ADAM-3000 series & PCLD- data sheets (Advantech Catalog, opens new tab or window)
Includes Terminal Board Selection Guide – Connection chart

Prices (Excluing GST, subject to change):
ADAM-3011-AE ISOLATED THERMOCOUPLE INPUT MODULE $291+GST    10/2020
ADAM-3013-AE ISOLATED RTD-INPUT MODULE $291
ADAM-3014-AE ISOLATED DC I/O MODULE $216
ADAM-3016-AE ISOLATED STRAIN GAUGE INPUT MODULE $291
ADAM-3017-AE EXTERNAL POWERED IEPE SIGNAL CONDITIONER $269
ADAM-3112-AE ISOLATED AC VOLTAGE INPUT MODULE $285
ADAM-3114-AE ISOLATED AC CURRENT INPUT MODULE $216

ADAM-3909-AE DB-9 WIRING TERMINAL, DIN-RAIL MOUNT $44
ADAM-39100-BE SCSI-100 WIRING TERMINAL, CONNECT $168
ADAM-3920-AE 20-PIN FLAT CABLE TERMINAL, DIN-RAIL MO $54
ADAM-3920R-AE 20-PIN FLAT CABLE WIRING RELAY BOARD $210
ADAM-3925-AE DB-25 WIRING TERMINAL, DIN-RAIL MOUNT $58
ADAM-3937-BE DB-37 WIRING TERMINAL, DIN-RAIL MOUNT $77
ADAM-3940-AE AMAX-2240 SERIES WIRING BOARD $77
ADAM-3950-AE 50-PIN FLAT CABLE TERMINAL, DIN-RAIL MO $98
ADAM-3951-BE SCREW-TERMINAL BOARD WITH LED INDICATOR $125
ADAM-3951R-AE SCREW-TERMINAL BOARD W/ RIBBON CONNECTOR $132
ADAM-3952-AE PCI-1240 WIRING TERMINAL, DIN-RAIL MOUNT $113
ADAM-3955-AE 2-AXIS 50-PIN SCSI DIN-RAIL MOTION WIRI $133
ADAM-3956-AE 4-AXIS 100-PIN SCSI DIN-RAIL MOTION WIR $147
ADAM-3962-AE DB-62 WIRING TERMINAL, DIN-RAIL MOUNT $68
ADAM-3968/50-AE SCSI-68 TO 2*IDC-50 CONVERTER, DIN-RAIL $90
ADAM-3968-AE SCSI-68 WIRING TERMINAL, DIN-RAIL MOUNT $113
ADAM-3978-AE DB-78 WIRING TERMINAL, DIN-RAIL MOUNT $132

PCLD-780-BE 2*IDC-20 WIRING TERMINAL $114
PCLD-782B-AE 16/24-CH OPTO-ISOLATED DI BOARD $260
PCLD-782-BE OPTO-ISOLATED D/I BOARD $231
PCLD-785-AE 16-CH RELAY OUTPUT TERMINAL $260
PCLD-785B-AE 24-CH RELAY OUTPUT TERMINAL $318
PCLD-788-AE RELAY SCANNER/MULTIPLEXER BOARD (CE) $358
PCLD-789D-AE AMPLIFIER & MULTIPLEXER BOARD (CE) $485
PCLD-8115-AE DB-37 WIRING TERMINAL W/CJC CIRCUIT $151
PCLD-8710-AE SCSI-68 WIRING TERMINAL W/CJC, DIN-RAIL $162
PCLD-8712-AE WIRING TERMINAL FOR PCI-1712, DIN-RAIL $202
PCLD-8751-AE 48-CH OPTO-ISOLATED DI BOARD $382
PCLD-8761-AE 24/24-CH RELAY OUTPUT/ISOLATED DI BOARD $413
PCLD-8762-AE 48-CH RELAY OUTPUT WIRING BOARD $441
PCLD-880-AE DB-37 WIRING TERMINAL $155
PCLD-8810E-AE SCREW TERMINAL BOARD WITH CJC FOR PCIE- $225
PCLD-8810I-AE SCREW TERMINAL BOARD WITH CJC FOR PCI-1 $225
PCLD-8811-AE ACTIVE FILTER BOARD $174
PCLD-8813-AE SIGNAL CONDITIONING FOR PCIE-1812/1813 $598
PCLD-881B-AE WIRING TERMINAL BOARD FOR PCI-1713 & PC $155
PCLD-8840-AE 20-PIN DIN-RAIL HDMI CABLE WIRING BOARD $114
PCLD-885-AE 16-CH POWER RELAY OUTPUT TERMINAL $306

ADAM-3000 series & PCLD- data sheets (Advantech Catalog, opens new tab or window)
Includes Terminal Board Selection Guide – Connection chart

Items ending in E are RoHS compliant.
RoHS – Restriction of Hazardous Substances   Info

DIN RAIL Mounting Accessories:

ADAM-3864  4 ch SSR Module Carrier Backplane for modules below  $156

Input modules: IAC24 (90-140VAC),   IAC24A (180-280VAC),   IDC24B (3-32VDC)

Output modules: OAC24A (24-280 VAC, 3A),   ODC24 (5-60VAC, 3A)

ADAM-3854   4 ch DIN Rail Relay Module, 250VAC 5A, 30VDC 5A, Single pole dble throw (ch over).
Input to each relay coil: 24VDC 2.2W

ADAM-3854-AE   4-ch Power Relay for DIN-rail Mounting $117+GST  9/14

ADAM-3000 series & PCLD- data sheets (Advantech Catalog, opens new tab or window)
Includes Terminal Board Selection Guide – Connection chart

Various Cable Connectors  to  Screw Terminals  converters

ADAM-3920   20-pin Flat Cable to 20 Screw Terminals, DIN rail mnting

ADAM-3950   50-pin flat cable cnnctr to 50 Screw terminals, DIN rail mnting module

ADAM-3909   DB9F to 9 Screw terminals, DIN rail mnting

ADAM-3925   DB25F to 26 Screw terminals, DIN rail mounting. (Looks similar to ADAM-3937)

ADAM-3937   DB-37F to 38 Screw terminals, DIN rail mounting module, see picture.

ADAM-3968   68-pin female cnnctr (SCSI type) to 68 Screw terminals
ADAM-3968/50 68-pin female (SCSI), to Two 50-pin box header

For prices, see the list above.
