News, January 2013: Hazardous locations
Advantech Announces ADAM-4000 and ADAM-6000 Series Have Received UL Approved Class I, Division 2 Certification.
They can be used in hazardous locations, more info below. i.e. gas, mining, oil or petrochemical industry where highly flammable substances may be produced, processed, stored, and transported to ensure the safety of the industrial facility.
Certified for use in the oil and gas industries, the Advantech ADAM-4000 Series and ADAM-6000 Series won’t cause explosions if gases, vapors and liquids are present.
Class I, Flammable Gases, Vapours or Liquids:
Division 2: Where ignitable concentrations of flammable gases, vapours or liquids are not likely to exist under normal operating conditions.
Zone 2: Where ignitable concentrations of flammable gases, vapours or liquids are not likely to exist under normal operating conditions.
Note: the term “intrinsically safe” applies to Class 1 or 2, Division 1, where ignitable concentrations of combustible dusts can exist all or some of the time under normal operating conditions. More info (Wikipedia) (opens in new tab)
ADAM 6000 Series
Smart Ethernet and Web I/O Modules
Smart Web I/O Modules – ADAM-6000 Smart Web I/O Module are industrial-grade Ethernet hub/switch/IO for Ethernet networking solutions in Industrial Automation environments.
They allow users to expand their industrial networks fast and cost-effectively.
The data is presented to the host in Modbus TCP/IP, UDP, or TCP/IP. Scada software such as Citect can use them.
RJ-45 connector is provided for ethernet.
Analog Input/Output Modules (ADAM-6015 to ADAM-6024) The analog input modules use microprocessor-controlled, high resolution, 16-bit, sigma-delta A/D converters to acquire sensor signals such as voltage, current, thermocouple or RTD.
ADAM-6000 Modules now include Peer-to-Peer & Graphical Conditional Logic Functionality – July 2008
Advantech has announces a new firmware enhancement for the ADAM-6000 Ethernet I/O modules which adds
advanced Peer-to-Peer (P2P) and Graphic Condition Logic (GCL) functionality.
PEER TO PEER: With this functionality, these distributed Ethernet I/O modules can actively update input channel status to specific output channels. In the past, a controller was needed to read data from the Ethernet input modules to Ethernet output modules. Now the data will transfer automatically, with no extra controller or programming needed. Also, it can minimize the system response time.
GRAPHIC CONDITION LOGIC: GCL is a windows-based software utility to add control logic between input and output without extensive programming. GCL can easily create equivalent instructions to simple ladder logic instructions on PLC’s. It also supports flexible cascade function locally or over the Ethernet network.
The ADAM-6000 modules provided a variety of input/output options, a simple PC ladder logic, logic cascade and feedback function, online monitoring of running status, the ability to connect to SCADA/HMI software, a built-in web server, and an extremely fast response time.
Prices:
ADAM-6015-BE CIRCUIT MODULE, 7-Ch RTD Input Module $433+GST 9/14
ADAM-6017-BE CIRCUIT MODULE, 8-Ch AI/DO Module $369
ADAM-6017-CE CIRCUIT MODULE, 8-Ch AI/DO Module $369
ADAM-6018-BE CIRCUIT MODULE, 8-Ch Thermocouple Input w/ DO Module $513
ADAM-6022-A1E CIRCUIT MODULE, Ethernet-based Dual-loop PID Controller $490
ADAM-6024-A1E CIRCUIT MODULE, 12-ch Isolated Universal I/O Module $553
E at the end of the part number indicates RoHS compliance.
The -A, -D or -D2 after the part number is a revision number and can be ignored when ordering.
Brochure with data on ADAM Modules (pdf file, opens in new tab)
ADAM-6000 User Manual (opens new tab or window)
ADAM-6000 Series
ADAM-6017 8-channel Analog Input w/DO Module
The ADAM-6017 is designed with 8 analog inputs and 2 digital outputs to satisfy all plant needs.
Each analog channel is allowed to configure an individual range for variety of applications.
10/100 Mbps communication rate
I/O type: 8 AI / 2 DO
Input type: mV, V, mA
Provide default/customized web page
Provides math. Functions: Max., Min., Avg.
ADAM-6050 Series: Digital Input/Output/Counter, Relay
The digital input/output channels provide three operational modes, with each channel able to set its operational mode independently. The counter/frequency module offers two 32-bit counter channels and a built-in programmable timer for frequency measurement. The relay module offers six isolated digital input channels and six isolated relay channels.
ADAM-6052 New Source Type Digital I/O Module from Advantech
Advantech presents the ADAM-6052, a 16-channel source type digital input/output module. With 8 digital inputs, and 8 source type digital outputs, the ADAM-6052 is aimed at meeting the demands for simpler control system architectures. The 1 A source type digital output signal is highly suitable for applications such as solenoid valve control in chemical plants, or any other kind of low current applications that need to be carefully controlled
Brochure with data on ADAM Modules (pdf file, opens in new tab)
Prices:
ADAM-6050-CE CIRCUIT MODULE, 18-Ch Isolated DI/O Module $237+GST 9/14
ADAM-6051-CE CIRCUIT MODULE, 16-Ch Isolated DI/O w/Counter Module $237
ADAM-6052-CE CIRCUIT MODULE, 16-Ch Source Type DI/O Module $254
ADAM-6060-CE CIRCUIT MODULE, 6 Relay Output/6 DI Module $254
ADAM-6066-CE CIRCUIT MODULE, 6 DO/6 DI Power Relay Module $272
Digital I/O EtherNet/IP Modules – isolated
EtherNet/IP (Ethernet Industrial Protocol) is designed for use in process control and other industrial automation applications. It is a communications protocol developed by Rockwell Automation, managed by the Open DeviceNet Vendors Association (ODVA).
Info about EtherNet/IP: http://en.wikipedia.org/wiki/EtherNet/IP (opens in new tab)
ADAM-6100 Real-time Ethernet I/O Modules
EtherNet/IP & PROFINET
Today, EtherNet/IP and PROFINET are two commonly used protocols in process control, manufacturing, and other industrial automation applications,
ensuring multi-vendor system interoperability.
EtherNet/IP is known as object orientated organization, and allows ordinary office Ethernet to become a more versatile system;
PROFINET is the open industrial Ethernet standard, including two modes – PROFINET IO and PROFINET CBA – and allowing combining distributed automation and distributed I/O flexibly.
Advantech’s ADAM-6100 EtherNet/IP and PROFINET Series can build a real-time distributed control system that is reliant on reliable and real-time communication among the controllers and devices. Improving safety, quality, and efficiency, a real-time system is expected to respond not just quickly, but also within a predictable period of time via industrial-grade EtherNet/IP and PROFINET protocols.
Brochure with data on ADAM Modules (pdf file, opens in new tab)
see pages 15 – 16 for ADAM-6100 modules
ADAM-6117EI-AE CIRCUIT MODULE, 8-ch Isolated AI EtherNet/IP Module $567+GST 9/14
ADAM-6117PN-AE CIRCUIT MODULE, 8-ch Isolated AI PROFINET Module $567
ADAM-6124PN-AE CIRCUIT MODULE, 4-ch Isolated AO PROFINET Module $570
ADAM-6150EI 15-ch Isolated Digital I/O EtherNet/IP Module
EtherNet/IP protocol
8-ch digital input and
7-ch digital output (sink)
Normal output current: 0.1 A (per channel)
2 x RJ-45 LAN (daisy chain)
Connectors: 2 x RJ-45 LAN (Daisy Chain), Plug-in screw terminal block (I/O and power)
Isolation Protection 2,500 VDC
Advantech’s ADAM-6100 series is a new line of Industrial Ethernet Remote I/O modules.
Designed with 2,500 VDC isolation protections, ADAM-6150EI, 15-ch isolated digital I/O EtherNet/IP module, is very resistant to field interference.
It is also equipped with the EtherNet/IP protocol, and allows daisy chain connections, making it possible to transfer data much faster during process control and other industrial automation applications.
Daisy chain connectivity provides a more scalable system with fewer wires to help avoid interference common in factory settings.
More importantly, Advantech’s ADAM.NET Utility comes bundled with each ADAM-6100 module, allowing users to configure, set, and test ADAM-6100 modules through Ethernet.
Data sheet on ADAM-6150EI, ADAM-6151EI, ADAM-6156EI, ADAM-6160EI (pdf file, opens in new tab)
ADAM-6150EI-AE CIRCUIT MODULE, 15-ch Isolated DI/O EtherNet/IP Module $381+GST 9/14
ADAM-6150PN-AE CIRCUIT MODULE, 15-ch Isolated DI/O PROFINET Module $381
ADAM-6151EI-AE CIRCUIT MODULE, 16-ch Isolated DI EtherNet/IP Module $381
ADAM-6151PN-AE CIRCUIT MODULE, 16-ch Isolated DI PROFINET Module $381
ADAM-6156EI-AE CIRCUIT MODULE, 16-ch Isolated DO EtherNet/IP Module $382
ADAM-6156PN-AE CIRCUIT MODULE, 16-ch Isolated DO PROFINET Module $382
ADAM-6160EI-AE CIRCUIT MODULE, 6-ch Relay EtherNet/IP Module $414
ADAM-6160PN-AE CIRCUIT MODULE, 6-ch Relay PROFINET Module $414
ADAM-6200 Series Ethernet I/O Modules
ADAM-6200 Series Ethernet I/O Modules
• Daisy chain connection with auto-bypass protection
• Remote monitoring and control with smart phone/pad
• Group configuration capability for multiple module setup
• DI/O LED Indication
• Flexible user-defined Modbus address
• Intelligent control ability by Peer-to-Peer and GCL function
• Multiple protocol support: Modbus TCP, TCP/IP, UDP,
• HTTP, DHCP
• Web language support: XML, HTML 5, Java Script
• System configuration backup
• User Access Control
Flexible Deployment with Daisy Chain Networking and Auto-Bypass Protection
Auto-bypass Protection
To prevent this critical issue from happening,
Advantech especially refines the hardware design of
ADAM-6200 so that it can rapidly recover the network
connection in about 2.5 seconds. Therefore, the
damage will be greatly minimized.
Remote Monitoring and Control with Smart Phone/Pad
HTML 5
HTML is a markup language popularly used to program the content for Web page over the Internet.
The fifth revision (HTML 5) is the latest revision which enhances its syntax structure
and additionally mixes up with rich Web technologies like CSS, Java Script to implement more Web service,
API, interactive applications in mobile communications.
Group Configuration Capability for Multiple Module Setup
ADAM-6200 series module is equipped with group configuration capability to reduce the repetitive
efforts and quickly finish the multiple module setups,
including firmware upgrade, configuration and HTML 5 file at one time.
Users can finish the module installation faster than before as the configuration time tremendously reduced.
ADAM-6217 8-ch Isolated Analog Input Modbus TCP Module
Interface: 10/100Mbps Ethernet
Channels: 8
Input Impedance: >10MΩ(voltage), 120 Ω(current)
Voltage Inputs: ± 150mV, ± 500mV, ± 1V, ± 5V, ± 10V
Current Inputs: 0 ~ 20 mA, 4 ~ 20mA, ± 20mA
Sampling Rate (samples/ second) 10
Burn-out Detection: Yes (4~20 mA)
Resolution 16-bit
Power Consumption 3.5W
Brochure with data on ADAM Modules (pdf file, opens in new tab)
see pages 19 – 21 for ADAM-6200 modules
ADAM-6217-AE CIRCUIT MODULE, 8-ch Isolated Analog Input Modbus TCP Module $369+GST 9/14
ADAM-6224-AE CIRCUIT BOARD, 4-ch Isolated Analog Output Modbus TCP Module $429
ADAM-6250-AE CIRCUIT BOARD, 15-ch Isolated Digital I/O Modbus TCP Module $246
ADAM-6251-AE CIRCUIT BOARD, 16-ch Isolated Digital Input Modbus TCP Module $246
ADAM-6256-AE CIRCUIT BOARD, 16-ch Isolated Digital Output Modbus TCP Module $246
ADAM-6260-AE CIRCUIT BOARD, 6-ch Relay Output Modbus TCP Module $246
ADAM-6266-AE CIRCUIT BOARD, 4-ch Relay Output Modbus TCP Module with 4-ch DI $246
ADAM-6500 & ADAM-6501:
Web-enabled Communication Controllers
The ADAM-6500 is a fully functional Ethernet-enabled controller for industrial automation and control.
It provides an ideal environment to develop applications converting RS-232/485 devices/equipment data to the Ethernet/Internet world with minimum efforts.
Brochure with data on ADAM Modules (pdf file, opens in new tab)
See price list at end of this page.
ADAM-6000 Modules now include Peer-to-Peer & Graphical Conditional Logic Functionality – July 2008
Advantech has announces a new firmware enhancement for the ADAM-6000 Ethernet I/O modules which adds
advanced Peer-to-Peer (P2P) and Graphic Condition Logic (GCL) functionality. See more near the top of this page.
ADAM-6501 Web-enabled Universal Communication Controller
Powerful Ethernet-enabled communication controller in a small package – CHECK AVAILABILITY
Built-in Windows CE .NET to run embedded Ethernet applications
Built-in web server
Microsoft embedded VC++ development environment sup
Built-in CompactFlash® slot
Flash disk for WinCE and user’s AP (ADAM-6500: 16 MB, ADAM-6501: 32 MB)
Built-in real-time clock and watchdog timer
Offers RS-232 and RS-485 series communication port (ADAM-6500: 3 x RS-232, 2 x RS-485; ADAM-6501: 1
Automatic data flow control in RS-485 mode
Communication speed up to 115.2 kbps
Easy to mount on a DIN-rail or panel Data on ADAM-6501 (.pdf file, opens in new tab or window)
With a 400 MHz Intel® XScale® processor packed into the small ADAM® form factor, ADAM-6501 provides a computing platform for challenging applications.
Equipped with a CompactFlash® slot, the controller can be equipped with custom applications or even WLAN capability.
There is also an embedded web server, FTP server, and telnet function that make it possible to create remotely operated stations.
ADAM-6501 has embedded Microsoft® Windows® CE .NET 4.2, and for applications there is 32 MB of onboard flash memory, and 64 MB SDRAM.
ADAM-6501 offers the optional Advantech Studio software, which makes it suitable for SCADA stations in EFMS applications.
ADAM-6520 Series: Ethernet Networking Modules
The industrial-grade Ethernet hubs, switches, and converters are designed to allow users to expand their industrial network fast and cost-effectively. Their rugged design ensures system reliability and stability.
ADAM-6520 5-port Industrial 10/100 Mbps Ethernet Switch
ADAM-6520 is a 5-port industrial-grade switch with Ethernet connectivity and from 10 to 100 Mbps transfer rates. (Auto-negotiation).
Just like any other product in the ADAM family, ADAM-6520 can be mounted in three different ways: DIN rail, Wall and Stack.
Solid industrial-grade design assures reliable operation in common application areas like: semi-conductor factories, inventory control environments, assembly lines, manufacturing and many more.
All modules support a wide voltage range of +10 ~ 70°, while ADAM-6520 from -40 ~ 85°. This permits them to be functional in harsh environments.
The six inclusive LED indicators make troubleshooting of the modules easier. Each prot has a pair of LEDs that indicate link status and port activities. This easily informs users of any collisions, the link status, power failure and data receipts for immediate on-site diagnosis.
ADAM-6520L 5-port Industrial 10/100 Mpbs Unmanaged Ethernet Switch
ADAM-6520L is a 5-port Industrial 10/100 Mbps Unmanaged Ethernet Switch, which substitutes ADAM-6510, which is being phased-out.
With ADAM-6520L, users can upgrade their 10 Mbps hub to a 10/100 Mbps switch, for a small cost.
ADAM-6521 Industrial Ethernet Switch with 4 x 10/100Base-TX Ports & 1 Multi-mode SC Type Fiber Optic Port
The ADAM-6521 is an industrial-grade Ethernet hub for infrastructure networking solution in industrial Automation environment.
It allows users to cost-effectively expand their industrial network with ease.
The ADAM-6521 consists of one fiber optic and four RJ-45 ports.
With fiber optic, you can prevent noise interference from the system and transmission distance up to 2 km.
The design is focused on industrial-grade reliability and stability.
Thus, the ADAM-6521 is especially suited for industrial environments with Ethernet networking needs, e.g. semi-conductor factories, inventory control environments, assembly lines, production and more.
ADAM-6521/ST Industrial Ethernet Switch with 4 x 10/100Base-TX Ports & 1 Multi-mode ST Type Fiber Optic Port
ADAM-6521/ST is an industrial-grade Ethernet switch with a fiber optic port that makes it possible to expand industrial networks fast and cost-effectively. ADAM-6521/ST has 1 fiber port and 4-RJ-45 ports.
With fiber optics, you can prevent noise interfering with your system and implement transmission distances up to 15 km.
ADAM-6521/ST supports a wide voltage range of +10 ~ 30 VDC over the terminal block, and 3,000 VDC surge protection (EFT) to protect it from being damaged by over-voltage.
A wide operating temperature range from -10 to 65° C (14 ~ 149° F), makes it functional in harsh operating environments.
Six inclusive LED indicators make troubleshooting easier.
Each port has a pair of LEDs that indicate link status and transmission speed.
This function conveniently informs users of any collisions, the link status, power failure and data receipts for immediate on-site diagnostics.
ADAM-6521S Industrial Switch with 4 10/100 Mbps Ethernet Port & 1 Single-mode Fiber Port
ADAM-652S1 is an industrial-grade Ethernet switch and single-mode fiber converter. It is designed to help extend an Ethernet network up to 15 km through areas with electrical noise interference.
ADAM-6521 has one fiber optic and four RJ-45 ports.
With single-mode fiber transmission, you can prevent noise interference and achieve transmission distances up to 15 km.
Thus, ADAM-6521S is especially suitable for industrial environments with long-distance Ethernet networking needs, e.g. warehouses, transportation, environmental monitoring, and many more.
ADAM-6541 Ethernet to Multi-mode Fiber Optic Converter
The ADAM-6541 is an industrial grade converter which is designed to convert Ethernet network (10/100Base-TX) to fiber network (100Base-FX).
It transparently converts Ethernet signals into optic signals.
The advantages of fiber optics are wide bandwidth, anti-EMI and suitable for long-distance transmission.
Therefore, the ADAM-6541 is an ideal solution for “fiber to building” application at central offices or local sites.
ADAM-6541/ST 10/100Base-TX Ethernet to 100Base-FX Multi-mode ST Type Fiber Optic Converter
ADAM-6541/ST is an industrial-grade converter designed to convert Ethernet networks to fiber networks.
It does so by transparently converting Ethernet signals to optic signals.
The advantages of fiber optics are wide bandwidth, EMI immunity and long-distance transmission capability.
Therefore, ADAM-6541/ST are ideal solution for “fiber to building” applications at central offices or local sites.
ADAM-6541/ST supports MDI/MDIX auto detection, so you don’t need to use crossover wires.
It also includes a switch controller that can sense the transmission speed (10/100 Mbps) automatically.
Both the Ethernet port and the fiber port have memory buffers that support store-and-forward mechanisms. This assures data cane be transmitted properly.
ADAM-6541/ST is extremely compact and can be mounted in three different ways:
DIN-rail, panel and piggyback.
ADAM-6541 and ADAM-6542 can operate from -10 ~ 65° C and accept a wide voltage range from +10 ~ 30 VDC. Besides, it also provides 3,000VDC surge protection (EFT) against over-voltage so it is suitable for harsh operating environments.
Prices:
ADAM-6520-BE ETHERNET DEVICE, 5-port 10/100 Mbps Industrial Switch $161+GST 9/14
ADAM-6520I-AE ETHERNET DEVICE, 5-port Wide Operating Temp. Industrial Switch $243
ADAM-6520L-AE ETHERNET DEVICE, 5-port 10/100 Mbps Unmanaged Switch $139
ADAM-6521/ST-AE ETHERNET DEVICE, 5-port Switch w/1 M-Mode ST Type Fiber Port $304
ADAM-6521-BE CIRCUIT BOARD, 5-port Switch w/1 Multi-Mode Fiber-Optic Port $304
ADAM-6521S-AE ETHERNET DEVICE, 5-port Switch w/1 Single-Mode Fiber-Optic Port $386
ADAM-6541/ST-AE ETHERNET DEVICE, Ethernet to M-Mode ST Type Fiber-optic Converter $205
ADAM-6541-AE ETHERNET DEVICE, Ethernet to Multi-Mode Fiber-Optic Converter $205
E at the end of the part number indicates RoHS compliance.
