Digital I/O Cards

Digital input cards | Digital output cards | Relay outputs | Counter / Timer cards

Digital I/O Cards, Advantech, etc

Warranty period for Advantech cards: 2 years.

Wiring boards, signal conditioning, amplifier & relay daughter boards are available for many of these cards.
See menu at left, if there is no menu

Software supplied with cards:
PCLS-DLL-DIO Windows Drivers for Win95 & NT

Other related pages:

Analog I/O Cards

WaveScan 2
Wavescan is a real-time waveform display utility capable of displaying on the screen and storing the incoming data into users’ HDD.
In the Version 2.0, moreover, Wavescan extend its support list to all our PCI cards.
The ActiveDAQ-based design concept gives more fexibility to the users by designing their own Wavescan edition.
See Software (for Advantech hardware only) (opens new tab)

Other software available: See Software (for Advantech hardware only) (opens new Tab or Window)

Note about installing the drivers for cards and devices under Windows

It is best to install the driver software before you install the actual hardware

1. Reboot the computer
2. Install the driver.
3. Insert the card into the PCI bus
4. Power on and take note of the i/o and interupt the PnP bios gives the card.
5. Boot into Windows and let the cards detect and let Windows search for the driver.

If you installed the card before installing the drivers:

1. Uninstall the driver, power off, remove the card.
2. Reboot, reinstall the driver.
3. Reinsert the card into the PCI bus, but in a different slot
4. Power on and take note of the i/o and interupt the PnP bios gives the card.
5. Boot into Windows and let the cards detect and let Windows search for the driver.

PCI Bus Cards – Plug and Play

Advantech PCI Bus Digital I/O Cards

Part Number

Description

Analog Input*

Analog Output*

General

Isolated Digital I/O

Relay Output

Timer/Counter

TTL DI/O

Channels

Resolution (Bits)

Sampling Rates (S/s)

Type

Channels

Resolution (Bits)

Update Rate (S/s)

Bus

Input Channels

Output Channels

Channels

Input Channels

Output Channels

PCI-1733-BE

32-ch Isolated Digital Input PCI Card

N/A

PCI

32

N/A

PCI-1734-CE

32-ch Isolated Digital Output PCI Card

N/A

PCI

N/A

32

N/A

PCI-1735U-AE

64-ch Digital I/O and Counter Universal PCI Card

N/A

PCI

N/A

3

32

PCI-1737U-BE

24-ch Digital I/O Universal PCI Card

N/A

PCI

N/A

24 (shared)

PCI-1739U-AE

48-ch Digital I/O Universal PCI Card

N/A

PCI

N/A

48 (shared)

PCI-1742U-AE

1 MS/s, 16-bit, 16-ch Universal Multifunction PCI Card

16

1 M

Scan

2

16

2 M

PCI

N/A

1

16

PCI-1747U-AE

250 kS/s, 16-bit, 64-ch Analog Input Universal PCI Card

64

16

250 K

Scan

N/A

PCI

N/A

PCI-1750-BE

32-ch Isolated Digital I/O and 1-ch Counter PCI Card

N/A

PCI

16

N/A

1

N/A

PCI-1750SO-AE

32-ch Isolated Digital I/O and 1-ch Counter PCI Card

N/A

PCI

16

N/A

1

N/A

PCI-1751-BE

48-ch Digital I/O and 3-ch Counter PCI Card

N/A

PCI

N/A

3

48 (shared)

PCI-1752U-BE

64-ch Isolated Digital Output Universal PCI Card

N/A

PCI

N/A

64

N/A

PCI-1752USO-BE

64-ch Isolated Digital Output Universal PCI Card

N/A

PCI

N/A

64

N/A

PCI-1753-CE

96-ch Digital I/O PCI Card

N/A

PCI

N/A

96 (shared)

PCI-1754-BE

64-ch Isolated Digital Input PCI Card

N/A

PCI

64

N/A

PCI-1756-BE

64-ch Isolated Digital I/O PCI Card

N/A

PCI

32

N/A

PCI-1757UP-AE

24-ch Digital I/O Low Profile Universal PCI Card

N/A

PCI

N/A

24 (shared)

PCI-1758UDI-AE

128-ch Isolated Digital I/O Universal PCI Card

N/A

PCI

128

N/A

PCI-1758UDIO-AE

128-ch Isolated Digital I/O Universal PCI Card

N/A

PCI

64

N/A

PCI-1758UDO-AE

128-ch Isolated Digital I/O Universal PCI Card

N/A

PCI

N/A

128

N/A

PCI-1760U-BE

8-ch Relay and 8-ch Isolated DI PCI Card with 8-ch Counter/Timer

N/A

PCI

8

N/A

8

N/A

PCI-1761-BE

8-ch Relay and 8-ch Isolated Digital Input PCI Card

N/A

PCI

8

N/A

8

N/A

PCI-1762-BE

16-ch Relay and 16-ch Isolated Digital Input PCI Card

N/A

PCI

16

N/A

16

N/A

PCI-1780U-AE

8-ch, 16-bit Counter/Timer Universal PCI Card

N/A

PCI

N/A

8

PCI-1784U-AE

4-axis Quadrature Encode/Counter Universal PCI Card with 8-ch Isolated Digital I/O

N/A

PCI

N/A

4

4 (Shared)

PCIE-1730-AE

32-ch TTL and 32-ch Isolated Digital I/O PCIE Card

N/A

PCIe

16

N/A

16

PCIE-1730H-AE

32-ch TTL and 32-ch Isolated Digital I/O PCIE Card

N/A

PCIe

16

N/A

16

PCIE-1750U-AE

32-ch Isolated Digital I/O with universal output PCIE Card

N/A

PCIe

16

N/A

PCIE-1751-AE

48-ch Digital I/O and 3-ch Counter PCIE Card

N/A

PCIe

N/A

3

48 (shared)

PCIE-1752-AE

64-ch Isolated Digital Output PCIE Card

N/A

PCIe

N/A

64

N/A

PCIE-1753-AE

96-ch Digital I/O PCIE Card

N/A

PCIe

N/A

96 (shared)

PCIE-1754-AE

64-ch Isolated Digital Input PCIE Card

N/A

PCIe

64

N/A

PCIE-1756-AE

64-ch Isolated Digital I/O PCIE Card

N/A

PCIe

32

N/A

PCIE-1756H-AE

64-ch Isolated Digital I/O PCIE Card

N/A

PCIe

32

N/A

PCIE-1758DI-AE

128-ch Isolated Digital I/O PCIE Card

N/A

PCIe

128

0

N/A

PCIE-1758DIO-AE

128-ch Isolated Digital I/O PCIE Card

N/A

PCIe

64

N/A

PCIE-1758DO-AE

128-ch Isolated Digital I/O PCIE Card

N/A

PCIe

0

128

N/A

PCIE-1760-AE

8-ch Relay and 8-ch Isolated Digital Input PCIE Card

N/A

PCIe

8

N/A

8

2

N/A

PCIE-1761H-AE

8-ch Relay and 8-ch Isolated Digital Input w/ digital filter and interrupt PCIe Card

N/A

PCIe

8

N/A

8

N/A

PCIE-1762H-AE

16-ch Relay and 16-ch Isolated Digital Input w/ digital filter & interrupt PCIe Card

N/A

PCIe

16

N/A

16

N/A

PCIE-1763AH-AE

16-ch Solid-State Relay Output and 16-ch Isolated Digital Input with Digital Filter and Interrupt PCIE Card

N/A

PCIe

16

N/A

16

N/A

PCIE-1763DH-AE

16-ch Solid-State Relay Output and 16-ch Isolated Digital Input with Digital Filter and Interrupt PCIE Card

N/A

PCIe

16

N/A

16

N/A

Axiomtek Analog & Digital I/O Cards

PCI Analog I/O Cards:
DASP-52104 14-bit Isolated 4 Analog Output w/Free-running Card
DASP-52180 12-bit 8 Isolated Analog Input w/Free-running Card
DASP-52282 12-bit 330KHz Multifunction w/Free-running Card
DASP-52283 12-bit 330KHz Multifunction w/Free-running Card
DASP-52286 16-bit 1MHz Multifunction Card

PCI Digital IO Cards:
DASP-52010 10-Channel Counter/Timer Card
DASP-52016 8 Isolated D/I and 8 Relay Output Card
DASP-52032 16 Isolated D/I and 16 Relay Output Card
DASP-52048 48-Channel DI/O and 1 Timer/Counter Card
DASP-52064 Isolated 32 D/I & 32 D/O Card
DASP-52096 High Density 96-channel DI/O Card

PCI Motion Control Cards:
DASP-52504 4-axis Servo / Stepping Motion Card
DASP-52506 6-axis Servo / Stepping Motion Card

Daughter Boards for outside the PC

AX750   General Purpose Screw Terminal Panel
AX752   16 Channel Amplifier & Multiplexer Panel
AX754   24 Channel Opto-isolated DI Panel
AX755     8 Channel Relay Output & 8 Channel Opto-isolated DI Panel
AX755/24   24 Channel Relay Output & 24 Channel Opto-isolated DI Panel
AX757          8 Channel Relay Output & 16 Channel Opto-isolated DI Panel
AX756A/B   24 Channel Relay Actuator Panel
AX758         16 Channel Relay Multiplexer Panel
AX851         DP-37 Universal Screw Terminal Panel
AX951A/B   Universal Screw Terminal Panel
AX1416/24   Solid-state Module Panel and I/O Module

Advantech ISA Bus Digital I/O Cards

PCL-720+-AE CIRCUIT BOARD, 64ch TTL Digital I/O Card w/Counter $196+GST 10/13
PCL-722-BE CIRCUIT BOARD, 144ch TTL Digital I/O Card $292
PCL-724-AE CIRCUIT BOARD, 24ch TTL Digital I/O Card $156
PCL-725-AE CIRCUIT BOARD, 8ch Relay & 8ch Isolated DI Card $179
PCL-726-BE CIRCUIT BOARD, 12bit, 6ch Analog Output Card $532
PCL-726-CE CIRCUIT BOARD, 12bit, 6ch Analog Output Card $527
PCL-727-BE CIRCUIT BOARD, 14bit, 12ch Synchronized Analog Output Card $835
PCL-728-AE CIRCUIT BOARD, 12bit, 2ch Analog Output Card $354
PCL-728-BE CIRCUIT BOARD, 12bit, 2ch Analog Output Card $351
PCL-730-CE CIRCUIT BOARD, 32ch Isolated Digital I/O Card w/32ch TTL DIO $253
PCL-731-AE CIRCUIT BOARD, 48ch TTL Digital I/O Card $166
PCL-733-BE CIRCUIT BOARD, 32ch Isolated Digital Input Card $238
PCL-734-BE CIRCUIT BOARD, 32ch Isolated Digital Output Card $238
PCL-735-AE CIRCUIT BOARD, 12ch Relay Card $240

PCL-720 64 Ch Dig I/O + Counter + Breadboard

Digital I/O: TTL 32 lines in, 32lines out, sink 24ma.
Counter/Timer: Programmable, 70154 CMOS: 3ch 16bit.
Breadboard: 31×21 pads, .1″ centres. Use connection board PCLD-782/785/786/885/780.
Connector: 5x 20-pin cnnctrs (4 for DIO, 1 for Cntr/Tmr)

PCL-722 144 Ch Digital I/O Card

144 dig I/O lines, 6 ports of 24 bits, each emulating 8255 mode 0 with buffered output: 24ma I sink & 15ma source.
I/f for Opto-22 I/O module rack card. Two Interrupt inputs, read back of output port state.
6 x 50-pin ribbon cable cnnctrs. Use connection board PCLD-782B/785B/885/ -7216/24Q
Connector: 6x 50-pin flat cable or Opto-22 cnnctrs

Cables:
PCL-10150-1.2E IDC-50 Flat Cable, 1.2m $34+GST 3/12
PCL-10150M-2E Cable 50-Pin SCSI, Ribbon type,2M $55

PCL-724 24 Ch Digital I/O Card

Emulates 8255 PPI chip (mode 0) but with higher drive capacity. Has read-back.
Two Interrupt inputs, Bit 0 of port C can generate interrupt to IRQ 2 to 7.
50-pin cnnctr compatible with OPTO-22 I/O module racks.
Use connection board PCLD-782B/785B/885.
Connector: 1x 50-pin Opto-22 cnnctr, & positions for 2x 20-pin cnnctrs paralleled to the 50-pin.
(Two 20-pin cnnctrs are supplied loose)

PCL-10150-1.2 Cable flat 50-pin, 1.2m…stake cnnctrs both ends
(for connecting PCL-722 or724 to PCLD-885, 782B, or 785B) Price: see above

PCL-731 48-bit Digital I/O Card

As for PCL-724, except with 48 lines, Two Interrupt inputs IRQ2 to15.
Two 50-pin connectors. Use connection board PCLD-782B/785B/885/ -7216/24Q.
Connector: 2x 50-pin Opto-22 cnnctrs

‡ Providing Screw Terminals ‡

‡ PCLD-880 external wiring board has 37-pin D connector and 2x 20-pin flat cable cnnctrs for connection to the I/O cards below marked with ‡ sign.
See menu at left, 3rd item. PCLD-880 (opens in new tab)

‡ ADAM-3937 has a 37-pin D connector, providing a screw terminal for each pin ADAM-3937 (opens in new tab) .

PCL-725 Relay Out+Dig Inp, Isol ‡

Relay Contacts: 8 ch SPDT (Form C) 120VAC/DC,1a, 500V AC/DC breakdown, req +12V 33ma per relay from the PC bus, has LED indicator for each relay.
Dig Inputs: 8ch opto 4N25, 1500V isolation, 80ma or 1.5V threshold,
Connector: DB37F (37-pin D-type female cnctr) on card, male cnctr included. ‡

PCL-730 32 Ch Isolated Dig I/O ‡

16 input & 16 output lines, all isolated, plus
16 input & 16 output line, TTL (not isolated). Use with board PCLD-782/785/786/885/880(isol)
Has 4x 20-pin for the non-isolated I/O &
Connector: 1x DB37F cnnctr for the isolated I/O ‡

PCL-733 32 Ch Isolated Dig Inp ‡

2500VDC isolation, Vin +5 to +24VDC, Rin 1.2Kohms, 10KHz thruput, with 2 interrupts (ch 0 & 16): Intrrpt lvls 2,3,5,7,10,12or15.
Connector: 1x DB-37F, use connection board PCLD-880. ‡

PCL-734 32 Ch Isolated Dig Out ‡

1000VDC isolation, Outputs are open collector transistors with suppression diode for inductive loads (+5 to 40VDC) 200mA/ch. 10KHz thruput. DB37
Use connection board PCLD-880.
Connector: 1x DB-37F. ‡

PCL-735 12 Ch Relay Output ‡

SPDT, Single pole double throw, Form C contacts.125VAC or 100VDC, 0.6A. 1000VAC/DC breakdown.
Addr two consec. bytes 200H – 3F8H. Readback of relay status, red LEDs on each.
Connector: 1x DB-37F. A DB-37M mating cnnctr is supplied
Use connection board PCLD-880. Has 1x DB-37F ‡

PCL-836 6 Ch Counter Timer

Has two 8254 chips, digital filter, binary or BCD, progr freq output, complex duty cycle output, sel interrupt input channel (2,4,5,7,10,11,12,15),
10MHz in, pulsewidth & period measurement, time delay generation, F/V conversion & accumulation; 3 PWM outputs,
16 TTL inputs & 16-bit TTL outputs Connectors: DB37 D cnnctr for counter I/O, 20-pin male flat cable connecter for dig I/O. 185 x 100mm.
Use connection board PCLD-782/785/786/885.
To connect to the DB37, use ADAM-3937 (screw term to DB37) and PCL-10137-1 (D37 cable).

Motion Control Cards

PCL-833 3-Axis Quadrature Encoder – ISA bus

3 independent 24-bit up/down counters (cascadable to 48-bit) and 5 digital inputs with 2500VDC isolation.
1MHz quadrature input rate, 2.4MHz input pulse rate, Programmable time interval interrupt.
Use connction board PCLD-782/785/786/885. Has DB25F cnnctr.
Windows dll driver for this card is supplied.

PCL-839 Stepping Motor Ctrlr – ISA bus

ISA bus. Fully Independent, simultaneous operation of 1, 2, or 3 motors, with dig I/O 8 bit in & 8 bit out.
Uses 3x 8039 processors & ROM to execute ctrl cmds.
Prog speed 1 to >4095 RPM (motor with >200 steps/rev) (ie 3.33 to 13650 pps) with accel/decel.
Either two pulse (CW, CCW) or pulse- direction mode.
Step no 1 to 32767 with read-back step posn. Output opto-coupled with open-collector.
Controllable by programming registers directly. Linear & circular interpolation functions.
Digital I/O (sep from above): 24 lines in 24 lines out, Digital inputs with interrupt, 37-pin mating cnctr.
Half size card. Incl PCL-10437-0 37-pin cnnctr assy.
Windows dll driver for this card is supplied. Disk provided has C Library & Command Interpreter

PCI-1240 4-Axis Stepping/Pulse-type Servo Motor Control Card

Axiomtek Analog & Digital I/O Cards

ISA Bus Cards
AX5008 8 Channel Relay Actuator & Opto-isolated DI Board
AX5032A    16-Channel Relay Actuator & Opto-isolated DI Board
AX5032IO 32 Channel DI & 32 Channel DO with Isolation Board
AX5064I     64 Channel Opto-isolated DI Board
AX5064O   64 Channel Opto-isolated DO Board
AX5210H    16 Channel Data Acquisition Board
AX5210H+ 16 Channel Data Acquisition / 2 Channel Analog Output Board
AX5213         2 Channel Isolated Analog Output Board
AX5214H   48 Bit DIO Board
AX5215H   96 Bit DIO Board

AX5216           5 Channel Counter/Timer Board
AX5218         10-Channel Counter/Timer & 24 Bit DIO Board
AX5220HA/B 32 Bit DIO & 3 Channel Counter/Timer Board
AX5224H         24 Bit DIO & 3 Channel Counter/Timer Board

AX5232      32 Channel Isolated Temp./Voltage Measurement Board
AX5244H   144 Bit DIO Board
AX5411H   Multifunction Data Acquisition Board
AX5412H   High Speed Multifunction Data Acquisition Board
AX5621H+ 16 Bit Multifunction Data Acquisition Board

GPIB – IEEE-488 Cards

PCI-1670 GBIP Interface PCI-bus – Advantech

Complete IEEE 488.2 compatibility zcu
Supports Windows 95/98/NT/ME/2000/XP and DOS.
Full driver, library, and example support, including Visual C++, Borland C++
Provides NI-like driver & function libraries.
PCI bus specifi cation 2.1 compliant
I/O address automatically assigned by PCI plug-and-play.
Provides powerful and easy-to-use configuration utility

PCI-1671UP-AE GPIB Interface Card $636+GST 3/12

Cables
PCL-10488-2 IEEE-488 Cable, 2M $86+GST 3/12

Ines GPIB Solutions – PXI Control Solutions

GPIB-PCI-XL GPIB-PCMCIA-XL GPIB-cPCI-XL GPIB-PMC-XL GPIB-PC104 GPIB cables sns
Data: click here (Ines site, opens in new tab)

PCI-488-CEC controls all IEEE488, GP-IB and HP-IB instruments

Plug-and Play Software with Auto Addressing for Instant Switchless Configuration dln
PCI-488 works in any computer with one or more PCI slots and controls all IEEE488, GP-IB and HP-IB instruments.
It implements all required and optional features of the IEEE-488.2 standard.

PCI-488 Commands: all IEEE-488.2 functions, including listen, talk, device clear, group execute trigger, go to local, interface clear, local lockout, parallel poll configure or disable, remote enable, selected device clear, serial poll, pass control, take control, unlisten and untalk
Macro Commands: commands and data an be combined in a single statement
Addressing: the IEEE-488 address of PC488 is programmable. PC488 can listen or talk to any device at any address
Modes: PC488 supports system controller and device mode programming. Modes are software selectable

Supported Languages: BASIC, QBASIC, Professional BASIC7, QuickBASIC, Visual BASIC for DOS & Windows Quick Pascal,
TurboPascal, Delphi, Quick C for DOS & Windows, C, C++, Visual C/C++, Watcom C, FORTRAN, hpVEE, LabVIEW, LabWindows CVI, TestPoint

Wiring Accessories

PCL-10501 Adaptor for Analog ports:
2x 20-pin female ribbon cable cnnctrs to 37-pin D-type F connector,
plus a 37-pin male connector with solder lugs for wiring to shielded cable

PCL-10502 Digital I/O Port Adaptor, extends dual 20-pin flat cable from centre of PC-Labcards to the edge of PC slot for user access:
Two 40cm, 20-pin flat ribbon cables and a metal I/O bracket with 20-pin male ribbon cnnctrs, (2 inside and 2 outside)

PCL-10503 Adaptor, converts dual 20-pin flat cable male cnnctrs inside, to external 37-pin female D-type.
Useful with both digital & analog ports

PCL-10502-AE Extender,Extend Dual 20P To PC Slot-Plate $33+GST 9/11
PCL-10503-AE Adapter Dual 20P To D-37 $33

Other Cables:
PCL-10120-0.4E IDC-20 Flat Cable, 0.4m $24+GST 9/11
PCL-10120-1E IDC-20 Flat Cable, 1m $24
PCL-10120-2E IDC-20 Flat Cable, 2m $30
PCL-10121-2E IDC-20 Shielded Cable, 2m $31
PCL-10125-1E DB-25 Shielded Cable, 1m $32
PCL-10125-3E DB-25 Shielded Cable, 3m $43
PCL-10126-0.2E CABLE, FLAT CABLE DB25PF/IDE#2 26P-2.54 20CM $25

PCL-10137-1E DB-37 Shielded Cable, 1m $32
PCL-10137-2E DB-37 Shielded Cable, 2m $36
PCL-10137-3E DB-37 Shielded Cable, 3m $41
PCL-10137H-1E DB-37 High-Speed Shielded Cable, 1m $45
PCL-10137H-3 DB-37 High-Speed Shielded Cable, 3m $72
PCL-10137H-3E DB-37 High-Speed Shielded Cable, 3m $72

PCL-10141-0.2E CABLE, F Cable D-SUB 37P(F)/IDE#2 40P-2.54 20CM $31

PCL-10150-1.2E IDC-50 Flat Cable, 1.2m $34
PCL-10150M-2E Cable 50-Pin SCSI, Ribbon type,2M $55
PCL-10152-1E 50-pin SCSI M-M Shielded Cable, 1m $47
PCL-10152-3E 50-pin SCSI M-M Shielded Cable, 3m $68

PCL-10162-1E DB-62 Shielded Cable, 1m $48
PCL-10162-3E DB-62 Shielded Cable, 3m $61
PCL-10168-1E SCSI-68 Shielded Cable, 1m $49
PCL-10168-2E SCSI-68 Shielded Cable, 2m $68
PCL-10178-1E DB-78 Shielded Cable, 1m $66

PCL-10220-1E 40-pin IDC to two 20-pin IDC cable, 1m $44
PCL-10220M-2E SCSI-20 Ribbon-Type Cable with 2 connectors, 2m $72
PCL-10250-1E SCSI-100 to 2*SCSI-50 Shielded Cable, 1m $77
PCL-10250-2E SCSI-100 to 2*SCSI-50 Shielded Cable, 2m $81
PCL-10251-1E SCSI-100 to 2*SCSI-50 Shielded Cable, 1m $79
PCL-10251-2E SCSI-100 to 2*SCSI-50 Shielded Cable, 2m $87
PCL-10251-3E 100Pin to two 50Pin SCSICable for PCI-1240,3M $91
PCL-10268-1E SCSI-100 to 2*SCSI-68 Ribbon-Type Cable, 1m $74
PCL-10268-2E SCSI-100 to 2*SCSI-68 Ribbon-Type Cable, 2m $89
PCL-10488-2 IEEE-488 Cable, 2M $86

Digital I/O Cards

Digital I/O Cards, Advantech, etc

Warranty period for Advantech cards: 2 years.

On this page:

Other related pages:

PCI Bus Cards – Plug and Play

Axiomtek Analog & Digital I/O Cards

Daughter Boards for outside the PC

Advantech ISA Bus Digital I/O Cards

Motion Control Cards

Motion Control Cards

Axiomtek Analog & Digital I/O Cards

GPIB – IEEE-488 Cards

Wiring Accessories
