The new AMAX-5070 ModBus/TCP coupler from Advantech provides simple and robust factory IT/OT system integration. It is a high-density ModBus TCP I/O system which aggregates data collection from all connected I/O modules.
The AMAX-5070 supports up to 255 different I/Os and has a compact form factor with dimensions of only 11 x 3 cm. It also provides Group IDs and cable redundancy to boost EtherCAT connectivity. These features combine to establish a powerful ModBus TCP DADC system that is easy to set up and remotely control, making it well-suited for factory systems upgrading to Industry 4.0 and beyond.
Photo courtesy of Advantech
Small but powerful
The AMAX-5070 ModBus TCP is part of the AMAX-5000 series and offers a maximum DIO of 160 points or AIO of 60 points within a width of only 15 cm. The AMAX-5000 series I/O also provides 15 functional modules, from basic analog/digital input and output to encoders and decoders, all managed remotely for a variety of applications.
Field site engineering simplified
The user-friendly design of the Group ID technology enables field site engineers to set up modules with speed and accuracy. The Group ID feature automatically matches a coupler’s rotary switch number, which helps engineers quickly synchronise the hardware and software for their applications.
The AMAX-5070 demands only one IP address for a maximum of 255 I/O modules. This overcomes factory IP shortage problems and streamlines maintenance for the IT department.
Key features
The AMAX-5070 Modbus TCP Coupler with ID Switch offers:
- Group IDs for Modbus Mapping
- Cable redundancy to enhance EtherCAT connectivity
- Compact, high-density design
- Fast, stable, and efficient
- Supports up to 255 I/O
- 15 functional modules
It’s a next-generation ModBus TCP coupler for fast, stable, remote management of manufacturing equipment, packing a great deal of flexibility and performance into a small form factor for reliable and efficient operation.
